Add standoffs to the Zumi board
8
Attach the mounting bracket
10
buildmanual_v4_aug2020_150size.indd 10
buildmanual_v4_aug2020_150size.indd 10
TIP!
From the side, check that this
part of the bracket is completely flat
against the Zumi board.
2
long plug
standoffs
Mounting
bracket
1
thick silver
bolt
