Summary of Contents for Robolink Zumi

  • Page 1 Build + Quick Start Guide...
  • Page 2: Parts List

    Parts List Hardware & Electrical Components Jumper wire microSD Card Zümi shell Fasteners Tools Raspberry Pi Zero OLED screen Zümi board Long plug standoff x2 Motor screws x6 Long socket standoff x3 Thick silver screws x10 Battery Velcro PiCam ribbon cable Mounting bracket Short plug standoff x2 Thin silver screws x6...
  • Page 3 Building Zümi Add standoffs to the chassis Zümi has to be assembled before she comes to life. Help put Long socket standoff her together by following these steps. Thick silver screws Attach motors Motors Chassis Motor screws Make sure the arms of the motors are on the inside of the chassis arms...
  • Page 4 Attach the velcro and battery Connect only the motor wires Battery 180° Right motor Velcro flip upside down Battery Left motor Add standoffs to the Zümi board Zümi board CAUTION Make sure to plug in the battery Short plug standoff just yet because i t may damage the board i f you turn i t on too earl y .
  • Page 5: Attach The Mounting Bracket

    Flip the Zümi board on top of the chassis Add standoffs to the Zümi board Long plug standoff Attach the mounting bracket Mounting bracket Flip i t over like a book cover! Thick silver screw Make sure to line up the four lights wi t h the chassis holes...
  • Page 6 Insert the ribbon cable into the Attach the Pi Camera to the Pi Camera latch mounting bracket Mounting screws Pi Camera The PiCam is PiCam Ribbon attached to the lower two holes Open Close of the mounting bracket In order to attach the Ribbon Cable to the Pi Camera, you need to open the latch, insert the cable, then close the latch Connect the Pi Camera to the Pi Zero, and attach it to the Zümi...
  • Page 7 Add standoffs Like step 9, insert the Short socket standoffs PiCam ribbon cable into the latch of the Raspberry Pi. Make sure to close i t ! Insert the jumper wire into the OLED screen, then mount it to the bracket OLED screen Jumper wire Make sure the pins line up wi t h...
  • Page 8 Plug the battery wire into the Zümi board Plug the jumper wire into the four-pin socket on the Zümi Board CAUTION Make sure to connect or disconnect components when 180° Zümi is on. It can damage some parts. turn to the Be sure the swi t ch is other side in the OFF posi t ion...
  • Page 9 Attach the shell Add the wheels Wheel Zümi shell Motor screws Thick silver screws Thin silver screws thick screws thin screws...
  • Page 10: Powering And Charging

    Powering and Charging Zümi has to be in the off posi t ion to charge. You can swi t ch her on to check the battery percentage and then boot up. Charging Zümi Plug Zümi in while the switch is in the OFF position (‘O’) to charge her battery.
  • Page 11 Getting Zümi Online Make sure to get Zümi online so she can get the latest updates! After Zümi boots up, she’ll tell you her name. You will need a computer with WiFi. You can access her If you don't see Zümi's name, try turning your device's dashboard once you connect to her WiFi signal.
  • Page 12 Support If you have technical questions, feedback, or other concerns, join us in the community at: forum.robolink.com We’re checking it daily!
  • Page 13 www.robolink.com...
