- Page 1 Wall transmitter Rojaflex WSTR-5 For Rojaflex radio tubular motors and radio receivers ORIGINAL ASSEMBLY AND OPERATING INSTRUCTIONS Eine aktuelle Vollversion der Anleitung finden Sie hier/ Original Montageanleitung Manuale d’uso originale You can find a current full version of the manual here/...
-
Page 2: Table Of Contents
Herewith declares Schoenberger Germany Enterprises GmbH & Co. KG, Hohenschäftlarn, that the radio system type rojaflex handheld transmitter "WSTR-5" complies with the directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following Internet address: www.rojaflex.com/konformitaetserklaerungen.html... -
Page 3: General Safety Instructions
Observe the instructions and safety receivers. instructions of the drive/receiver controlled by the radio control as well as the corresponding instructions of the driven roller shutter or sun protection system! www.rojaflex.com... - Page 4 Never use defective or damaged the end of their useful equipment. life and must not be disposed of together • Check the motor controlled by the with normal household waste. radio control and the power cable of the motor for integrity. www.rojaflex.com...
- Page 5 This applies in particular to information and environment. telecommunications technology devices such as computers and smartphones. In your own interest, please note that each end user is responsible for deleting the data on the old devices to be disposed of! www.rojaflex.com...
-
Page 6: Function Overview / Changing The Battery
One-way/two- cumen- way commu- nication 5-channel wall transmitter WSTR-5 Wall transmitter - back side The K1 and K2 keys can be used to switch between the individual channels (1-5). The channel highlighted in black is active in each case. As soon as the “a” (after channel display 5) is highlighted, group control is active. -
Page 7: Function Overview Display
Function overview display LCD - Anzeige The Rojaflex WSTR-5 wall transmitter has a multi-line display. The upper area shows the days of the week, the center of the display shows the time, the selected function (MANUAL / AUTO / AUTO with random function) as well as the status (UP/DOWN) and summer or winter time. -
Page 8: Technical Data / Scope Of Delivery
Range indoors: approx. 30 m * 5-channels Channels Compatibility Rojaflex radio motors and radio receivers Radio system Rolling Code Dimensions (approx.) (HxWxD) 50 mm × 50 mm × 14 mm * Range data are approximate values and depend on the structural conditions. -
Page 9: Programming And Settings
Programming and settings Programming mode - radio receiver or radio motor Set the receiver (external Rojaflex radio receiver or Rojaflex radio motor), on which the wall transmitter is to be programmed, to programming mode according to the associated instructions. Each keystroke must be executed within 4 seconds! Otherwise, the system automatically exits the programming mode. -
Page 10: Add Wall Transmitter / Delete Wall Transmitter
*The frequency of the beeps or the response of the motor / shutter depends on the receiver. Please refer to the corresponding instructions for the respective receiver/motor. For more information, please refer to the instructions of the Rojaflex radio tubular motors or radio receivers. -
Page 11: Activating And Deactivating The Timer Function
After approx. 5 seconds, the Automatic mode again. display changes from “MAN” After another approx. 5 to “AUTO”. seconds, the display changes Release the key. from “AUTO” to “AUTO with random function“. Release the key. Automatic mode with random function. www.rojaflex.com... -
Page 12: Setting The Current Time And Date
To confirm the year, press the The date display appears in Use the UP and DOWN keys After setting the month, press P2 programming key once. the display. to set the current month. the K2 key. The month display flashes. www.rojaflex.com... - Page 13 Use the UP and DOWN keys to set the current hour. the K2 key. to set the current minute. To confirm the set values (year/month/day/time), press the P2 programming key again. The programming of the time and date is completed, the settings are saved. www.rojaflex.com...
-
Page 14: Programming Of The Up And Down Times
Time programming options Use the UP and DOWN keys K2 key. are displayed. to select between the 3 different time programming After approx. 5 seconds, the options (see above - Time time programming options programming options). are displayed. Release the key. www.rojaflex.com... - Page 15 After you have set the time The display changes to the set the desired minute. you want for OPEN, press the programming of the AB time. P2 key. The hour display flashes. The set UP time for the dis- played day is saved. www.rojaflex.com...
- Page 16 Please note! The UP and DOWN travel times must be programmed separately for each channel! (select channel - switch to automatic mode - select time programming option - program UP time - program DOWN time - confirm with P2 etc.). www.rojaflex.com...
-
Page 17: Checking The Set Values
To exit the function, press the Stop key. For more information, please refer to the instructions of the Rojaflex radio tubular motors or radio receivers. www.rojaflex.com... -
Page 18: Notes
