Familiarization Guide
This guide is for experienced HP Response Center personnel, CEs,
and reseller technicians. That is, personnel who have already
completed the HP Vectra PC family training course, or equivalent,
and have at least six months of experience servicing the HP Vectra
PCs.
It is a self-paced training guide designed to train you to install,
configure, and repair the PC. You can follow it without having any
equipment available.
HP Vectra XU 6/xxx PC
and
HP Vectra VT 6/xxx PC
