- Page 1 GPL Series General Purpose Loudspeakers USER MANUAL GPL-5 & 5T GPL-8 & 8T GPL-12 & 12HQ GPL-15 & 15HQ GPL-28B GPL-115B GPL-118B GPL-218B www.wharfedalepro.com...
-
Page 2: Important Warnings & Safety Instructions
UNPACKING All Wharfedale Pro products are fully checked before leaving our factory. After unpacking please inspect the cabinets for any physical damage Please retain the shipping carton if possible and internal packing material incase the unit ever needs to be returned. Please check as soon as possible that the unit is functioning. - Page 3 GPL series is serious for fixed installation projects where audio quality matters. A unique characteristic of the GPL series is that all full range models feature an original design waveguide horn. This allows the high frequency range to be addressed directly to the audience and reduces unde- sired reflections.
-
Page 4: Product Features
Product Features GPL-5 & 5T GPL-8 & 8T • 70° conical coverage • 70° conical coverage • 200 W AES (Continuous) • 350 W AES (Continuous) • 400 W Programme • 700 W Programme • 800 W Peak • 1400 W Peak •... - Page 5 GPL Series Recommended systems GPL-28B Up to 4 x GPL-115B Up to 4 x GPL-118B Up to 8 x Up to 4 x GPL-218B GPL-5 GPL-8 GPL-12 GPL-15 GPL-12HQ GPL-15HQ...
- Page 6 GPL Series sound system example GPL-15/15HQ sound system example GPL-15HQ GPL-15HQ DP-4100N(F) Amplifier DP-4100N(F) Amplifier...
- Page 7 GPL Series sound system example Parallel Connection of Two GPL-8 Two Way Enclosures G G PL-8 GPL-8 GPL-8 GPL-8 DP-4065N(F) Amplifier DP-4065N(F) Amplifier...
- Page 8 GPL Series sound system example Two GPL-118B and Two GPL-12 sound system example GPL-12 GPL-12 GPL-118B GPL-118B DP-4100N(F) Amplifier DP-4100N(F) Amplifier...
- Page 9 GPL Series sound system example GPL-15/15HQ and GPL-218B sound system example GPL-15/15HQ GPL-15/15HQ GPL-15/15HQ GPL-15/15HQ GPL-218B GPL-218B DP-2200N(F) Amplifier DP-4100N(F) Amplifier DP-2200N(F) Amplifier DP-4100N(F) Amplifier...
- Page 10 GPL Series Connections Connecting the GPL Series to your system is easy. The rear panel includes two (2) parallel NL4 and a barrier strip connector. Run your speaker wires from your ampli er to the speaker; you can use either input connector. Use the correct gauge of stranded insulated speaker cable according to the power handling ability of your GPL Series cabinet.
- Page 11 GPL Series Connections GPL-5T and GPL-8T For Hi-Z systems the transformer models are tapped as follows…. GPL-5T 70 V : 120 / 60 / 30 / 15 W 100 V : 120 / 60 / 30 W GPL-8T 70 V : 200 / 100 / 50 / 25 W...
- Page 12 GPL Series Connections GPL-28B Discrete Mode NL-4 Wiring In DISCRETE mode for the GPL-28B. The NL-4 connector needs to be wired 1- / 1+ for one LF driver and 2- /2+ for the other LF driver. The amplifier needs to have either a 4 pole NL-4 output connector or a NL-4 "Y”...
- Page 13 GPL Series Connections GPL-28B GPL-115B/GPL-118B GPL-218B...
-
Page 14: Dimensional Drawings
Dimensional Drawings GPL-5 and GPL-5T 95.0 205.0 190.0 108.0 GPL-8 and GPL-8T 140.0 280.0 275.0 108.0... - Page 15 Dimensional Drawings 185.0 GPL-12 70.0 191.0 370.0 360.0 127.0 GPL-12HQ 185.0 70.0 191.0 370.0 360.0 127.0...
- Page 16 Dimensional Drawings GPL-15 225.0 70.0 203.0 420.00 450.0 127.0 GPL-15HQ 225.0 70.0 203.0 420.00 450.0 127.0...
- Page 17 Dimensional Drawings GPL-28B 47.0 740.0...
- Page 18 Dimensional Drawings 235.0 GPL-115B 47.0 470.0 280.0 GPL-118B 50.0 560.0...
- Page 19 Dimensional Drawings GPL-218B 1065.0...
- Page 20 GPL Series Response graphs GPL-5 and GPL-5T Note : Specification and graphs are created with the dedicated DSP presets.
- Page 21 GPL Series Response graphs GPL-8 and GPL-8T Note : Specification and graphs are created with the dedicated DSP presets.
- Page 22 GPL Series Response graphs GPL-12 Note : Specification and graphs are created with the dedicated DSP presets.
- Page 23 GPL Series Response graphs GPL-12HQ Note : Specification and graphs are created with the dedicated DSP presets.
- Page 24 GPL Series Response graphs GPL-15 Note : Specification and graphs are created with the dedicated DSP presets.
- Page 25 GPL Series Response graphs GPL-15HQ Note : Specification and graphs are created with the dedicated DSP presets.
- Page 26 GPL Series Response graphs GPL-28B Note : Specifications are created with the dedicated DSP presets.
- Page 27 GPL Series Response graphs GPL-115B Note : Specifications are created with the dedicated DSP presets.
- Page 28 GPL Series Response graphs GPL-118B Note : Specifications are created with the dedicated DSP presets.
- Page 29 GPL Series Response graphs GPL-218B Note : Specifications are created with the dedicated DSP presets.
-
Page 30: Polar Plots
Polar Plots GPL-5 and GPL-5T... - Page 31 Polar Plots GPL-8 ad GPL-8T...
- Page 32 Polar Plots GPL-12...
- Page 33 Polar Plots GPL-12HQ. Horizontal...
- Page 34 Polar Plots GPL-12HQ. Vertical...
- Page 35 Polar Plots GPL-15...
- Page 36 Polar Plots GPL-15HQ. Horizontal...
- Page 37 Polar Plots GPL-15HQ. Vertical...
-
Page 38: Specifications
Specifications Model Name GPL-5 / 5T GPL-8 / 8T System Type 5" coaxial passive 8" coaxial passive Configuration two-way two-way Frequency Response (+/-3 dB) 80 Hz - 20 KHz 65 Hz - 20 KHz DP-N / F preset Frequency Range (- 10 dB) 68 Hz - 25 KHz 53 Hz - 25 KHz DP-N / F preset... - Page 39 Specifications Model Name GPL-12 GPL-12HQ GPL-15 GPL-15HQ System Type 12" coaxial passive 12" coaxial passive 15" coaxial passive 15" coaxial passive Configuration two-way two-way two-way two-way Frequency Response (+/-3 dB) 55 Hz - 20 KHz 55 Hz - 20 KHz 42 Hz - 20 KHz 42 Hz - 20 KHz DP-N / F preset...
- Page 40 102 mm / 4" 102 mm / 4" LF Frame Material Aluminium Aluminium Aluminium Aluminium Driver brand Wharfedale Pro Wharfedale Pro Wharfedale Pro Wharfedale Pro Power System Continuous Power (W) 400 W Parallel / 200 W x 2 Discrete 1000...
-
Page 41: Installation Hardware
Installation Hardware Installations can be complicated enough, so Wharfedale Pro have made GPL series as easy as possible. GPL-5 (5T) and GPL-8 (8T) are quickly fixed to a wall using the optional WPB-3 wall bracket or with the included steel yoke. - Page 42 Wall Bracket And Yoke Dimensions 70.0 70.0 247.0 ISOMETRIC 251.0 40.0 GPL-5 and GPL-5T RIGHT LEFT FRONT 110.0 110.0 396.0 ISOMETRIC 40.0 402.0 GPL-8 and GPL-8T LEFT FRONT RIGHT...
- Page 43 Wall Bracket And Yoke Dimensions 160.0 160.0 494.0 502.0 50.0 ISOMETRIC GPL-12 & 12HQ FRONT LEFT RIGHT 598.0 ISOMETRIC 606.0 50.0 GPL-15 & 15HQ FRONT RIGHT LEFT...
- Page 44 Wall Bracket And Yoke Dimensions OPTIONAL WPB-1 PARTS AND SPECIFICATIONS WPB-1 ASSEMBLY...
- Page 45 Wall Bracket And Yoke Dimensions OPTIONAL WPB-3 PARTS AND SPECIFICATIONS WPB-3 ASSEMBLY...
- Page 46 Wharfedale Pro products are warranted of manufacturing or material defects for a period of three years from the original date of purchase. In the event of malfunction, contact your authorised Wharfedale Pro dealer or distributor for information. Please be aware that the warranty details may differ from country to country. Contact your dealer or distributor for information (available at www.wharfedalepro.com).
