Wharfedale Pro GPL-5T Quick Start Manual

Your full user manual can also be downloaded from
www.wharfedalepro.com
Product Features
GPL-5T
• 70° conical coverage
• 200 W AES (Continuous)
• 400 W Programme
• 800 W Peak
• 1.5" LF Voice coil
• 125 dB Max SPL @ 1 m
• 70 V / 100 V connections via barrier strip
Frequency Response (+/-3 dB)
Frequency Range (- 10 dB)
Sensitivity 2.83 V/1 m
Sensitivity 2.83 V/1 m half space
Calculated Maximum SPL @1 m
System Peak SPL*
*level at 1 m using pink noise with crest factor 4,
with dedicated pre-set.
System Rated Impedance
Low Frequency Transducer
LF Frame Material
High Frequency Transducer
Coil Size (mm / inches)
Exit Size (mm / inches)
Diaphragm Material
Nominal Coverage(HxV)
Special Features
System Continuous Power (W)
System Programme Power (W)
System Peak Power (W)
Transformer Taps (70 V)
Transformer Taps (100 V)
Crossover Frequency
Recommended HPF = BW18dB/oct.
Rigging & Hardware:
Enclosure Material and finish
Grille Material & Finish
Dimensions - Unpacked (mm / inches):
Dimensions - Packed (mm / inches):
Note : Specification and graphs are created with the dedicated DSP presets.
Model Name
System Type 5" coaxial passive
Configuration
DP-N / F preset
DP-N / F preset
Size
Voice coil size
HF Driver Type Compression Driver
Waveguide Type
Waterproof LF cone
Driver brand
Power
Transformer (T)
Input Connector 1 x Barrier Strip
2 x M10 threaded rigging points.
4 x M8 threaded points for WPB-3
Accessories:
GPL-5 horizontal flying yoke included
HANDLE
Enclosure
Cabinet Type
12 mm plywood
Colour Options Black paint, White on request
Powder coated steel
Height
Width Front
Width Rear
Depth
Height
Width Front
Width Rear
Depth
Weight
Net Weight 6.32 kg / 13.90 lbs
Gross Weight 6.90 kg / 15.18 lbs
GPL-5T GPL-8T
QUICK START GUIDE
GPL-8T
• 70° conical coverage
• 350 W AES (Continuous)
• 700 W Programme
• 1400 W Peak
• 2.5" LF Voice coil
• 128 dB Max SPL @ 1 m
• 70 V / 100 V connections via barrier strip
GPL-5T
two-way
80 Hz - 20 KHz
68 Hz - 25 KHz
96 dB
/
125 dB
131 dB
8 Ω
155 mm / 5''
38.1 mm / 1.5''
Aluminium
38.1 mm / 1.5"
25.4 / 1"
PM4
Spherical
70° conical
Beyma
200
400
800
100 V / 70 V
7.5,15,30,60 W
15,30,60 W
2.5 KHz
63 Hz
NO
Trapezoid
/ Rhino Rock
235 mm / 9.25"
190 mm / 7.5"
145 mm / 5.7"
205 mm / 8.1"
275 mm / 10.8"
250 mm / 9.8"
250 mm / 9.8"
265 mm / 10.4"
GPL-8T
8" coaxial passive
two-way
65 Hz - 20 KHz
53 Hz – 25 KHz
97 dB
/
128 dB
134 dB
8 Ω
211.5 mm / 8''
63.5 mm / 2.5"
Aluminium
Compression Driver
44.4 mm / 1.75"
25 / 1"
PM4
Spherical
70° conical
Waterproof LF cone
FEA optimized, Shared High performing Ferrite
magnet system design
Beyma
350
700
1400
100 V / 70 V
15,30,60,120 W
30,60,120 W
1.6 KHz
48 Hz
1 x Barrier Strip
2 x M10 threaded rigging points.
4 x M8 threaded points for WPB-3
GPL-8 horizontal flying yoke included
1 on back
Trapezoid
12 mm plywood
/ Rhino Rock
Black paint, White on request
Powder coated steel
388 mm / 15.3"
280 mm / 11.0"
180 mm / 7.1"
275 mm / 10.8"
448 mm / 17.6"
335 mm / 13.2"
335 mm / 13.2"
340 mm / 13.4"
12.28 kg / 27.02 lbs
13.32 kg / 29.30 lbs
