H2Tu-C-388 List 3E Standard Config Menu Options - ADC HiGain H2TU-C-388 Technical Practice

LTPH-TP-1001-02, Issue 2
Table 5 describes the Standard Config screen options and lists their front-panel display codes.
describes the ADC Config screen options and lists their front-panel display codes. Selections in bold type are the
factory default settings.
Front-panel
Standard Config
Display
Menu Options
Code
Loopback LBTO
Timeout
Loop Attenuation LATT
Threshold
Margin Threshold MARG
DS1 Frame FRMG
Formatting
DS1 Line Coding DS1
H2TU-C EQL
Equalization
See "H2TU-C
Equalization
(EQL) Option." on
page 22.
H2TU-R Line RLBO
Buildout
Alarm Pattern ALMP
See "Alarm
Pattern (ALMP)
Option." on
page 22.
H2TU-R TLOS TLOS
Loopback
Network NLBP
Loopback Pattern
H2TU-C-388 List 3E
Table 5. H2TU-C-388 List 3E Standard Config Menu Options
Selection Description
NONE Disables automatic time-out cancellation of all loopbacks.
20 Sets automatic cancellation of all loopbacks to 20 minutes after initiation.
60 Sets automatic cancellation of all loopbacks to 60 minutes after initiation.
120 Sets automatic cancellation of all loopbacks to 120 minutes after initiation.
0 through Determines the maximum loop attenuation before an alarm is declared. Zero
40 dB disables the alarm. The loop attenuation threshold can only be set through the
HiGain maintenance screens.
32 dB Default value.
0 to 15 dB Determines the minimum allowable margin below which a system alarm can
occur. Zero disables the alarm. The Margin (Alarm) Threshold can only be set
through the HiGain maintenance screens.
5 dB Default value.
AUTO Configures the HiGain HDSL2 system to operate in an auto-framing (AUTO)
mode. It detects and locks to both SF or ESF DS1 frame patterns. Line and
path performance parameters are maintained and displayed. Unframed
payloads will cause the ES-P and SES-P counters to increment.
UNFR Configures the same as AUTO except unframed payloads do not cause the
ES-P and SES-P counters to increment.
B8ZS Places both the H2TU-C and H2TU-R into their B8ZS modes.
AMI Places both the H2TU-C and H2TU-R into their AMI modes.
0 Sets the Equalizer to DSX-1 for 0 to 132 feet.
133 Sets the Equalizer to DSX-1 for 133 to 265 feet.
266 Sets the Equalizer to DSX-1 for 266 to 398 feet.
399 Sets the Equalizer to DSX-1 for 399 to 532 feet.
533 Sets the Equalizer to DSX-1 for 533 to 655 feet.
Sets the DS1 receive level output toward the Customer Interface (CI). H2TU-R
Line Buildout can only be set through the maintenance screens.
0 dB Sets the DS1 RLBO level toward the CI to 0 dB.
-7.5 dB Sets the DS1 RLBO level toward the CI to -7.5 dB.
-15.0 dB Sets the DS1 RLBO level toward the CI to -15.0 dB.
AIS Enables the HiGain HDSL2 system to output an AIS payload at its DS1 ports
for LOSW and LOS DS1. For priority resolution, see
LOS Enables the HiGain HDSL2 system to output an LOS condition at its DS1 ports
for LOSW and LOS DS1.
ENA Enables a logic loopback at the H2TU-R when an LOS occurs at its DS1 input,
if enabled at the H2TU-R. For priority resolution, see
DIS Disables Transmit Loss of Signal (TLOS) logic loopback.
AIS Enables the H2TU-R to transmit an AIS towards CI for any network loopback.
For priority resolution, see
LOS Enables the H2TU-R to transmit an LOS towards CI for any network loopback.
February 28, 2001
Table 6 on page 20
Figure 27 on page
Figure 27 on page
Figure 27 on page 48.
Provisioning
48.
48.
19
