- Page 1 COOLSTACK® Installation Manual Version 2022Mar_TW...
- Page 2 Electromagnetic Compatibility Directive (EMC) 2014/30/EU (EN 55015:2019/ EN 61547:2009/ EN IEC 61000-3-2:2019/ EN 61000-3-3:2013+A1:2019) CUL/UL 8800 Design Lights Consortium™ (DLC) Ver 5.0 General Ingress Protection Code (IP67) CoolStack® Installation Manual | Version 2022Mar_TW Page 1 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
-
Page 3: Table Of Contents
COOLSTACK® COMPACT Installation Procedures --On Trellis Precautions Maintenance, Environmental and Disposal =Page 19= Maintenance Use of cleaning agents, crop protection products and other chemicals Cleaning the COOLSTACK® products CoolStack® Installation Manual | Version 2022Mar_TW Page 2 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com... -
Page 4: Introduction
With over two hundred hectares of installed lamps in greenhouses and grow rooms, the COOLSTACK® became the reference for LED top lights in Europe and gained the trust of many leading growers around the world. CoolStack® Installation Manual | Version 2022Mar_TW Page 3 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com... -
Page 5: Order Contents
250V with PE L, N, PE 96.031.4053.1 96.032.4053.1 Light Grey 250V with PE L, N, PE 96.031.4053.0 96.032.4053.0 Leaves green 250/400V with PE 1, 2, PE 96.031.4055.7 96.032.4055.7 CoolStack® Installation Manual | Version 2022Mar_TW Page 4 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com... - Page 6 250V with PE L, N, PE 96.031.4053.1 96.032.4053.1 Light Grey 250V with PE L, N, PE 96.031.4053.0 96.032.4053.0 Leaves green 250/400V with PE 1, 2, PE 96.031.4055.7 96.032.4055.7 CoolStack® Installation Manual | Version 2022Mar_TW Page 5 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 7 250V with PE L, N, PE 96.031.4053.1 96.032.4053.1 Light Grey 250V with PE L, N, PE 96.031.4053.0 96.032.4053.0 Leaves Green 250/400V with PE 1, 2, PE 96.031.4055.7 96.032.4055.7 CoolStack® Installation Manual | Version 2022Mar_TW Page 6 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
-
Page 8: Symbols Used On The Product
Recycling of materials contributes to the conservation of natural resources. Therefore, do not discard your old electrical and electronic equipment via the domestic waste. All components are RoHS compliant products. CoolStack® Installation Manual | Version 2022Mar_TW Page 7 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com... -
Page 9: Specifications
-20°C to 35°C / 95% RH Condition Cooling Passive Passive Passive Ingress Protection IP67 IP67 IP67 Physical Lamp Dimension 1120x170x209.5 1120x170x209.5 635x170x209.5 Net Weight 15.6kg 15.6kg 8.9kg (Driver included) CoolStack® Installation Manual | Version 2022Mar_TW Page 8 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com... - Page 10 Lamp above pathway Lamp near wall DC Input Connector Lighting area Lighting area Pathway Pointing to crop Pointing to pathway / wall COOLVIEW® HCP Lens Lighting Scenario CoolStack® Installation Manual | Version 2022Mar_TW Page 9 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 11 Tighten the connector by turning the lock clockwise. Install Install the driver beside the lamp with self tapping screws. Properly position it before fixing it on the c-profile bar. CoolStack® Installation Manual | Version 2022Mar_TW Page 10 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 12 630mm) to the mains supply. When the connector clockwise. lamp is foreseen from the CoolControls Mesh DO NOT twist the cable during locking as internal antenna, the lamp will blink. wiring might break. CoolStack® Installation Manual | Version 2022Mar_TW Page 11 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 13 The standard driver mounting plates support as well round as square V-bars with a size up to 75mm. If your V-bars excess these sizes, please contact us for customized hooks. CoolStack® Installation Manual | Version 2022Mar_TW Page 12 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 14 Tighten by turning the lock from the cable lamp is foreseen from the CoolControls Mesh connector clockwise. antenna, the lamp will blink. DO NOT twist the cable during locking as internal wiring might break. CoolStack® Installation Manual | Version 2022Mar_TW Page 13 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 15 Tighten the connector by turning the lock Install Install the driver beside the lamp with self clockwise. tapping screws. Properly position it before fixing it on the c-profile bar. CoolStack® Installation Manual | Version 2022Mar_TW Page 14 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 16 630mm) to the mains supply. When the connector clockwise. lamp is foreseen from the CoolControls Mesh DO NOT twist the cable during locking as internal antenna, the lamp will blink. wiring might break. CoolStack® Installation Manual | Version 2022Mar_TW Page 15 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 17 The standard driver mounting plates support as well round as square V-bars with a size up to 75mm. If your V-bars excess these sizes, please contact us for customized hooks. CoolStack® Installation Manual | Version 2022Mar_TW Page 16 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
- Page 18 630mm) to the mains supply. When the lamp is foreseen from the CoolControls Mesh DO NOT twist the cable during locking as internal antenna, the lamp will blink. wiring might break. CoolStack® Installation Manual | Version 2022Mar_TW Page 17 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com...
-
Page 19: Precautions
CoolStack® Installation Manual | Version 2022Mar_TW Page 18 EMAIL horti@mechatronix-europe.com EMAIL horti@mechatronix-asia.com www.horti-growlight.com... -
Page 20: Maintenance, Environmental And Disposal
Use of cleaning agents, crop protection products and other chemicals Mechatronix COOLSTACK® products are weatherproof engineered for high PPF daily usage. Anti-Reflection and anti-dust coating layer is applied onto your lens. Damages to the lens may affect the overall performance of the crop production.
