MANUAL SWING GATE Installation Procedure
Head Assembly
M12 x 40 Bolt
(x2)
M8 Bolt
M8 Washer
IP36_Installation Procedure - MSG5000 © Copyright 2016
M12 Washer
(x4)
M12 Nut
(x2)
M8 Nyloc Nut
M8 Washer
Brace
Assembled View
www.barriergroup.com.au
Exploded View
Rail
Wall Mount Assembly
M8 x 60mm Bolt
M8 x 25mm Bolt
MSGRK
M8 Nyloc Nut
(x2)
M8 Washer
(x4)
Advertisement
Table of Contents
Related Manuals for barrier MSG5000
Summary of Contents for barrier MSG5000
- Page 1 (x2) Wall Mount Assembly MSGRK M8 Nyloc Nut M8 Washer M8 x 60mm Bolt M8 x 25mm Bolt M8 Nyloc Nut M8 Bolt (x2) M8 Washer M8 Washer (x4) Brace Assembled View www.barriergroup.com.au IP36_Installation Procedure - MSG5000 © Copyright 2016...
- Page 2 1. The installer must ensure the desired mounting point for the gate is level, plumb and rigid. 2. Use fixings appropriate to the material into which they are being fixed (not included). 3. Check all parts are included. Contact Barrier Group immediately if you are missing a piece. www.barriergroup.com.au...
