  • Page 1 Stainless Steel LAM2400 LAM2402 Chimney Extractor User & Installation Guide...
  • Page 2 European Directive 2002/96/EC on Waste Electrical and Electronic Equipment. Contact your town hall or your retailer for the used appliance collection points closest to your home. We thank you doing your part to protect the environment. Page _ 2 www.howdens.com...
  • Page 3: Table Of Contents

    General Cleaning Grease Filters Carbon Filters Replacing the Lamps Installation Methods of extraction Extraction Via Ducting Extraction Via Recirculation Parts Identification Hanging your extractor Decorative Chimney Fitting Electrical Connections Technical specification Troubleshooting Your Guarantee Page _ 3 Exclusive to Howdens Joinery.co...
  • Page 4: Before Using The Extractor

    Make sure that fuse rating is compatible with the product. • Repair procedures must always be performed by qualified service agents. The manufacturer shall not be held responsible for damages arising from procedures carried out by unauthorised persons, which may also void the guarantee. • Page _ 4 www.howdens.com...
  • Page 5: General Information And Operation

    Recirculation vent Lower chimney section Fan and light controls Extractor body Grease filters Light Control panel layout Extractor Power off Extractor power level 1 Extractor power level 2 Extractor power level 3 Extractor Light on/off Page _ 5 Exclusive to Howdens Joinery.co...
  • Page 6: Care And Maintenance

    The intervals between changing the filter will depend entirely upon the amount of cooking you do, but on average they will last about 6 months. Please quote the part refrence number HJA2910 (pack of 2) when re-ordering. • To gain access to the carbon filters, first of all remove the grease filters as above. • Remove the old filters and install new charcoal filters by turning them gently Page _ 6 www.howdens.com...
  • Page 7: Replacing The Lamps

    The lamps on this appliance should only be used during operation of the cooker hood. They should not be left on permanently and used as a main lighting source. The extractor is for domestic use only. Page _ 7 Exclusive to Howdens Joinery.co...
  • Page 8: Installation

    Charcoal filters are not required if the extractor • Remove the grease filters is to be ducted out. • Align the carbon filters over the pins located on either side of the fan motor. • Turn the carbon gently, until you feel them click into postilion. • Replace the grease filters before the power supply it turned back on. Page _ 8 www.howdens.com...
  • Page 9: Parts Identification

    User manual LAM2400 LAM2402 PARTS IDENTIFICATION On opening your box you will find the extractor body, a two-piece telescopic decorative chimney, two fixing brackets, and ducting connector and reducer. Main Extractor Body 5mm Screw Lower Chimney Chimney Bracket Upper Chimney Outlet Reducer Page _ 9 Exclusive to Howdens Joinery.co...
  • Page 10: Hanging Your Extractor

    Mark and drill the holes required to mount the extractor body. • The principal securing point is the top keyhole slot; fix this screw first leaving approximately 5mm between the screw head and the wall. • With the help of an assistant, level and secure in position through the lower two holes tightening the upper screws as necessary. Wall Page _ 10 www.howdens.com 275 mm...
  • Page 11: Decorative Chimney Fitting

    DO NOT: Operate the extractor without the grease filters in position. 150mm. ( ** ) Please use rawl plugs and screws appropriate to the type of wall (not supplied) mm Minimum distance to worktop mm Recommended distance to worktop Page _ 11 Exclusive to Howdens Joinery.co...
  • Page 12: Electrical Connections

    ‘N’ or coloured BLACK. The wire which is coloured brown must be connected to the terminal which is marked with the letter ‘L’ or coloured RED. Blue. Brown. (Neutral) (Live) LOAD Green / Yellow. SUPPLY (Earth) LOAD FUSE 250V~ SUPPLY Fig 3. Fig 4. Page _ 12 www.howdens.com...
  • Page 13: Technical Specification

    Authorized Service Agent. Never try to repair a nonfunctional product yourself. Technical specification TECHNICAL INFORMATION General Total power consumption 206W Fuse Voltage /Frequency 220-240 V ~ 50 Hz Cable type / section 0.75mm², 2 core or equivalent Cable length max. 1.3m E14 28W each Lamps Page _ 13 Exclusive to Howdens Joinery.co...
  • Page 14: Your Guarantee

    What to do if you need to report a problem- Please ensure you have ready: • The product’s model & serial numbers • Howdens Proof of Purchase document • Your full contact details Call the Service Line on 0845 00 60 006 Page _ 14...
  • Page 15 User manual LAM2400 LAM2402 Notes Page _ 15 Exclusive to Howdens Joinery.co...
  • Page 16 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
