Summary of Contents for Howdens HJA2231
- Page 1 60cm Integrated Extractor HJA2231 HJA2241 User & Installation Guide...
- Page 2 European Directive 2002/96/EC on Waste Electrical and Electronic Equipment. Contact your town hall or your retailer for the used appliance collection points closest to your home. We thank you doing your part to protect the environment. Page _ 2 www.howdens.com...
-
Page 3: Table Of Contents
User manual HJA2231 / HJA2241 Index Before using the extractor Safety General Fire Saftey Safety for children Safety when working with electricity General information & operation Extractor layout Control panel layout Using Your Cooker Hood General Cleaning Care and maintenance... -
Page 4: Before Using The Extractor
Development Department. • Never use the product when your judgment or coordination is impaired by the use of alcohol and/or drugs. • Product must be disconnected from the mains during installation, maintenance, cleaning and repair procedures. Page _ 4 www.howdens.com... -
Page 5: Fire Saftey
User manual HJA2231 / HJA2241 Fire Safety Do not set your cooker hood less than 700mm above your cooker. When installing the hood, ensure that the following recommended distances are observed • When installed between adjoining wall between the highest point on the hob top... -
Page 6: General Information & Operation
Cabinet door / facia Light Air Intake Control panel Control panel layout Light off Extraction off 1. 2. 4. 5. Light on Extraction level low Motor n neon indicator Extraction level medium Extraction lavel high 1. 2. 4. 5. Page _ 6 www.howdens.com... -
Page 7: Using Your Cooker Hood
User manual HJA2231 / HJA2241 Using Your Cooker Hood This process must be followed before the cooker hood is used for the first time.You should clean the appliance using a damp new cloth and warm soapy water before using the appliance for the first time. You should then dry it thoroughly using a soft cloth. Make sure that it has been installed by a suitably qualified person, as per the installation instructions. To use your cooker hood •... -
Page 8: Care And Maintenance
Rinse it off thoroughly with hot water. Repeat the process if required. Refit the grease filter once it has dried. Close the front cover. You should wipe over the front panel with a damp cloth and hot soapy water, then dry it thoroughly with a soft cloth. Page _ 8 www.howdens.com... -
Page 9: Carbon Filters
User manual HJA2231 / HJA2241 The Carbon Filters Replacing the Lamps If the appliance is going to be used in recirculation The extractor hood is fitted with lamps that may mode then it is necessary to fit carbon filters. This need to be replaced periodically. will help to absorb odours caused by cooking. To do this, ensure that the power is switched off and Carbon filters have a limited life. We advise you... -
Page 10: Installation
Charcoal filters are not required if the extractor • Remove the grease filters is to be ducted out. • Align the carbon filters over the pins located on either side of the fan motor. • Turn the carbon gently, until you feel them click into postilion. • Replace the grease filters before the power supply it turned back on. Page _ 10 www.howdens.com... -
Page 11: Before Beginging Instalation
User manual HJA2231 / HJA2241 Before beginning installation Installing your cooker hood • Check that the product purchased is of a You will have to decide before installing your suitable size for the chosen installation area. cooker hood whether to use it in extraction mode In addition check whether there is an electrical or recirculation mode. -
Page 12: Connecting To Exturnal Ducting
If there is a gap between the rear of the cooker hood 90 degree bend. and the rear wall. There is a spacer provided that can be cut to the size of the gap and attached to the rear of the cooker hood. Page _ 12 www.howdens.com... -
Page 13: Electrical Connections
User manual HJA2231 / HJA2241 Electrical Connections IMPORTANT: Ensure that the electricity supply is switched off before connecting. Your Extractor is intended for permanent installation. Your appliance must be connected to fixed wring via the use of a double pole switched fused spur outlet with at least 3mm contact separation, The isolation switch must be accessible after installation. (See technical data for fuse rating). -
Page 14: Technical Specification
270mm Height (canopy): 380 mm Your Cooker Hood is fitted with: Single / Twin motor Slider control operation Slider control operation 3 Speeds (HJA2231) (HJA2241) 1 lamp (28w E14 halogen) 2 lamps (28w E14 halogen) 1 Aluminium grease filter 1 Aluminium grease filter Extraction capacity: 220 m³/hr Extraction capacity: 360 m³/hr Noise level min/max: 43 –... -
Page 15: Troubleshooting
User manual HJA2231 / HJA2241 Troubleshooting TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions • A replacement lamp is probably Disconnect the mains electricity supply before Lamps fail to operate? necessary, but first check that adjusting or replacing the lamps. the lamp is correctly fitted into its holder. The extractor lamps may become hot; therefore... -
Page 16: Your Guarantee
What to do if you need to report a problem- Please ensure you have ready: • The product’s model & serial numbers • Howdens Proof of Purchase document • Your full contact details Call the Service Line on 0845 00 60 006 Page _ 16... - Page 17 User manual HJA2231 / HJA2241 Notes Exclusive to Howdens Joinery.co Page _ 17...
- Page 18 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
