Lumens CaptureVision Station LC100 User Manual

Hide thumbs Also See for CaptureVision Station LC100:
Table of Contents

Advertisement

Quick Links

Download this manual
LC100
CaptureVision Station
User Manual - English
[Important]
To download the latest versions of the Quick Start
Guide, multilingual user manual, software, driver,
etc., please visit Lumens
https://www.MyLumens.com/support
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CaptureVision Station LC100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens CaptureVision Station LC100

Summary of Contents for Lumens CaptureVision Station LC100

  • Page 1 LC100 CaptureVision Station User Manual - English [Important] To download the latest versions of the Quick Start Guide, multilingual user manual, software, driver, etc., please visit Lumens https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Package Contents ..............3 Chapter 2 Product Overview ..............4 2.1 RS-232/RS-485 I/O pin description ..............5 Chapter 3 Instruction for installation ............. 6 3.1 Product connection diagram ................. 6 3.2 Live Streaming Application Diagram ............. 6 Chapter 4 Function Description .............

  • Page 3: Chapter 1 Package Contents

    Chapter 1 Package Contents 3-PIN to 2-PIN LC100 Power Adapter Power Cord connector Appearance may vary (For Japan only) depending on country/ region Quick Installation RS-232/RS-485 Mounting Metal Plate Mounting sheet metal Guide Connector (x2) (x2) screws (M3 x 6 x 4) Hard drive locking Cable holder-1 Cable holder-2...

  • Page 4: Chapter 2 Product Overview

    Chapter 2 Product Overview The LC100 CaptureVision Station uses the Linux operating system and an ARM architecture processor to provide stable recording services. It supports video recording, mixing and switching from various input signal sources. It enables voice, image, and data in bidirectional transmission through the public network and support pre-scheduled recording and uploading.

  • Page 5: Rs-232/Rs-485 I/O Pin Description

    2.1 RS-232/RS-485 I/O pin description  RS-232 Pin NO. Function  RS-485 Pin NO. Function T/R+ T/R -...

  • Page 6: Chapter 3 Instruction For Installation

    Chapter 3 Instruction for installation 3.1 Product connection diagram 3.2 Live Streaming Application Diagram...

  • Page 7: Chapter 4 Function Description

    Chapter 4 Function Description 4.1 LCM Screen 4.1.1 Setting Menu 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values IP/ FW/ Mode/ Display the current system Information SN/ MAC information 1. HDMI1 or HDMI2 2. SDI1 or SDI2 3.

  • Page 8: Real-Time Operation Menu

    1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Shows the remaining space and Remaining space total space 4.1.2 Message Description Item Message Description USB Disk Insert USB flash drive or USB HD is inserted into LC100 USB Disk Remove USB flash drive or USB HD is removed from LC100 No Storage...

  • Page 9: Parameter Setting

    4.3 Parameter setting This Section provides descriptions of the web-based interface to control the display items. HDMI MultiView only provides items of [System Settings] and [Video Settings]. 4.3.1 System Settings 4.3.1.1 System Settings You may set up the device’s basic information, initial date and time, and others here. Item Function Descriptions Device...
  • Page 10 You can customize an intermission image for LC100 Click [Browse] and select a file to upload. Once done, a thumbnail will be generated File format: Intermission  File format: PNG Image  File Size (Max.): 3 MB  Resolution Size (Max.): 1920 x 1080 Click [Apply] to save this change.
  • Page 11 Main firmware information and update Select the master firmware file you want to update, and then click Main Firmware [Apply] to update it Engineering mode, for Lumens engineers only Saves system log files to user’s computer Enter file name Service History Click [Export] to export system log files <Remark>...
  • Page 12 4.3.1.4 Setting File You can export the configuration files of the device to a computer, and import the configuration files to another device to apply the same configuration. Item Function Descriptions Export Exports the current configuration of LC100 as a configuration file Import Imports the exported configuration files from a LC100 to another LC100 4.3.1.5 Display Settings...
  • Page 13 4.3.2 Account You can manage accounts for 3 kinds of user mode here: modify the user name and password to [System Management], [Director], and [Content Management]. Item Username/Password Function Descriptions System admin / admin Sets up the permission of main system management Management Online Manages playback and changes simple basic image...
  • Page 14 Function Descriptions Click [Refresh] and automatically scan the network cameras in the same LAN Click [Login Verification] and enter login information to connect the camera Login Verification Username: Lumens Network Network Camera Camera Password:  Account: admin  Password: 9999 Verific- ation Once the status display “OK”, indicating that the image can be set...
  • Page 15 4.3.3.2 Video communication source management Item Function Descriptions Display the video communication source information for users to edit the Video source name and order communication <Caution>ID1-4 are fixed as HDMI 1 / HDMI 2 / SDI 1 / SDI 2 (not source removable) management...
  • Page 16 connected to the front and rear USB port  Cycling Record: Enabling the cycle record function can prevent recording error when storage device is full  Audio Delay Adjustment: 0 ~ 600 ms  Audio source: Set the audio source for Channel recording files Audio Settings <Remark>...
  • Page 17  Real Time Streaming Protocol (RTSP): The default RTSP location for the customized LC100 real-time streaming path is: rtsp://LC100_IP_address:554/pgm Streaming Settings Streaming 1 Streaming 2 Streaming 3 Port: Verification RTSP URL: Factory Reset 4.3.5 Scene 4.3.5.1 Scene LC100 provides 5 overlay styles, 5 background images, and 5 scenes. You can also add your own styles.
  • Page 18 For background image setting, you can adjust the order by dragging the mouse left and right. Users can upload their own files for application. Click [ ] and select a desired file from the window. Check the preview image and file name, and click [Apply] to start uploading and Background Image applying this background image.
  • Page 19 Position Setting tracking <Remark> After checking the box, the Marco will proceed the setting of the network camera on Channel 1 ~ 2. 4.3.5.3 Time Stamp Item Function Descriptions Turn on/off Time Stamp Enable Time Stamp <Remark> When the Time Stamp function is enabled, other overlays cannot be applied Time display format Format...
  • Page 20 4.3.6 Storage Settings You can set up recording storage, cycle recording, and display hard drive information and NAS setting here. Item Function Descriptions Local storage: Click the drop-down menu and select SATA HDD or USB HD for the local storage hard drive Please refer to 2.
  • Page 21 You can synchronize schedules from network servers (e.g. Google Calendar) <Remark> Please refer to the videos of How to series on Lumens™ YouTube channel for related application settings Click [Stop] to stop the current scheduled recording Cancel Recording Stand by and Wake Enable/disable the scheduled standby and wake-up functions.
  • Page 22  Connection Test: Click [Connection Test] to test if a connection can be created with the current setting <Remark> Please refer to the videos of How to series on Lumens™ YouTube channel for related application settings 4.3.9 About LC100 Device-related Information: Firmware version, device serial number, and...

  • Page 23: Online Director

    4.4 Online Director LC100 is built in Director, which allows you to monitor recording and preview the output video from streaming director. Three login methods below are available:  Select online Director from the HDMI1 MultiView real-time operation menu  When login the web page, select the online Director icon at the upper right corner on the parameter setting page ...
  • Page 24 Online Director related feature description as below: Item Function Descriptions Channel Signal Drop down to select the image signal source Source Selection Start or stop recording; also select whether to synchronously stream or REC Record Setting Audio Source Manage the input and output audio sources; adjust the audio recording Management volume Scenes Layout...
  • Page 25 Hard Drive (USB) USB Device Operation Snapshot Invalid Fail Others 4.4.2 REC Record Setting Item Function Descriptions After checking the box, press recording button to start push and Recording while Push recording function Enable/Stop/Pause : Enable/Stop Recording Recording : Pause/Keep Recording Single-channel Push Push right away without starting recording function Button...
  • Page 26 4.4.4 Scenes Item Function Descriptions Scenes page is the integration of “Overlay,” “Background Image,” and Scenes “Recording Layout,” which can perform a series of scene change according to your needs. Layout Apply a different layout to highlight the screen focus of different channels.

  • Page 27: File Management

    4.5 File management LC100 provides file management feature which can perform the following functions via the file management interface: Upload, download, delete, replay video files and editing recording information. Item Function Descriptions Preview screen Click desired video files to play and control on the Preview screen Program screen Display the Director screen or switch to synchronize with the Preview screen Screen Switch...
  • Page 28  Video management ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ Item Function Descriptions Video Click to access the video management page management Photo Click to access the picture management page Management Click to access the system setting page <Note> System settings Log in the web page with admin/admin to display system setting subpage If you log in the web page with video/video, you will not find the system setting...
  • Page 29  File Management Description  Uploading Check the thumbnails of the videos to upload. Click [ ] and the videos will be uploaded to the location set in Upload Settings. Please refer to [System Management/Upload Settings] for related settings. Upload Status Description: Icon Upload Status Icon...
  • Page 30 Download Button Click this button to download the checked video files or datasets Apply Button After editing and modifying the video content, click this button to apply  Photo Management You can manage the photo files captured by pressing SNAPSHOT. Folders will be named with the shooting date automatically;...

  • Page 31: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting This chapter describes problems you may encounter while using LC100. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center. Problems Solutions Boot without power signal...

  • Page 32: Chapter 6 Safety Instructions

    Chapter 6 Safety Instructions Always follow these safety instructions when setting up and using the LC 100 CaptureVision Station: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table. 1.3 Please clean the dust on the power plug prior to usage.

  • Page 33: Addendum 1

    Addendum 1  Frequently used port No. Port No. Description Applicable for RTMP push to most platforms, such as YouTube, Vimeo, and 1935/TCP Twitch 80/TCP Applicable for RTMP push to Periscope 443/TCP Applicable for RTMPS push to Facebook 1935/TCP Applicable for RTMP push to LinkedIn 1936/TCP 2935/TCP Applicable for RTMPS push to LinkedIn...

  • Page 34: Copyright Information

    Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.

  • Page 35: Supplier's Declaration Of Conformity 47 Cfr § 2.1077 Compliance Information

    Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Manufacturer：Lumens Digital Optics Inc. Product Name：LC100 Model Number：CaptureVision Station Responsible Party – U.S. Contact Information Supplier：Lumens Integration, Inc. 4116 Clipper Court, Fremont, CA 94538, United States e-mail ：support@mylumens.com FCC Compliance Statement This device complies with Part 15 of the FCC Rules.
