2. INTRODUCTION
4-in-1 Air cooler, heater, air purifier and humidifier. Remote control and panel control. Large 12L water tank supplied with ice pack. Generates
negative ions to purify and sterilise output air. Hi-tech PTC heating element assures safer and rapid heating with two power options
(1000/2000W). Adjustable airflow direction. Three selectable fan speeds. Up to 12 hour timer. Easy to operate and move around on castors.
3. SPECIFICATION
Model No.: ............................................................ SAC41.V3
Cooler: ............................................................................80W
Cooling Water Tank: ......................................................... 12L
Heater: ...............................................................1000/2000W
Maximum Airflow: .....................................................485m³/hr
Supply: ...........................................................................230V
Maximum Flow Rate (F): ........................................ 7.5m³/min
Fan Power Input (P): .......................................................80W
Service Value (SV): .......................................0.09 (m³/min)/W
Standby Power Consumption (Psb): .............................0.0W
Fan Sound Power Level (Lwa): ................................. 65dB(A)
Maximum Air Velocity (c): ............................................. 10m/s
4. OPERATION
Ion
Cooler
Swing
Select either Cooling or Heating by use of the lever (Fig.1) on the side of the machine.
4.1.
Use the rocker switch on the rear of the unit to turn the power on.
4.1.1.
The LED display will light up and show the current ambient temperature.
4.1.2.
4.2.
ON/OFF
Pressing the ON/OFF button the unit will start the unit running in whichever mode you have selected (See below). Pressing the
4.2.1.
button a second time will cause the unit to stop working after approximately 30 seconds. The LED display will show the
current ambient temperature.
4.3.
COOLING MODE
The unit produces a cooling effect by evaporating water which is contained in a tank in the base of the unit. Before using as a
4.3.1.
cooler, the water tank must be filled. Ensure that the unit is unplugged from the mains supply before topping up with water.
Pull the tank from the unit and pour water into the tank. Check the level of water in the tank is between 'min' and 'max'. For an
4.3.2.
increased cooling effect, additionally place ice freezer blocks directly into the tank checking that the water level is still below
the maximum mark when immersed.
Press the On/Off button and machine will start running.
4.3.3.
4.3.4.
If Cooling is selected, the unit starts running and displays the low fan speed symbol
for Wind/Heat
When Cooling mode is selected, press Cooler button and the Cooling symbol will illuminate
4.3.5.
4.3.6.
In cooling mode, the fan speed can be adjusted using the Speed button. There are three speed settings and can be cycled
through by pressing the Speed button. Low speed is indicated by
The cooling effect has three settings, On
4.3.7.
Press the Wind/Heat button to cycle though the options.
4.4.
HEATING MODE
Press the On/Off button and machine will start running.
4.4.1.
4.4.2.
If Heating is selected, the unit starts running and displays a single power symbol indicating low power
medium fan speed symbol
To set the heating to use full power, press the Wind/Heat button and a second power will display alongside the first.
4.4.3.
NOTE: In Heating mode, the fan speed cannot be altered.
© Jack Sealey Limited
Wind
Timer
Heat
.
, intermittent (long interval)
.
Original Language Version
Speed
On/Off
, medium speed
Fig.1
and the low level indicator
.
, and high speed
and intermittent (short interval)
, and the
Issue 1
SAC41.V3
.
.
10/12/21
