Lemo REDEL 1P Assembly Instructions

Download this manual

Note: 1) Specified strip lengths are recommended values and may need to be adjusted to accommodate cable construction and

If you have any

questions or

require customer

assistance, please

at (800) 444-5366.

02/06

1/03

other variables unique to each application.

2) Some inserts with stepped, multi-row contacts may require shorter middle conductor lengths.

3) For potted assemblies, in addition to selecting a potting material that meets the requirements of the application

environment, the potting material must also be chemically compatible with the connector materials. Dependent upon the

specific part number, this could include PEI, PSU, ABS and/or PEEK. LEMO recommends LOCTITE ® M-31CL as a potting

material that is compatible with all LEMO Redel series materials.

4) Collet nut torque should not exceed recommended value. Optimal torque value depends upon cable construction.

5) All LEMO connectors with solder-style contacts are fully compatible with lead-free solder and the required higher

temperatures.

Please contact LEMO USA with any questions.

(800) 444-5366 • (707) 578-8811 • fax: (707) 578-0869

www.lemousa.com • e-mail: info@lemousa.com

LEMO USA, Inc.

635 Park Court, Rohnert Park, CA 94928

P.O. Box 2408, Rohnert Park, CA 94927-2408

Notes

Need help?

Do you have a question about the REDEL 1P and is the answer not in the manual?

Page 1 Dependent upon the specific part number, this could include PEI, PSU, ABS and/or PEEK. LEMO recommends LOCTITE ® M-31CL as a potting material that is compatible with all LEMO Redel series materials.
Page 2 Rosin core solder such as Kester SN63PB37 flux "44" and a non-corrosive solder flux such as GC Electronics, Part # 10-4216. For RoHS compliant assemblies, LEMO recom- assistance, please assistance, please mends flux core solder such as Kester #58/275 Lead-Free wire solder with no-clean flux and when required, a non-corrosive flux such as Kester 959T no-clean liquid flux.
Page 3 P.O. Box 2408, Rohnert Park, CA 94927-2408 (800) 444-5366 • (707) 578-8811 • fax: (707) 578-0869 (800) 444-5366 • (707) 578-8811 • fax: (707) 578-0869 02/06 www.lemousa.com • e-mail: info@lemousa.com www.lemousa.com • e-mail: info@lemousa.com ©2003 LEMO USA, Inc. 1/03 ©2003 LEMO USA, Inc. 1/03...
Page 4 Polysulfone Chemical Recommendations LEMO’s, 1P, 2P and 3P series REDEL connectors are manufactured with Polysulfone. Use of any chemicals not compatible with Polysulfone may cause serious damage to connectors. VTCS-6 Clear Vibra-Tite® or ThreeBond 1401 liquid thread-locker Application Place liquid thread-locker on the inside of the threads of the collet nut.
