- Page 1 Atim Cloud Wireless ® Water Leak Detection User guide Versions concerned: ACW/SF8-WL-I ACW/LW8-WL-I ACW/SF8-WL-O ACW/LW8-WL-O ACW/SF8-WLL-I ACW/LW8-WLL-I...
-
Page 2: Table Of Contents
UMMARY Historic of this document ..............................3 Disclaimer ..................................3 Trademarks and copyright ..............................3 Declaration of compliance ..............................4 Environmental recommendations ............................. 4 Explosive atmosphere Environment Radio Technical specifications ..............................6 Features Technical features Water Leak Sensor Mounting Identification Available versions ................................ - Page 3 ACW Configurator ................................16 Compatible versions Configuration ................................... 16 Frames format ................................. 18 Quick start Test frame ................................18 Alert frames ................................18 End of alert frames ..............................18 Full frames details Classic frame ................................19 Alert frame................................20 Keepalive frame ..............................21 Test frame ................................
-
Page 4: Historic Of This Document
Trademarks and copyright ATIM radiocommunications®, ACW ATIM Cloud Wireless® and ARM Advanced Radio Modem® are registered trademarks of ATIM SARL in France. The other trademarks mentioned in this document are the property of their respective owners. ATIM_ACW-WLL_UG_EN_V1.4... -
Page 5: Declaration Of Compliance
Declaration of compliance All ACW Atim Cloud Wireless® products comply with the regulatory requirements of the R&TTE Directive (1999/5/EC), article 3: 1 SAFETY (Article 3.1a of the 1999/5/EC Directive) NF EN60950-1 Ed. 2006/A1:2010/A11:2009/A12:2011 (health) EN62479: 2010 (power <20mW) or EN62311:2008 (power > 20mW) 2 Electromagnetic compatibilities (Article 3.1b of the 1999/5/EC Directive) -
Page 6: Radio
General hazard – Failure to follow the instructions presents a risk of equipment damage. Electrical hazard – Failure to follow the instructions presents a risk of electrocution and physical injury. Direct-current symbol WARNING: do not install this equipment near any source of heat or any source of humidity. WARNING: for your safety, it is essential that this equipment be switched off and disconnected from mains power before carrying out any technical operation on it. -
Page 7: Technical Specifications
Technical specifications a. Features INDOOR: ACW/xxx-WL(L)-I OUTDOOR: ACW/xxx-WLL-O Build-in alarm + Led + Buzzer (optional) IP68 enclosure + LED (no buzzer) Internal antenna External antenna (+4m wire) Leak detection using electrode or cable Leak detection using electrode or cable Leak localization (+/- 1m) using specific cables No leak localization Long life (up to 5 to 10 years) Long life (up to 5 to 10 years) -
Page 8: Water Leak Sensor
LoRaWAN ID Each product in the ATIM ACW range has a QR Code label visible either on the side or on the front of the product. This QR code can be easily read with any 2D barcode reader application on a smartphone. -
Page 9: Available Versions
Interpretation: ACW/LW8- ATIM 190114 5.11 70B3D59BA0008C0A WL-O Sigfox ID Date of Application Manufacturer Product Revision Manufactu Hardware manufactu firmware name reference number ring site version version DevEUI LoRaWAN Available versions a. Electrodes only In this version, the sensor can detect a leak just under itself like in this picture. -
Page 10: Localisation And Detection Cable
c. Localisation and detection cable Using this cable, you can locate the leak by measuring the distance between the device and the leak with a precision of +/- 1m. This cable is available in different lengths: 5m / 7m / 10m / 15m and can be connected to various accessories to monitor several rooms at the same time. -
Page 11: Cables Versions Summary
e. Cables versions summary Detection cable for ACW/WL CAB-WL [€/meter for cable] 3 meters cable for detection + localization CAB-WLL-3 5 meters cable for detection + localization CAB-WLL-5 7 meters cable for detection + localization CAB-WLL-7 15 meters cable for detection + localization CAB-WLL-15 Link cable between ACW/WLL and cable CAB-WLL-xx CAB-WL-LEAD... -
Page 12: Cable Setup
Cable setup Installation examples Jumper cables are unresponsive to water presence Be careful! Never loop a cable on itself nor create contact points with conductive material, it might lead to false- positives! ATIM_ACW-WLL_UG_EN_V1.4... - Page 13 ATIM_ACW-WLL_UG_EN_V1.4...
-
Page 14: Operation
Operation a. Operating modes - Exploitation mode: This is the standard mode when the devices start. In this mode the devices send radio frames in case of water leaks according to the configuration chosen. (If the device has never been configured, the factory settings are used. -
Page 15: Product Start-Up
5 minutes of the pairing phase, no network has been reached, then the product emits WHITE light signal and enters its nominal operating mode. Even if no network has been reached, it is assumed with this mode that an ATIM LoRa / LoRAWAN repeater located nearby will be able to ATIM_ACW-WLL_UG_EN_V1.4... -
Page 16: Emission Of A Test Frame
repeat the Local frames sent by the product in LoRAWAN frame on the network that the repeater will have joined. c. Emission of a test frame When the product is in its operating mode (and only in this mode), it is possible to send a test frame including a measurement sample (which avoids waiting for the next measurement frame). -
Page 17: Keepalive Frame
V5.2.2 or more LoRaWAN: V0.0.1 Téléchargez et installez le logiciel de configuration ‘’setupACW.exe‘’ à l’adresse : https://www.atim.com/en/products-configurator/ Configuration The configuration is done via USB or Bluetooth. In case of Bluetooth, the device must be restarted, this one should appear in the devices list on the main page of the configurator. Double click on it to open the ACW-WL related page. - Page 18 ⚫ Mode: Select the sensor used (Electrode or Cable) ⚫ Threshold: Set the sensors threshold for water detection. It must be set according received values in the test frames. If the devices trigger the alarm without real water leak. During the installation of the device, plunge the cable / electrodes into water to emulate a water leak and power on the device to send test frames.
- Page 19 Frames format a. Quick start Here are the most used frames when using the ACW-WLL. If more detail is needed, keep reading the next pages, Test frame Sent when the device starts, right after it joins the network: 0x854A0000xxxx With xxxx the measured value from the sensor.
- Page 20 Alert frame (threshold crossing); New generation: These frames combine a conventional frame and a measurement frame. They consist of a header warning that a threshold has been exceeded, followed by samples of each of the channels for which a threshold has been exceeded. Classic frame Byte 1 - Header Bit 7...
- Page 21 0x0c Reserved 0x0d Variable Alert frame followed by samples in alert. 0x0e General error 0x0f Variable ... Subframe for ACW. Depending on the ACW Alert frame If the Timestamp is enabled, 4 bytes with the Timestamp value will be preceded by the header (byte 1). Byte 1 - Header Bit7 Bit6...
- Page 22 The Measure Type is identical to the measure frame. The sample xxxx causing the alert is put at the end of the frame: Example: 0x8D4A0000xxxx Keepalive frame The life frame is sent at regular intervals according to the configuration applied (by default 4 days) and contains the battery levels of the product when empty (the product does nothing) and when charging (the product is transmitting a frame radio).
- Page 23 Byte 2 - Header 0x4A Bytes left: Measured value by the sensors during the test. On a test frame it must be close to 0 when using electrodes, or close to 0x6YY (YY = any value) when using a cable. Error frame If the Timestamp is enabled, 4 bytes with the Timestamp value will be preceded by the header (byte 1).
- Page 24 The number of samplings is too large or too small for the 0x84 ERR_NB_SAMPLE_OUT_OF_RANGE frame The number of the channel in the header of the frame is too 0x85 ERR_NWAY_OUT_OF_RANGE large or too small The type of measurement in the frame header is too large 0x86 ERR_TYPEWAY_OUT_OF_RANGE or too small...
- Page 25 Check if the device has been registered on the network (JOIN) • Check the network coverage • Check if the LEDs blinks when emitting data Technical support For any information or technical problems, you can contact our technical support: Technical support | ATIM ATIM_ACW-WLL_UG_EN_V1.4...
