The information contained in this document is subject to change without notice and does not represent a commitment on the part of ATIM. Trademarks and copyrights ATIM, ACW ATIM Cloud Wireless®, ARM Advanced Radio Modem® are registered trademarks of ATIM Sarl in France. Other trademarks mentioned in this document are the property of their respective owners. ATIM_ACW-LTEM_UG_EN_V1.0...
Declaration of conformity All ACW Atim Cloud Wireless® products comply with the regulatory requirements of R&TTE Directive 1999/5/EC Article 3 : 1 SAFETY (Article 3.1a of Directive 1999/5/EC) NF EN60950-1 Ed. 2006/A1:2010/A11:2009/A12:2011 (health) EN62479: 2010 (power <20mW) or EN62311:2008 (power > 20mW) 2 Electromagnetic compatibility (Article 3.1b of Directive 1999/5/EC)
Page 5
General danger :- If the instructions are not followed, there is a risk of damage to equipment. Electrical hazard : If the instructions are not followed, there is a risk of electric shock and personal injury. WARNING : do not install near sources of heat or moisture. WARNING : for your own safety, before carrying out any technical work on the equipment, it must be disconnected from the mains.
Technical data Product Dimensions 100 x 100 x 35 mm Antenna Integrated (patch type) 0°C to +50°C (Operation) Temperature 0°C to +30°C (storage) Mounting Wall IP 66** Power supply 2 x Lithium A batteries [ER18505M] [ER18505M Poids 220 g Frequency 800 –...
Product commissioning Sensor connection • If the LTE-M modem is supplied without a sensor, it can be connected to terminal block J2 on the circuit board. • The sensor cable must first be inserted into the housing via the cable gland. Ensure that the cable runs to the left of the terminal block, so as not to obstruct the passage of the battery when closing the housing.
1WIRE power supply 1wire data Connection examples LEFOO T3000 0-5V] [DIEHL IZAR] Pulse I water flow Temperature sensor [DS18B20 sensor 1wire] [DS18B20 1wire level sensor Operating mode If the magnet is held for more than 2 seconds on the location indicated by the QR code, the operating mode will change according to the order defined below : Magnet To find out the status of the product, simply pass a magnet briefly (<2 sec) over the above location, causing the LED to...
Once the mode has been changed, the modem processes an associated function. The LED then lights up continuously while the function is being processed, for example : • mode, the modem starts sending a life frame before going into standby mode until the next frame is sent (PSM for Power Sleep Mode).
Frame format When the modem is in mode, it operates in PSM (Power Sleep Mode), connecting to the network at regular intervals to send MQTT frames. Between two connections, the modem is in standby mode to minimize power consumption. The period between two transmissions (T3412) is adjustable. The graph below shows the consumption curve for three network connections : Blue areas represent data transmission periods, the most power-hungry periods (150mA average).
To enable connection to the broker, all MQTT identifiers and any TLS security certificates must be set up on the modem. Two integrations are currently available: 1. ATIM Cloud Wireless® platform 2. Live Objects platform. ATIM Cloud Wireless platform When ACW integration is selected, the life frame format is as follows: "IMEI":"861340040029330",...
The format of statement frames is as follows: Analog sensor "CNT":2, "MPERIOD":10, "TAB": 440,431,441,439,429,440,431,430,429,442,445,431,435,445,431,436,433,447, 435,441,436,445,433,440,433,430,435,431,438,440,441,431,432,443,429,434, 427,439,435,431,431,433,447,433,440,444,430,442,444,433,441,429,439,435, 437,440,444,437,427,432,432,440,441,437,439,445,432,444,431,429,433,447, 435,436,432,440,437,434,445,435,447,436,427,431,431,431,435,432,430,433, 439,439,432,448,446,439,435,430,445,433 Pulse sensor "CNT":2, "MPERIOD":10, "IDX":183, "TAB": 0,0,7,0,0,0,5,0,0,0,6,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 ATIM_ACW-LTEM_UG_EN_V1.0...
Page 14
DS18B20 temperature sensor "CNT":2, "MPERIOD":10, "IDX":183, "TAB": 18.2,17.5,17.6,17.6,17.5,17.5,17.5,17.5,17.4,17.4,17.5,17.5,17.4,17.4, 17.4,17.4,17.4,17.4,17.3,17.3,17.3,17.3,17.3,17.3,17.3,17.3,17.3,17.3, 17.3,17.3,17.3,17.3,17.3,17.3,17.3,17.3,17.3,17.4,17.3,17.4,17.4,17.4, 17.4,17.4,17.4,17.4,17.4,17.4,17.4,17.4,17.4,17.5,17.5,17.5,17.5,17.5, 17.5,17.5,17.5,17.5,17.5,17.5,17.5,17.5,17.5,17.5,17.6,17.6,17.6,17.6, 17.6,17.6,17.6,17.6,17.6,17.6,17.6,17.6,17.6,17.6,17.6,17.7,17.7,17.7, 17.7,17.7,17.7,17.8,17.8,17.8,17.8,17.8,17.8,17.8,17.8,17.8,17.8,17.8, 17.8,17.8 The CNT field is the frame counter, incremented each time a reading or life frame is sent. The MPERIOD field is the period between two measurements in minutes. The TAB table is filled in each time a measurement is taken.
Page 15
The first "Device" page of the ACW platform displays the latest readings: In addition, the top-left frame shows the latest RSRP, RSSI, SINR and battery voltage values. The second "Index Change" page displays raw frames in JSON format : ATIM_ACW-LTEM_UG_EN_V1.0...
Live Objects platform (Orange) When Liveojects integration is preferred, the format of life frames published in MQTT is as follows: "model":"atim-sample", "value": "IMEI":"861340040029330", “RSRP”:-115, “RSRQ”:-16, "RSSI":-66, "SINR":11, "VOLTAGE":3437, "FPERIOD":4, "MPERIOD":10, "CNT":1 An additional model parameter is then available to identify modems under Live Objects.
Configuration Modem functional parameters can be modified via Downlink from the ATIM Cloud Wireless or Live Objects platforms. On the other hand, MQTT identification and APN parameters require the use of the ATIM configurator. On both platforms, configuration changes will take effect the next time the modem sends a frame.
Page 18
On the Live Objects platform, it is also possible to edit the period for measuring and sending frames via the Commands menu (Downlink). To do this, fill in the fields as shown in the example below, where the requested sending period is 5 hours: ATIM_ACW-LTEM_UG_EN_V1.0...
Configurator When the ATIM configurator is launched, the program first checks the Internet connection in order to connect to the remote configuration server. If the connection with the server has been established, the identifiers of the modem to be configured (IMEI, etc.) can be entered before clicking on the download arrow.
