Basic Zone Configuration
OL-6109-01
Zone Configuration
This chapter describes zone configuration. It includes the following major
sections:
Basic Zone Configuration
•
Zone Remote Guard List
•
Zone Traffic Learning
•
•
Zone Detection
This section describes the initial Zone configuration procedures that relate to zone
parameters such as: zone name, description, and zone IP address.
It describes the following procedures:
Defining a New Zone
•
Duplicating a Zone
•
Removing a Zone
•
•
Removing All Zones
Displaying Zone Templates
•
Entering a Zone Command Level
•
Describing a Zone
•
Defining the Zone IP Address
•
