- Page 1 User Manual PowerGate PGA-М-1DE, PGA-М-4DE, PGS-3-2DE, PGS-5-2DE, PGS-3-4DE, PGS-5-4DE Version 2.00 November 11, 2020...
-
Page 2: Table Of Contents
PowerGate Contents Safe operation General information Installation Wireless network configuring Indication Web-settings Main settings Advanced settings Network settings Profiles Firmware update Technical maintenance Notes... -
Page 3: Safe Operation
PowerGate Safe operation Warning! To ensure safe and reliable operation of the devices, please observe The device uses hazardous the following requirements: voltage AC 100-230V Use the device only for its intended purpose; Do not use devices that show signs of malfunctioning; Avoid strong physical impacts on the device;... -
Page 4: Installation
PowerGate Installation Warning! 1. Visually inspect the device to make Before mounting and power up, it is sure that there are no transportation damages; necessary to verify protective earthing 2. Connect the first device in transmitter mode and cable connections. to DMX signal source, and the second device in receiver mode to DMX-controlled equipment;... -
Page 5: Web-Settings
PowerGate Web-settings PowerGate devices support configuring most of their parameters through the web-interface using HTTP protocol (TCP port 80). -
Page 6: Main Settings
PowerGate Main settings To access the settings page enter the IP-address of the device to the browser. Main settings page of the PowerGate device will be displayed. PowerGate PowerGate PowerGate Pic. 1 Main settings Indication – switching LED indication modes: Normal Indication depending on the current port status Рис. -
Page 7: Advanced Settings
PowerGate Advanced settings To edit the advanced settings of the device, click on the link “Advanced”. PowerGate Pic. 2 Advanced settings RDM devices – RDM devices list, connected to DMX ports: Start discovery Searching connected devices Refresh report Refresh search/list state detected devices... - Page 8 PowerGate DMX signal timing – sets the parameters of the output DMX signal for all ports: Break from 4 to 1000 µs from 4 to 1000 µs Data slots 1 to 512 Pause from 0 to 10000 µs DMX line terminator – enables (selected) or disables (cleared) termination resistor between D+ and D- wires of DMX line on each port.
-
Page 9: Network Settings
PowerGate Network settings To edit the network settings of the device, click on the link “Network”. PowerGate Pic. 3 Network settings MAC address Hardware address and secondary (permanent) IP-address of the device Main IP Set the main network address of the device Subnetwork mask Set the mask of the IP-subnet Gateway IP address... -
Page 10: Profiles
PowerGate Profiles For profile operations, click on the link «Profiles». Pic. 4 PowerGate Profiles settings Download current profile Download the current settings as a file Profile for uploading Select the file of previously saved profile Upload profile To upload the selected profile in the device Firmware update To update firmware of the device, click on the link «Firmware». -
Page 11: Technical Maintenance
The device should be free from dirt, dents, connecting cables and wires must be intact and securely fastened. Notes Please send all your warranty questions to www.sundrax.com All Sundrax Electronics products are covered by a 36-month warranty. Technical characteristics and appearance of the equipment of the Sundrax Electronics trademark can be changed without notice. - Page 12 Sundrax Electronics 6008, First Central 200 2 Lakeside Drive, Park Royal, London NW10 7FQ United Kingdom + 44 (0) 208 991 33 19 office@sundrax.com www.sundrax.com...
