- Page 1 RFL-P500H Pulsed Fiber LaserUser Guide Wuhan Raycus Fiber Laser Technologies Co., Ltd.
-
Page 2: Table Of Contents
Wuhan Raycus Fiber Laser Technologies Co., Ltd. Users Guide RFL-P500H TABLE OF CONTENTS 1 Safety Information ........................1 1.1 Security Warning ....................... 1 1.2 Laser Safety Grade ......................1 1.3 Safety Identification ......................2 1.4 Optical Safety ........................3 1.5 Electrical Safety ........................ 3 1.6 Other Safety Rules ...................... -
Page 3: Safety Information
User Guide of RFL-P500H 1 Safety Information Thank you for choosing Raycus fiber laser. This User Guide provides important safety, operation, warranty and other information. Please read it carefully before use this product. In order to ensure safe operation and optimal performance of the product, please follow the warnings, cautions, operating procedures and other instructions accordingly. -
Page 4: Safety Identification
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H 1.3 Safety Identification Figure 1 Safety identification position English Label（300W） English Label English Label Chinese Lable（300W） Chinese Lable Chinese Lable 3: Class 2M Laser Product 1: Laser Emit Head... -
Page 5: Optical Safety
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H 7: Electrical Hazard 1.4 Optical Safety Any dust on the end of the collimator assembly can burn the lens and damage the laser device. CAUTION: DO NOT emit when the protective cap is not removed, otherwise the lens or crystal will be damaged. -
Page 6: Product Description
Please refer to package accessoriesare in the packing box. 2.3 Unpacking and Inspection Raycus fiber laser is delivered in a package, which is designed to offer the maximal safety. Upon the delivery, please inspect all packaging for evidence of mishandling or damage. If you find any evidence of mishandling, please keep the... -
Page 7: Operation Environment
User Guide of RFL-P500H Please double check if each listed contents is inside the package; and contact Raycus as soon as possible if there is any issue. Take extra care when removing the unit from the package to make the fiber optic cable stay away from collision and vibration. -
Page 8: Attentions
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H e) Do not look into the output head directly. Wear appropriate protective eye glasses all the time when operating the laser. It is recommended to install the product in an environment with air conditioning. - Page 9 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H ≤10 Spectral Width RR=25kHz@30ns Pmax 5Hrs 后/RR=50kHz Output Power ≤5 Unstability P=Pmax RR=10kHz@100ns Pmax 90-100 RR=13kHz@70ns Pmax 65-75 Pulse length RR=15kHz@50ns Pmax 45-55 RR=25kHz@30ns Pmax 27-33 RR=45kHz@20ns Pmax 17-23 RR=50kHz P=100%～...
-
Page 10: Installation
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H Cooling Method Water Cooling 3 Installation 3.1 Dimensions Figure 2 shows dimensions of the product. Figure 2 Dimensions of 500W Product (unit:mm) -
Page 11: Cooling Requirements
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H The output head is IQB, the following figure 3 show the details of the IQB output head. Figure 3 IQB Output head (unit: mm) CAUTION: (1) Keep the protective cap properly, prevent it from contamination;... -
Page 12: Installation Rule
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H b) If ambient temperature is between -10℃ and 0℃, we recommend to use 30% alcohol(volume ratio), and replace it every 2 months. c) If ambient temperature is below -10℃, the chiller with both heating and cooling functions must be used, and keep it in full-time operation. - Page 13 Check the output head and clean it before installation. This procedure must be performed by Raycus personnel or person authorized by Raycus. f) Prevent the delivery cable from treading, pinching or excessive bending during installation.
-
Page 14: Using The Product
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H 4 Using the Product 4.1 Front Panel Figure 4 shows the front panel. Figure 4 Front Panel View 1. REM/OFF/ON: Key switch, the power switch of the laser. Insert the key and then turn the key clockwise to 'ON' to active the laser or turn anti-clockwise to ‘REM’... -
Page 15: Rear Panel
1. INPUT: The socket for power supply input that can be only mated with the plug on the power cord Raycus provided.The socket is provided with a protective cover and a lock catch. Please use the protective cover and lock catch when not use the laser device. -
Page 16: Power Connection
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H 4.3 Power Connection CAUTION: (1) Before connect the product to AC power, you must check up that the AC supply you will apply is in accordance with the specifications provided in Table 1. -
Page 17: Interface Definitions
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H 4.4 Interface Definitions 4.4.1 SERVICE Figure 7 SERVICE Definitions The pin definitions are shown in Table 4: Table 4 SERVICE Definitions Unit Definition Comments Remote key Equivalent to front panel KEY switch SWITCH. - Page 18 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H Figure 8 DB25 control interface The DB25 behind the power module is the interface between the control system (such as marking machine) and the laser system. Be sure to connect reliably before working.
- Page 19 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H actual laser power may not be strictly linear with the setting value). The relationship between PIN value and output power is shown in Table 6: Table 6 Definition of power control PIN value...
- Page 20 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H Figure 9 DB25 sequence diagram 1) T represent the initialization time of the laser machine. The initialization time is less than 10s from power-on to perform initialization. 2) T represent the pump recharge time, usually around 5ms.
- Page 21 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H Table 8 PIN Definition of Serial Communication Name Description The setting of the data bits synchronize with Serial input rising edge of the serial clock. Serial clock, frequency range: 10KHz～...
- Page 22 Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H binary coding of laser duration (for example: 100 is the decimal number of 0x0064, represents the setting pulse duration is 100ns). 5) Pin22 is the Enable signal. The Enable should achieve high state at least 10us before Pin2 and Pin3 changing.
-
Page 23: Rs-232 Serial Port
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H Control’ panel, follow that select ‘IPG_YLPM’, and then close this window. 3）Pulse duration can be modified by the ‘Duration’ on the right side of the window. If the setting duration is smaller than the limiting minimum value, the duration of output laser will be 20ns (minimum). -
Page 24: Application Steps Of Laser Device
Laser data transmitter Laser data reference Others Unconnected in suspension RS232 interface is a special interface for Raycus internal personnel debugging. 4.5 Application Steps of Laser Device 4.5.1 Pre-inspection a) Make sure the size and connection of water pipe are correct, mainly including water temperature, water flow rate, maximum input pressure, refrigeration capacity. -
Page 25: Operational Steps
Wuhan Raycus Fiber Laser Technologies Co., Ltd. User Guide of RFL-P500H d) Make sure the power supply and control signal of the laser are connected correctly. e) Make sure the emergency stop switch is loose. 4.5.2 Operational Steps a) Starting procedures... -
Page 26: Warranty, Return And Maintenance
The warranties start on the date of shipment from Raycus for a period of time as set forth in the applicable purchase contracts or product specifications. Raycus has the right to choose to repair or replace any product that proves to be defective in materials and workmanship selectively during the warranty period. -
Page 27: Limitations Of Warranty
Raycus. The customer has the responsibility to understand and follow this instruction to use the device. Any damage caused by fault operating is not warranted. - Page 28 All the items about warranty and service above provided by Raycus are for uses’reference; formal contents about warranty and service are subject to the contract.
