- Page 1 FRONT LOADING WASHING MACHINE OWNER’S MANUAL MODEL: TWD-BM105GF4S TWD-BM115GF4S TWD-BM135GF4S Read This Manual Read and follow the instructions carefully. Keep the operation instructions handy for future use .
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS Safety Instructions ..........INSTALLATION Product Description ..........Installation ............OPERATION Quick Start ............. Before Each Washing ..........Detergent Dispenser ..........Control Panel ............Programmes............Option..............MAINTENANCE Cleaning and Care ..........Trouble Shooting ............ Technical Specifications ......... Product Fiche ............ -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Safety Instructions Please read the following safety information thoroughly and follow it strictly to minimize the risk of fire or explosion, electric shock and to prevent property damage, personal injury or loss of life. Failing to follow these instructions shall void any warranty. ！... - Page 4 SAFETY INSTRUCTIONS •The appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 5: Installation
SAFETY INSTRUCTIONS •Do not operate the machine in rooms with a temperature of below 5°C. This can cause damages to parts of it. If it is unavoidable, make sure to drain the water completely from the appliance after every use (see „Maintenance - Cleaning of drain pump filter“) to avoid damages caused by frost. - Page 6 SAFETY INSTRUCTIONS •Water and electrical connections must be carried out by a qualified technician in accordance with the manufacturer‘s instructions and local safety regulations. ！ Warning! •Don´t use multiple plugs or extension cords. •The appliance must not have an external switching device such as a timer or connected to a circuit that is regularly switched on and off.
- Page 7 SAFETY INSTRUCTIONS OPERATION AND MAINTENANCE ！ Warning! •Never stop the washer dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat can dissipate. •The washer dryer is not to be used if industrial chemicals have been used for cleaning.
- Page 8 SAFETY INSTRUCTIONS •Always unplug the appliance and close the water tap before cleaning and maintenance and after each use. •Never pour water over the appliance for cleaning purpose. Risk of electric shock! •Repairs shall only be carried out by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Page 9 SAFETY INSTRUCTIONS Packaging/Old appliance This marking indicates that this product should not be disposed with other household wastes throughout the EU.To prevent possible harm to the environment or human health from uncontrolled waste disposal,recycle it responsibly to promote the sustainable reuse of material resources.To return your used device, please use the collection systems or contact the retailer where the product was purchased.
-
Page 10: Product Description
INSTALLATION Product Description Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Door Service flap Drain hose Note! • The product picture is for illustration only, please refer to real product as reference. Accessories 4 x Cover caps 1 x Owner’s manual 1 x Supply hose cold water... - Page 11 INSTALLATION Installation Installation area ！ Warning! · Stability is important to prevent the product from wandering! Make sure the machine is standing leveled and stable. • Make sure that the product does not stand onto the power cord. W> 20mm •...
- Page 12 INSTALLATION Remove transport bolts ！ Warning! • You must remove the transport bolts from the backside before using the product. Loosen the 4 Remove the bolts Close the holes using transport bolts with a including the rubber the cover caps. spanner.
- Page 13 INSTALLATION Drain Hose ！ ！ Warning! Warning! • Do not kink or protract the drain hose. • Position drain hose properly ,otherwise damage might result of water leakage. There are two ways to place the end of drain hose: 1. Put it into the water trough. 2.
-
Page 14: Operation
OPERATION Quick Start Caution! • Before washing, please make sure the washer dryer is installed properly. • Your appliance was thoroughly checked before it left the factory. To remove any residual water and to neutralize potential odors, it’s recommended to clean your appliance before first use. - Page 15 OPERATION 1. Before Washing earth terminal Main wash Softener Prewash Close door Plug in Open tap Load Add detergent Note! • Detergent need to be added in compartment I if the pre-wash function is selected. 2. Washing Select programme Select function or Power On Press remain default...
-
Page 16: Before Each Washing
OPERATION Before Each Washing • The ambient temperature of the washer dryer should be 5-40°C. If used under 0°C, the inlet valve and draining system may be damaged. If the machine is installed under freezing conditions, it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose can unfreeze before use. -
Page 17: Detergent Dispenser
OPERATION Detergent Dispenser Pre wash Main wash Softener Release button to pull out the dispenser Caution! • Detergent only need to be added in "compartment I “after selecting pre-wash function. Programme Programme Rinse & Spin Cotton Wool Baby Care ECO 40-60 Intensive ℃... -
Page 18: Control Panel
OPERATIONS Control Panel Model: TWD-BM105GF4S; TWD-BM115GF4S; TWD-BM135GF4S Note! • The chart is for reference only, Please refer to real product as standard. On/Off Start/Pause Product is switched on or off. Press the button to start or pause the washing cycle. -
Page 19: Programmes
OPERATION Programmes Model: TWD-BM105GF4S; TWD-BM115GF4S; TWD-BM135GF4S Programme Load(kg) Default Time 10.0 12.0 10.0 12.0 1:18 COTTON 10.0/7.0 12.0/8.0 3:47 GREATWAVES 10.0/7.0 12.0/8.0 1:10 5.0/5.0 6.0/6.0 0:55 ECO WASH 10.0 12.0 10.0 12.0 0:12 SPIN ONLY 1:18 DRUM CLEAN 10.0/7.0 12.0/7.0... - Page 20 OPERATION Programmes Programmes are available according to the laundry type. Programmes Hard-wearing textiles, heat-resistant textiles made of cotton or COTTON linen. Press [Temp.] and [Spin] 3sec. for my cycle to memory the MEMORY procedure. The default my cycle is cotton. Mixed load consisting of textiles made of cotton and synthetics.
- Page 21 Model: TWD-BM105GF4S; TWD-BM115GF4S; TWD-BM135GF4S Default spin speed in rpm 1400 COTTON 1000 GREATWAVES 1000 1000 ECO WASH SPIN ONLY – 1000 DRUM CLEAN MEMORY 1000 QUICK 12' cold TIME DRY – DRY ONLY – WOOL ANTI-ALLERGY...
- Page 22 OPERATION Option Delay Set the Delay function: 1. Select a programme; 2.Press the Delay button to choose the time(the delaying time is 0-24 H.) 3.Press [Start/Pause] to commence the delay operation Delay Choose the Programme Setting time Start Cancel the Delay function: Press the [Delay] button until the display be 0H.It should be pressed before starting the programme.
- Page 23 OPERATION Reload This operation can be executed during the washing progress. When the drum is still rolling and there is large amount of water with high temperature in the drum. The state is unsafe and the door cannot be opened forcefully. To press [Start/Pause] for 3 sec.
- Page 24 OPERATION Child Lock To avoid mis operation by children. Press [Delay] and [SpaCare] Delay SpaCare 3 sec. till buzzer beep. Caution! When child lock is activated and program starts, child lock indicator will switch on, and the CL and remaining time on the display are alternately displayed in 0.5s. Press the other buttons will make child lock indicator flash for 3s.
- Page 25 OPERATIONS Wi-Fi Touch the “Wi-Fi” for 3 seconds, the washing machine will be connected to the internet on your smartphone.The details of Wi-Fi connect , please check page 24.This is the Wi-Fi switch ,if you want make your appliance connect to the internet.You need turn on the “Wi-Fi”...
- Page 26 WiFi, otherwise, please login the router and change the SSID name. • If there is a large number of devices connecting with the WiFi router, the network stability might be affected. Toshiba is not obliged to advise you that how many devices you shall connect you’re your WiFi router, for it depends on router quality and many other factors.
-
Page 27: Maintenance
MAINTENANCE Cleaning and Care Warning! • Always unplug the appliance and close the water tap before cleaning and maintenance. Cleaning the Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. - Page 28 MAINTENANCE Cleaning the Inlet Filter Note! • Diminishing water flow is a sign that the filter need to be cleaned. 1. Close the tap and remove the water supply hose from it. 2. Clean the filter with a brush. 3. Unscrew the water supply hose from the backside of the machine.
- Page 29 MAINTENANCE Cleaning the Drain Pump Filter Warning! • Make sure that the machine has finished the washing cycle and is empty. Switch it off and unplug it before cleaning the drain pump filter. • Be careful of hot water. Allow the water to cool down. Risk of scalding! •...
-
Page 30: Trouble Shooting
MAINTENANCE Trouble Shooting Whenever there is a problem with the appliance, check if you can solve it following the tables below. If the problem persists, please contact the customer service. Description Possible cause Solution Appliance does Door is not closed properly. Close the door properly and not start restart. -
Page 31: Technical Specifications
The machine door cannot be used as a handle. Technical Specifications Power Supply 220-240V~,50Hz MAX.Current Standard Water Pressure 0.05MPa~1MPa Model Rated Power Dimension Net Weight Washing Capacity (W*D*Hmm) TWD-BM105GF4S 2000W 9.5kg 72kg 595*615*850 TWD-BM115GF4S 10.5kg 595*615*850 2000W 72kg 2000W 12.5kg 595*645*850... - Page 32 MAINTENANCE TWD-BM105GF4S TWD-BM115GF4S TWD-BM135GF4S 51. 9 66. 9 0.513 3.424 1350 1350 1350...
- Page 33 MAINTENANCE...
- Page 34 MAINTENANCE 1) The actual energy consumption will depend on how the appliance is used. 2) The actual water consumption will depend on how the appliance is used and on the hardness of the water. 3) Delivery of the spare parts within 15 working days after having received the order.
