Downee Keystone DPG300 Installation Instructions

GRAVITY
Latch
no-drill
install
START
The Latch comes ready
Left or
for Right-Handed gates. A
few simple steps and the
Right?
Latch is ready for
Left-Handed gates.
Viewed from
inside the Property
- Suits 50 - 125mm Posts
- Two-Way Access
- Lock-unlock from same side
- Exit when locked
from outside
Swap to Left-Handed
LEFT
DPG300
Spindle
Be careful to keep inner parts in place.
Remove base from Button Body.
RIGHT
Carefully remove spring, button clip and spindle.
Rotate mounting base, button clip, and spindle 180° then
reassemble.
Next step
is on
Repeat on Latch body.
the back
page.
GRAVITY
GRAVITY
Latch
Latch
no-drill
no-drill
install
install
- Suits 50 - 125mm Posts
- Two-Way Access
- Lock-unlock from same side
- Exit when locked
from outside
Button Body
Button (do not rotate)
Spring
- Suits 50 - 125mm Posts
- Two-Way Access
- Lock-unlock from same side
- Exit when locked
DPG300
from outside
Button clip
Mounting base
DPG30
Spin
31/08/16
