READYNAS
X6
version B
☼ ☼
Prepare for Installation
Please read this guide before you install disks into your ReadyNAS system. Prepare the
following for the disk installation:
ReadyNAS X6 Disk-less System
Disk drive brackets and screw in accessory box
Hard disk drives (not included)
Screw driver (not included)
ReadyNAS X6 allows you to start with one disk and add a second disk at a later time for
redundancy. You can then expand the data volume by adding a third disk to double the
capacity or a fourth disk to triple the capacity. This guide illustrates the steps of install-
ing four disks.
1
Remove the top cover to access disk cage
ReadyNAS X6 case (Version B)
2
Install the hard disk mounting brackets
the connector end
the components
side
Prepare SATA hard disk drives
Disk Installation Guide
Important instruction on how to install hard disks in your ReadyNAS
Remove the 3 screws in back.
4 x
16 x
Disk installation Accessories
Remove top cover
Install the bracket
to the new hard disk
the Components Side
F
F
Advertisement
Related Manuals for Infrant Technologies READYNAS X6
Summary of Contents for Infrant Technologies READYNAS X6
- Page 1 Hard disk drives (not included) Screw driver (not included) ReadyNAS X6 allows you to start with one disk and add a second disk at a later time for redundancy. You can then expand the data volume by adding a third disk to double the capacity or a fourth disk to triple the capacity.
- Page 2 © 2005 Infrant Technologies, Inc. All rights reserved. ReadyNAS, RAIDar, RAIDiator, X-RAID and FrontView are trademarks 3065 Skyway Ct., Fremont CA 94539 Phone: (510)4 38-7982 of Infrant Technologies, Inc. All other product names are the properties Email: support@infrant.com of their respective owner. Web: www.infrant.com Printed in U.S.A.
