  • Page 1 compass ® User Manual compass ®...
  • Page 2 In this user manual you will find information on the following products: Lower extremities: compass® 530 Ab-/Adduction compass® 530 Leg Extension/Curl compass® 530 Leg Extension compass® 530 Leg Curl...
  • Page 3 compass® 530 Leg Press compass® 530 Hip Extension compass® 530 Multi Hip...
  • Page 4 Hull: compass® 530 Lateral Flexion compass® 530 Trunk Extension/Flexion compass® 530 Trunk Extension compass® 530 Trunk Flexion...
  • Page 5 compass® 530 Trunk Rotation...
  • Page 6 Upper extremities: compass® 530 Chest Press/Rowing compass® 530 Chest Press compass® 530 Butterfly/Butterfly Reverse compass® 530 Rowing...
  • Page 7 compass® 530 Pulldown/Dip compass® 530 Pulldown compass® 530 Dip...

  • Page 8: Foreword

    Dear Customer, We would like to thank you for your confidence that you have chosen products of proxomed Medizintechnik GmbH with your purchase and that you share and support our vision of a healthy society. We are pleased that our devices are in therapeutic use with you and support many patients in their rehabilitation.

  • Page 9: Table Of Contents

    Table of contents Foreword ............................ 8 Legend ............................13 Safety instructions ..............................13 Safety instructions ........................14 Marking on the device .............................. 14 Applied symbols for transport ..........................15 Liability notice ................................16 Intended use ................................. 16 Indications and contraindications ........................17 Patient target group ..............................
  • Page 10 compass 530 Leg Extension ..........................28 ® Intended use ............................... 28 Indications ................................28 Specific patient positioning .......................... 28 compass 530 Leg Curl ............................29 ® Intended use ............................... 29 Indications ................................29 Specific patient positioning .......................... 30 compass 530 Leg Press ............................31 ®...
  • Page 11 Specific patient positioning .......................... 39 compass ® 530 Trunk Flexion ..........................39 Intended use ............................... 39 Indication ................................40 Specific patient positioning .......................... 40 compass ® 530 Trunk Rotation ..........................41 Intended use ............................... 41 Indication ................................41 Specific patient positioning .......................... 41 Device descriptions Upper extremities .................
  • Page 12 Indications ................................49 Specific patient positioning .......................... 49 compass 530 Dip ..............................50 ® Intended use ............................... 50 Indication ................................50 Specific patient positioning .......................... 50 General training settings ......................52 Maintenance, cleaning, servicing, disposal ................54 Accessories ..........................56 Technical data..........................

  • Page 13: Legend

    Legend These operating instructions are part of the product and must be kept safe and accessible throughout the entire service life. In the event of a change of ownership, the operating instructions must be handed over to the new owner. If supplements to these operating instructions are supplied, they must be added to the document.

  • Page 14: Safety Instructions

    Safety instructions Marking on the device Figure Description Reference Observe operating instructions EN ISO 15223-1 Manufacturer, name, address, year EN ISO 15223-1 manufacture CE Mark EU 2017/ 745 Serial number EN ISO 15223-1 Unique Device Identification EU 2017/ 745 Medical Device Multi-year inspection sticker EN 62353 Next test date...

  • Page 15: Applied Symbols For Transport

    Follow instructions ISO 15223-1 Is additionally attached to devices with electr. components Applied symbols for transport Figure Description Reference TOP - top here DO NOT stack Protect from moisture Temperature range ISO 15223-1 Humidity ISO 15223-1...

  • Page 16: Liability Notice

    Liability notice The device has been built according to the current state of the art and recognized safety regulations. Nevertheless, inadmissible misuse may result in hazards to persons and the device. No design or development changes may be made to the device. The installation of additional components or the removal of components is not permitted.

  • Page 17: Indications And Contraindications

    Indications and contraindications The indications for the use of the devices in therapy are shown in chapter 7 of the respective device. The devices are contraindicated and must not be used for the conditions listed below: • Febrile diseases • Current pain at rest or during activity, as well as acute health complaints •...

  • Page 18: Usage Note Butterfly/Butterfly Reverse

    ® 530 devices can be optionally equipped with the smart assist accessory. smart assist is an active medical device from proxomed Medizintechnik GmbH that contains software. smart assist was developed and tested according to EN 60601-1. 3.13 Side effects and residual risks The devices are developed in such a way that no critical side effects can occur.

  • Page 19: Incident Reporting

    3.14 Incident reporting Please report any clinical events that occurred during and immediately after use of the device directly to the manufacturer at the address: vigilance@proxomed.com...

  • Page 20: Storage, Transport And Installation

    The devices are usually delivered completely assembled. In rare cases, it may be necessary to ship the units partially disassembled for transport reasons. In these cases, please use the corresponding assembly instructions at the service service@proxomed.com and follow the instructions given there! ●...
  • Page 21 In general, make sure that the distance of at least 60 cm (starting from Movement ● the movement dimension) to other devices is maintained during dimension installation. However, the safety clearances may overlap. Area until next device Active Training area The device must be set up on a level, impact-resistant surface that can withstand the load of the device and the maximum permissible body weight of the user of 200 kg.

  • Page 22: Commissioning

    Commissioning Before each start-up, check that the training device is in perfect technical condition.  Locking bolt on function, the locking button must engage automatically.  Protective cladding - present or damaged.  Screw connections - check for tight connection. ...

  • Page 23: Training Tips

    Training tips The device must be adjusted to the ergonomic conditions of the user before the first training. The adjustment of the training device for the user is the responsibility of the qualified personnel. CAUTION Improper or excessive training can lead to health problems. To prevent injuries and make training more effective, a general and special warm-up program •...
  • Page 24 Different training methods are used. If training is done according to the repetition method, • several series of exercises are performed with appropriate breaks. The load intensity is based on the load capacity of the individual indications, the rehabilitation • phase and the treatment goal.

  • Page 25: Device Descriptions Lower Extremities

    Device descriptions Lower extremities ® compass 530 Ab-/Adduction Intended use compass 530 Ab-/Adductor is designed for muscular stabilization of the abducting or approaching ® leg muscles. Indications Sarcopenia of the leg muscles • Nonspecific lower back pain • Postoperative rehabilitation after hip arthroplasty •...

  • Page 26: Compass ® 530 Leg Extension/Curl

    surfaces are brought into the desired starting position, i.e. outward for adduction movement, inward for abduction. The starting position is adjusted individually according to the patient's mobility. The adjustment is possible in 10° steps, which are set by the release lever (yellow) to the left of the user (latching position).

  • Page 27: Indications

    Indications Sarcopenia of the leg muscles • Osteoporosis in early stages (grade 0 and 1) • Postoperative therapy after hip arthroplasty • Specific patient positioning The patient sits on the seat and leans against the backrest. The seat is now moved backwards or forwards, depending on the length of the thigh, until the axis of rotation of the training device coincides with the axis of movement of the knee joint (imaginary line through the two femoral condyles) with full contact with the backrest and the lumbar cushion (optional).

  • Page 28: Compass ® 530 Leg Extension

    compass ® 530 Leg Extension Intended use compass ® 530 Leg Extension is designed for muscular stabilization of leg extensor muscles. Indications Sarcopenia of the leg muscles • Osteoporosis (grade 0 and 1) • Postoperative rehabilitation after hip arthroplasty • Hip joint arthrosis •...

  • Page 29: Compass ® 530 Leg Curl

    The length of the lever arm depends on one hand on the length of the lower leg and on the other hand on the load-bearing capacity of the injured structures. Thus, the lower leg pad is usually located just above the malleolus fork of the ankle joint (distal lever attachment). A gentler training method results from shortening the lever by bringing the pad closer to the knee joint (proximal lever approach).

  • Page 30: Specific Patient Positioning

    Specific patient positioning The patient sits on the seat and leans against the backrest. The seat is now moved backwards or forwards, depending on the length of the thigh, until the axis of rotation of the training device coincides with the axis of movement of the knee joint (imaginary line through the two femoral condyles) with full contact with the backrest and the lumbar cushion (optional).

  • Page 31: Compass ® 530 Leg Press

    compass ® 530 Leg Press Intended use compass ® 530 Leg Press is designed for muscular stabilization of the leg extensor muscles. Indications Sarcopenia of the leg extensor muscles • Osteoporosis in early stages (grade 0 and 1) • Hip joint arthrosis •...

  • Page 32: Compass ® 530 Hip Extension

    The adjustable foot plate allows for a variety of exercise options. The range of motion (starting and end position) can be precisely defined and limited for limited knee and hip joint mobility in extension and/or flexion. For this purpose, the distance between the seat/lying surface and the footplate is fixed by means of locking bolts, taking into account the movement restriction.

  • Page 33: Indications

    Indications Sarcopenia • Osteoporosis in early stages (grade 0 and 1) • Nonspecific lower spine pain • Specific patient positioning The training is done in a standing position. The knee joint of the respective standing leg should be slightly bent. The height of the arm rest pad is adjusted so that the upper body is in a slightly inclined position during the workout.

  • Page 34: Indications

    Indications Sarcopenia • Osteoporosis in early stages (grade 0 and 1) • Nonspecific pain in the lower spine • Specific patient positioning The starting position is in standing position, the knee joint of the standing leg should be slightly bent. The height of the foot plate is adjusted by a spindle so that the axis of rotation of the hip joint coincides with the axis of rotation of the device.
  • Page 35 CAUTION Before adjusting the height of the footplate, always check the setting of the lever arm pad to prevent the footplate from hitting the pad!

  • Page 36: Device Descriptions Hull

    Device descriptions Hull ® compass 530 Lateral Flexion Intended use compass 530 Lateral Flexion is designed for muscular stabilization of the sagittal trunk muscles. ® Indication Sarcopenia of the trunk muscles • Osteoporosis in early stages (grade 0 and 1) •...

  • Page 37: Compass ® 530 Trunk Extension/Flexion

    compass ® 530 Trunk Extension/Flexion Intended use compass ® 530 Trunk Extension/Flexion is designed for muscular stabilization of the dorsal side of the trunk (back muscles) and for stabilization of the ventral side of the trunk (abdominal muscles). Indication Sarcopenia of the trunk muscles •...

  • Page 38: Compass ® 530 Trunk Extension

    height after loosening the locking screw. For the extension movement, the upper edge of the pad should be flush with the spinae scapulae; for the flexion movement, it should sit just below the clavicles. To set the initial position, actuate the pushbutton of the guide rod on the cam disk, bring the lever arm into the desired position and let the bolt snap back into place there by releasing the pushbutton.

  • Page 39: Specific Patient Positioning

    Specific patient positioning Training is performed in the closed system, i.e. the feet are placed on the adjustable footplate, which can be adjusted according to body size and desired starting position. For this purpose, the turning/locking handle is loosened by turning it to the left (counterclockwise) by half a turn, and by pulling the knob, the footrest can be adjusted.

  • Page 40: Indication

    Indication Sarcopenia of the trunk muscles • Osteopenia of the spine • Osteoporosis in early stages (grade 0 and 1) • Nonspecific pain of the lumbar spine • Specific patient positioning Training is performed in the closed system, i.e. the feet are placed on the adjustable footplate, which can be adjusted according to body size and desired starting position.

  • Page 41: Compass ® 530 Trunk Rotation

    compass ® 530 Trunk Rotation Intended use compass ® 530 Trunk Rotation is designed for muscular stabilization of trunk rotators. Indication Sarcopenia of the trunk muscles • Scoliosis • Specific patient positioning The patient sitting upright on the seat cushion. Adjust the lateral stabilization aids to the patient. To do this, loosen the turning handles by turning them to the left (half turn) and adjust the supports.
  • Page 42 an upright position. However, you can also adjust the height accordingly with the help of the rotation/locking bolt. To do this, turn the knob counterclockwise to disengage the pivot/locking pin and pull the knob to adjust the height of the entire unit. Then snap the knob back into place and fix it by turning it to the right.

  • Page 43: Device Descriptions Upper Extremities

    Device descriptions Upper extremities ® compass 530 Chest Press/Rowing Intended use compass 530 Chest Press/Rowing is designed for muscular stabilization of the anterior, upper trunk ® muscles. Indication Sarcopenia of the trunk muscles • Shoulder blade instability • Osteoporosis in early stages (grade 0 and 1) •...

  • Page 44: Compass ® 530 Chest Press

    The Range of Motion Limiter (optional) for the end position is located above the weight block and is adjusted by loosening the fastening screw. Depending on the start position of the machine arms, both a rowing pull and a chest press movement can be performed.

  • Page 45: Compass ® 530 Butterfly/Butterfly Reverse

    adjusted according to the patient's size. By pressing the footrest/entry aid forward with the foot, the lever arms with the handles are brought into a comfortable starting position. For this purpose, the weight block is lifted and the changes to the weights, including the fine graduation (optional), must no longer be made.

  • Page 46: Specific Patient Positioning

    Specific patient positioning The seat height can be individually adjusted according to the patient's size The seat with the gas pressure spring can be adjusted by actuating the release underneath the seat. The patient is positioned so that he or she reaches 90° of flexion at the knee and hip joints and the feet are in contact with the floor. This angle may differ for very small and very tall persons.

  • Page 47: Compass ® 530 Rowing

    compass ® 530 Rowing Intended use compass ® 530 Rowing is designed for muscular stabilization of the anterior, upper trunk muscles. Indication Sarcopenia of the trunk muscles • Shoulder blade instability • Osteoporosis in early stages (grade 0 and 1) •...

  • Page 48: Compass ® 530 Pulldown/Dip

    The movements can also be performed alternately, in which case only half of the weight is moved (pulley principle). compass ® 530 Pulldown/Dip Intended use compass 530 Pulldown/Dip is designed for muscular stabilization of the upper chest, dorsal upper arm ®...

  • Page 49: Compass ® 530 Pulldown

    The spine should be in contact with the backrest during the entire exercise. The freely movable Lumbar Cushion (optional) is individually adjusted according to the patient's size. Care should be taken during exercise to ensure that the cervical spine remains in the neutral position and the head is not taken forward.

  • Page 50: Compass ® 530 Dip

    The starting position - height adjustment of the handles - is set via the adjustment lever (yellow) on the left side of the user. The adjustment is made in steps and snaps every 10°. The spine should be in contact with the backrest during the entire exercise. The freely movable Lumbar Cushion (optional) is individually adjusted according to the patient's size.
  • Page 51 she achieves approx. 90° flexion at the knee and hip joints and the feet are in contact with the floor. This angle may differ for very small and very large persons. The starting position - height adjustment of the handles - is set via the adjustment lever (yellow) on the left side of the user.

  • Page 52: General Training Settings

    10 General training settings Weight settings 5kg Main weights max. 100 kg max. 20 weights à 5 kg Additional weights optional 4 kg 4 weights à 1 kg CAUTION No external weights may be attached to the devices! Weight settings 10kg Main weights max.
  • Page 53 Additional weights optional 8 kg 4 weights à 2 kg CAUTION No external weights may be attached to the devices! Range of Motion Limiter optional Up to 100 cm stepless...

  • Page 54: Maintenance, Cleaning, Servicing, Disposal

    11 Maintenance, cleaning, servicing, disposal CAUTION The devices are subject to an annual safety and functional test (maintenance) in accordance with §7 of the Medical Devices Operator Ordinance "Maintenance of Medical Devices". With the optional "smart assist ISO" accessory, a metrological test (MTP) is performed at 2-year intervals in accordance with the manufacturer's specifications.
  • Page 55 The authorized service will help you quickly and competently. You will find the "Repair order/ malfunction report" form in the enclosed medical device booklet. Create an error message and send it by mail (service@proxomed.com) or use our servicehelper form (see chap. 12 Fehler! Verweisquelle konnte nicht gefunden werden.).

  • Page 56: Accessories

    12 Accessories smart assist Item no. 10629100 Support during movement execution. Connection to proxotrain software for training planning, training control and training documentation. smart assist ISO Item no. 10629200 Support during movement execution. Connection to proxotrain software for training planning, training control and training documentation including isometric measurement function.
  • Page 57 Additional Weight Increments 4 x 1 kg Item no. 10181600 The Additional Weight Increments are intended for the targeted adjustment/dosing of the training weight. The adjustment is possible in two variants. 4 x 1 kg (5 kg weight stack) Additional Weight Increments 4 x 2 kg Item no.

  • Page 58: Technical Data

    13 Technical data 13.1 Lower extremities Movement Device Patient Training Adjustable size Isometricload dimension weight weight weight Depth x width maximum Depth x width x maximum maximum maximum x height in cm height in cm (Standard) compass 530 Ab-/Adduction ® 80 kg 300 kg 250 kg...

  • Page 59: Hull

    13.2 Hull Movement Device Patient Training Isometricloa Adjustable size dimension weight weight weight Depth x width x Depth x width x maximum maximum maximum maximum height in cm height in cm (Standard) compass 530 Lateral Flexion ® 80 kg 150 kg 250 kg 1.500 N 144 x 99 x 166...

  • Page 60: Upper Extremities

    13.3 Upper extremities Movement Device Patient Training Adjustable size Isometricload dimension weight weight weight Depth x width x maximum Depth x width x maximum maximum maximum height in cm height in cm (Standard) compass 530 Chest Press/Rowing ® 300 kg 250 kg 80 kg 152 x 155 x 166...
  • Page 61 Ambient conditions operation Temperature +5° to +45° Celsius Humidity < 65% Transport and storage Temperature -10° to +45° Celsius Humidity < 65% Requirements Medical Device Directive 93/ 42/ EEC Product life 7 years as medical device Stationary training equipment EN ISO 20957-1, ISO 20957-2 Use class according to ISO 20957-1 Risk classification 93/ 42/ EEC...

  • Page 62: Warranty

    It is the customer's responsibility to ensure the functionality of the device by replacing the wear parts at an early stage if the intervals for safety checks specified by proxomed are not adhered to or if no maintenance contract has been concluded with proxomed.
  • Page 63 All illustrations in these instructions for use are only approximate for typographical reasons; we accept no liability for typographical errors. Errors excepted. Operating Instructions compass 530, Version 02, 2022-10-04...
