ELECTRIC LIFT FRYERS
CONTENTS
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
Page
6
Page
9
Page
10
Page
11
Page
15
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLS.ODFE.010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GGM gastro PLS.ODFE.010

Summary of Contents for GGM gastro PLS.ODFE.010

  • Page 1: Table Of Contents

    ELECTRIC LIFT FRYERS CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    ELECTRIC LIFT FRYERS GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    ELECTRIC LIFT FRYERS PRODUCT DESCRIPTION *The Professional Electric Fryers ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) PLS.ODFE.010 400x900x850 95 kg 460x990x1030 PLS.ODFE.020 800x900x850 TECHNICAL INFORMATION Cable Power...

  • Page 4: A3 Transportation

    ELECTRIC LIFT FRYERS TRANSPORTATION *This appliance can be moved by hand from area to area.Do not crash and drop the appliance while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    ELECTRIC LIFT FRYERS SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials.  *Do not operate the appliance when the machine is empty. *Do not load so less or more than appliance’s capacity.

  • Page 6: Doperation

    ELECTRIC LIFT FRYERS OPERATION *Control Panel: Clicking this button will completely turn off the fryer and return 01. FRYER ON / OFF the fryer baskets to their starting position. 02. FRYER START / By clicking this button, the selected fryer basket goes down to the frying position and the frying time starts counting, if it is STOP already browning...
  • Page 7 ELECTRIC LIFT FRYERS 6. LEFT FRYER The left fryer basket is shown as in the picture when it is not frying, if the basket is clicked, the BASKET white basket turns red and it is understood that it has been selected, if it is clicked again, the selection is canceled and the basket turns white.
  • Page 8 ELECTRIC LIFT FRYERS If the right basket shaking time has expired, an animation like in the photo is shown on the screen, click on it to close this warning. When the left fryer basket starts to fry, the time set here starts to 08.

  • Page 9: Ecleaning & Maintenance

    ELECTRIC LIFT FRYERS CLEANING & MAINTENANCE  CLEANING AND MAINTENANCE AFTER EVERY USE  Always turn off the appliance and disconnect from the power supply before cleaning.  Clean the outer surface of the appliance with a wet cloth and chrome shiner. ...

  • Page 10: Ftroubleshooting

    ELECTRIC LIFT FRYERS TROUBLESHOOTING Check if the appliance is plugged in. THE APPLIANCE DOESN’T Check the electrical connections and voltage. OPERATE Check the resistances. Check the level of oil. THE APPLIANCE DOESN’T Check the thermostat switch.If the oil can not be FRY WELL heated as desired,contact with authorized service.

  • Page 11: Gspare Part List-Exploding Drawing

    ELECTRIC LIFT FRYERS SPARE PART LIST-EXPLODING DRAWING PLS.ODFE.010...
  • Page 12 ELECTRIC LIFT FRYERS SPARE PART LIST-EXPLODING DRAWING ÜRÜN KODU: PLS.ODFE.010 ÜRÜN ADI ÜRÜN KODU TOP COVER HANDLE Y.PLS.ODFE.010.001 TOP COVER Y.PLS.ODFE.010.002 BASKET Y.PLS.ODFE.010.003 BASKET SHAFT Y.PLS.ODFE.010.004 BASKET LOWER SHEETMETAL Y.PLS.ODFE.010.005 RESISTANCE HOLDER SHEETMETAL FRONT Y.PLS.ODFE.010.006 RESISTANCE HOLDER SHEETMETAL REAR Y.PLS.ODFE.010.007 RESISTANCE Y.PLS.ODFE.010.008...

  • Page 13: Helectric Circuit Schema

    ELECTRIC LIFT FRYERS ELECTRIC CIRCUIT SCHEMA ATTENTION: If a 12 VDC input is installed on the rail card, this card can only be operated with a communication cable. There is no need to enter separate supply to both the front card and the relay card. In this case, if the communication cable is disconnected, the front card is de-energized.
  • Page 14 ELECTRIC LIFT FRYERS ELECTRIC CIRCUIT SCHEMA LOWER CARD REPLACEMENT AC IN REPL UPPER CARD COMMUNICATION CABLE LEFT DRIVER RIGHT DRIVER...
