Compaq Evo D300V Supplementary Manual

Compaq Evo Desktop D300v
Illustrated Parts Map
Compaq Evo Desktop Family of Personal Computers
Microtower Models, Celeron and Pentium III Processors
s
b
System Unit
* Access Panel, Types 1 & 2 chassis
1 Access Panel, Type 3 chassis
2 Chassis assembly, Type 1, for all Celeron 800 MHz
to 1.1 GHz and all P3 processors
3 Chassis assembly, Type 2, for Celeron 1.1 and 1.2
GHz processors
4 Front bezel with bezel blank, Types 1 & 2 chassis
5 Front bezel with bezel blank, Type 3 chassis
6 Chassis assembly, Type 3, for Celeron 1.2 and 1.3
GHz processors, with front I/O connector
7 Power supply, PFC, 145W, Types 1 & 2 chassis
* Power supply, 145W, Types 1 & 2 chassis
* Power supply, PFC, 200W, Type 3 chassis
* Power supply, 200W, Type 3 chassis
* Not shown
Mass Storage Devices
1 20-GB Hard drive, 5400 RPM
2 48X CD-ROM drive
3 Diskette drive, 3.5-inch
Documentation and Packaging (not illustrated)
Service Reference Guide
Quick Troubleshooting Guide
Illustrated Parts Map
Return kit
© 2002 Compaq Information Technologies Group, L.P.
Compaq, the Compaq logo, and Evo are trademarks of
Compaq Information Technologies Group, L.P.
Intel, Pentium, and Celeron are trademarks of Intel
Corporation in the United States and other countries.
All other product names mentioned herein may be
trademarks of their respective companies.
Compaq shall not be liable for technical or editorial errors
or omissions contained herein. The information in this
document is provided "as is" without warranty of any kind
and is subject to change without notice. The warranties for
Compaq products are set forth in the express limited
warranty statements accompanying such products. Nothing
herein should be construed as constituting an additional
Cables
ATA 66 Cables for Type 1 chassis
1 Diskette drive cable (143218-0002), 180 mm long
2 CD-ROM/hard drive data cable, 350 mm long
3 Audio cable, 360 mm long
4 LED Power Switch Assembly
ATA 100 Cables for Types 2 & 3 chassis
257659-001 * Diskette drive cable, 150 mm long
* CD-ROM drive data cable, 280 mm long
Not spared
* Hard drive cable, 240 mm long
Not spared
* Audio cable, 330 mm long
Not spared
* LED Power Switch Assembly
251617-001 *Not shown
280560-001
Not spared
251625-001
251626-001
280568-001
280569-001
Standard and Optional Boards
1 System board, Type 1 Chassis (see System Unit)
* System board, Types 2 & 3 Chassis (see System
Unit)
2 Memory module, 64 MB
* Memory module, 128 MB
Intel Processor with heatsink
* Celeron, 800 MHz, Type 1 Chassis
197799-001
* Celeron, 900 MHz, Type 1 Chassis
253105-001
* Celeron, 1.1 GHz, Type 1 Chassis
251629-001
* Celeron, 1.2 GHz, Types 2 & 3 Chassis
* Celeron, 1.3 GHz, Types 2 & 3 Chassis
* Pentium III, 933 MHz, Type 1 Chassis
* Pentium III, 1.0 GHz, Type 1 Chassis
259968-001
* Modem, V.90
153837-001
260444-001
* Not shown
207742-001
warranty.
July 2003
Document Part Number 234803-006
Spare Part Number 260444-001
253110-001
253111-001
251621-001
251620-001
271723-001
271722-001
271721-001
271720-001
279960-001
251614-001
262275-001
170080-001
170081-001
235024-001
261565-001
262030-001
263883-001
272404-001
239421-001
244105-001
166358-002
Miscellaneous Parts
1 Bezel blank
2 I/O panel, Type 1 Chassis
3 I/O panel, Types 2 & 3 Chassis
4 Power button with spring
5 Heatsink, up to 866 MHz, Type 1 chassis
* Heatsink, 866 MHz to 1.0 GHz, Type 1 chassis
* Heatsink, 1.1 GHz and above, Types 2 & 3 chassis
* Battery, real-time-clock
* Mouse
*Not shown
Miscellaneous Screws, Types 1 & 2 (not illustrated)
Miscellaneous screw kit, includes:
#6-32 x 1/4" long hex head (4 ea)
#6-32 x 3/16" long round head (3 ea)
M3 x 6 mm long hex head (14 ea)
Miscellaneous Screws, Type 3 (not illustrated)
Miscellaneous screw kit, includes:
T15 Torx slotted #6-32 x 0.236" long hex head (4 ea)
T15 Torx, slotted #6-32 x 0.157" long round head (4 ea)
T15 Torx slotted M3 x 6 mm long hex head (14 ea)
Keyboards (not illustrated)
United States
Canadian French
Latin American Spanish
Japanese (Kanji)
Polish
People's Republic of China
Taiwan and Hong Kong
251618-001
251615-001
271719-001
251619-001
251627-001
251628-001
268513-001
153099-001
253113-001
253112-001
280561-001
251623-001
251623-121
251623-161
251623-291
251623-241
251623-AA1
251623-AB1
