Page 1 TDC-0971- 011 ChoiceConnect® Fixed Network CCU 100 and Repeater 100 Installation Guide...
Page 2 All other product names and logos in this documentation are used for identification purposes only and may be trademarks or registered trademarks of their respective companies. Suggestions If you have comments or suggestions on how we may improve this documentation, send them to TechnicalCommunicationsManager@itron.com If you have questions or comments about the software or hardware product, contact Itron Technical Support: Contact Internet: www.itron.com...
Page 3: Table Of Contents
Lightning Arrestor ..........................12 AC Mains Power ..........................13 DC Mains Power ..........................14 Materials Not Provided by Itron ......................14 Coaxial Cable .......................... 14 Remote Mount Standard 5.15 dBi 915 MHz Antenna on a Standard CCU/Repeater .. 14 Remote Mount High Gain (8.15dBi) 900MHz Antenna on a Standard Collector or Repeater ........................
Page 4 Contents Wall Mount ..........................27 Davit Arm Mount ........................28 Connecting Cables ..........................29 Installing a Local 4G WAN Antenna ....................33 Installing the Battery .......................... 34 Providing Power ..........................37 CCU Installation Wiring Diagram ...................... 38 Tower Installation ..........................38 Tower Installation Overview ....................
Page 5 TCU / CCU / Repeater Remote Antennas & Coax on Towers ........106 Installing Coax Ground Kits ....................106 Collector Sites with Indoor Itron TCU / CCU Equipment ............109 RF Components Protection (Coax) ................109 Grounding Rooftop Network Devices..................111 Down Conductor Installation ....................
Page 6 Determining the Correct Measuring Point ..............120 Testing Procedures ..................... 121 Measuring Rod/Grid Resistance ................. 121 Understanding Party Responsibilities ................... 122 Itron Responsibilities ....................122 Supplier Responsibilities..................... 122 Index ........................... 125 TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 7: Before You Begin
The CCU 100 (also known as a cell control unit or collector) is the main collection point for the ChoiceConnect Fixed Network. The CCU reads data from Itron electricity meters, gas endpoints, and water endpoints and gathers consumption, daily, or hourly meter reads, and other information from endpoints and communicates it back to the utility over a public or private network.
Page 8: Related Documents
Before You Begin Tip A tip helps users apply the techniques and procedures described in the text to their specific needs. A tip is not essential to the basic understanding of the text. Related Documents For more information about CCUs/repeaters and the Fixed Network, see the following guides: Network Collection Engine User Guide •...
Page 9: Ccu/Repeater Basics
Electrical components are encased in a plastic enclosure that provides double insulation and a high level of safety for the installer. Caution Only authorized Itron personnel may open this device. Unauthorized access or modifications to this device voids the warranty.
Page 10: Ccu/Repeater Module
CCU/repeater configuration. Caution Only authorized Itron personnel may open this device. Unauthorized access or modifications to this device voids the warranty. Per FCC rules, unapproved modifications or operation beyond or in conflict with these instructions for use could void the user's authority to operate the equipment.
Page 11: Local Gps (Wan-3G Only)/Wan Antenna System
Connects the collector or repeater to the Ethernet backhaul. Also used to connect the collector or repeater to a router for initial collector setup. Mating weatherproof cables are available from Itron. These cables are sealed industrial Ethernet circular IP67 connectors (CONEC).
Page 12: 900 Mhz Antenna
Chapter 1 CCU/Repeater Basics Caution You must install the external GPS antenna in a vertical orientation, and the antenna must have an unobstructed view of the southern sky (North America and Europe) to properly receive a GPS signal. The external GPS/WAN antenna system is shown below. Item Description External GPS antenna...
Page 13 CCU/Repeater Components There are three antennas that can be used for the 900 MHz radio link. • A standard vertically polarized antenna (5 dBi) directly attached to the collector or repeater. A standard vertically polarized antenna (5 dBi) connected remotely. •...
Page 14 Chapter 1 CCU/Repeater Basics TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 15: Planning A Ccu/Repeater Installation
The collector or repeater is secured to a pipe or fence railing (from 2 to 3.5 inches in diameter). This type of installation typically occurs on the tops of water towers. For more information about these profiles, as well as the Itron-recommended profile, see Installing the CCU/Repeater on page 19.
Page 16: Propagation Study And Collector Or Repeater Site Selection
Itron's Joint Use Team. Propagation Study and Collector or Repeater Site Selection Before you install a collector or repeater in the field, contact Itron to perform a propagation study. A propagation study is performed for the following reasons: •...
Page 17: Ac Service Requirements
Siting Collectors or Repeaters • Near objects or devices attached to the same pole. • Within 500 feet of high power radio frequency (RF) transmitters (such as paging transmitters, cellular transmitters, and municipal communications transmitters). Note Typically, maintaining a 10-foot vertical separation from other transmitters allows for a co-location type of installation.
Page 18: Remote 900 Mhz Antenna Placement
5 feet. (For example, a 24-inch standoff at 4-inch diameter to a 60-inch standoff at 10-inch member diameter.) • Inform Itron about any conditions that may impact the collector or repeater performance. Grounding the Antenna System To minimize the potential for a lightning event, it is essential that remote/external antenna systems be properly grounded.
Page 19: 900 Mhz Antenna
Siting Collectors or Repeaters All grounding materials and procedures must meet or exceed local codes. Use coaxial grounding kits recommended by the coaxial cable manufacturer. Warning Under no circumstances should the antenna grounding wires be run inside a building. Always install ground bars and grounding material on the building's exterior.
Page 20: Lightning Arrestor
Chapter 2 Planning a CCU/Repeater Installation • A high-gain vertically polarized remote antenna (8.15 dBi) mounted remotely in place of the direct attached solution. Warning Do not install an 8.15 dBi antenna directly on the CCU. Antenna installation directly on the CCU will compromise mechanical integrity and will not meet the compliance requirement for a loss of 2.2 dB.
Page 21: Ac Mains Power
GFCI breaker. Size the wiring in accordance with the National Electrical Code, ANSI/NFPA 70, and, where applicable, the Canadian Electrical Code, Part I, CSA C22.1 or the prevailing local code. Power wiring on the Itron-supplied power cable follows conventional color coding for AC wiring: green (ground), white (neutral), black (hot).
Page 22: Dc Mains Power
+12V source. Attach the black wire to ground. Materials Not Provided by Itron The following materials are not provided by Itron in the collector or repeater kit, but are required for installation. Please acquire these items prior to beginning an installation.
Page 23: Remote Mount High Gain (8.15 Dbi) 900 Mhz Antenna On A Tower Ccu
You may use any type of 50 ohm coaxial cable as long as the total loss, including connectors, is less than 5 dB at 1.5 to 1.8 GHz. Itron recommends using regular 1/2" coax or Times Microwave LMR-400. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide...
Page 24: Antenna Sweep Test
Caution Since each installation is unique, you must ensure the mounting hardware securely supports the collector or repeater. The collector or repeater (minus attachment hardware) weighs 7 pounds. Itron recommends consulting with a qualified engineer to verify load requirements and safety issues. Also, be sure to check and comply with local codes when installing the collector or repeater.
Page 25 2.5 inch to 3.5 inch galvanized Two pipe mount brackets for pipes up to 3.5 inches in steel pipe diameter, supplied by Itron (part number FAB-0192- 001, two brackets are required for each collector or repeater). TDC-0971-011 CCU 100 and Repeater 100 Installation Guide...
Page 26 Chapter 2 Planning a CCU/Repeater Installation TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 27: Installing The Collector Or Repeater
A thorough structural analysis should be performed by a registered professional engineer at your desired location prior to installation. Itron is not responsible for improper installations or for installations at a site that cannot adequately support the collector or repeater.
Page 28: Attaching The External Gps/Wan Antennas
Chapter 3 Installing the Collector or Repeater Attaching the Local GPS/WAN Antennas You can attach the external GPS and WAN antennas to pipes, poles, walls, and davit arms. The 3G and 4G pole mount assemblies are shown in the following graphics. 3G GPS/WAN Antenna 4G GPS/WAN Antenna To attach the local GPS/WAN antennas...
Page 29 Attaching the Direct Mount Standard (5 dBi) 915 MHz Antenna 1. Slide the black rubber boot onto the base of the antenna as shown in the following illustration. 2. Screw the antenna onto the top of the collector or repeater. Be careful not to cross- thread the connectors.
Page 30: Attaching The Collector Or Repeater
For a wall mount, use two metal brackets (not shown below), four mounting bolts, nuts, and lock washers to prepare the collector for mounting. Itron does not supply the hardware necessary to mount the wall mounting brackets to the wall.
Page 31: Pipe Mount
Attaching the Collector or Repeater An integrated mounting support on the back of the collector or repeater enclosure slides into the slot in the center of the mounting bracket. A set screw locks the collector or repeater to the mounting bracket. Orientation of the enclosure may be adjusted +/- 16 degrees horizontal to compensate for different angles.
Page 32 Chapter 3 Installing the Collector or Repeater To mount the collector or repeater on a pipe In the following illustration, the mounting plate is attached to the vertical pipe with the mounting brackets. The collector or repeater enclosure is secured to the mounting plate. 1.
Page 33: Pole Mount
Attaching the Collector or Repeater Pole Mount If the vertical pipe or pole exceeds 6.75 inches in diameter, you may use metal bands instead of the mounting brackets to secure the mounting plate to the pipe or pole. Two sets of slots (1.5 in. long) on the mounting plate are provided for the metal bands. It may be necessary to use the remote 900 MHz antenna kit to achieve optimum RF performance and GPS coverage if the pole obstructs the desired RF path.
Page 34 Chapter 3 Installing the Collector or Repeater 2. Insert the mounting disc (on the back of the collector) into the mounting plate keyhole. 3. Using the provided set screws, secure the collector to the mounting plate with the antenna in the upright position. 4.
Page 35: Wall Mount
2. Using four bolts, secure the collector or repeater to the two wall mounting brackets with the antenna in the upright position. 3. Using four appropriate screws or bolts (not provided by Itron), attach the mounting brackets to the wall.
Page 36: Davit Arm Mount
Chapter 3 Installing the Collector or Repeater Davit Arm Mount The following figure illustrates a typical utility pole or street light pole installation. The collector or repeater is mounted on a davit arm or the street light arm. Two types of power connections are typical.
Page 37: Connecting Cables
Connect the remote/external antenna cables (if needed), Ethernet cable (if needed), and grounding wire. Due to the variable requirements for cable length, cables are not provided by Itron. Important All coaxial cable connections must be properly weather-proofed per industry standards unless otherwise specified. (For an example, see Step 3 of the...
Page 38 Chapter 3 Installing the Collector or Repeater To connect cables 1. The GPS cable has an SMA connector on one end and a TNC connector on the other end. Connect the SMA connector end of the GPS antenna cable to the collector or repeater.
Page 39 Connecting Cables b. Wrap vinyl electrical tape around the connection starting at the collector and moving up the cable as shown in the following illustration. The vinyl electric tape provides a foundation for the butyl rubber sealant, making it easier to disconnect the cable. c.
Page 40 Chapter 3 Installing the Collector or Repeater e. Overlap the butyl rubber so there is no gap. The butyl rubber will self-vulcanize over time and the seam will disappear. f. Wrap vinyl electric tape around the butyl rubber starting at the CCU and moving up as you did in Step a.
Page 41: Installing A Local 4G Wan Antenna
Installing a Local 4G WAN Antenna g. Continue wrapping the vinyl tape in a spiral back down to the collector. You now have two layers of vinyl tape covering the butyl rubber. 4. If you are using an Ethernet backhaul, attach the Ethernet cable ensuring the weather- tight connector is properly secured.
Page 42: Installing The Battery
Chapter 3 Installing the Collector or Repeater 2. Attach the 4G WAN antenna on the N-Connector on the bottom of the CCU labeled WAN. Installing the Battery If you are installing a battery with a ferrite bead on the wires, as shown in the following illustration, follow the directions in To install a battery (ferrite bead) on page 36.
Page 43 Installing the Battery 2. Plug in the four pin battery wiring harness. The harness should snap into place, providing a secure connection. 3. Slide the battery into the battery compartment. 4. Replace the battery compartment cover, and torque the screws to 6 inch-pounds. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 44 Chapter 3 Installing the Collector or Repeater To install a battery (ferrite bead) 1. Insert the battery connector into the connector on the CCU 100. 2. Align the edges of the ferrite bead with the edges of the recess in the battery well. 3.
Page 45: Providing Power
Providing Power Providing Power The final step of the collector or repeater installation is to provide power to the equipment. Depending on the collector or repeater model, either a two pin cable (DC), three pin cable (AC), or a five pin cable (solar) is required. Caution Do not move or tilt the collector for one minute after connecting power.
Page 46: Ccu Installation Wiring Diagram
Tower CCU and mounting hardware. A thorough structural analysis should be performed by a registered professional engineer at location prior to installation. Itron is not responsible for improper installations or for installations at a site that cannot adequately support the Tower CCU.
Page 47: Tower Installation Overview
Tower Installation Because of the size and weight of the Tower CCU, Itron recommends more than one person be present for the installation. For more information, see the Tower Enclosure CCU 100 Basic Installation Quick Reference (TDC-0964-000). Tower Installation Overview...
Page 48 Chapter 3 Installing the Collector or Repeater • Wall/H-Frame mount. In this configuration, the TCU is bolted to a stable and secure vertical surface, such as a wall or h-frame, with 3/8–16 (min) bolts and pierced and slotted brackets (no kit). The TCU box comes preassembled except for the CCU.
Page 49: Tcu Components
Important This unit must be installed in accordance with the National Electrical Code and with all local codes. Provide power to the cabinet using electrical conduit. Itron recommends using a knockout punch and die (such as a Greenlee® Slug-Buster®) to punch the appropriate sized hole in the bottom of the cabinet.
Page 50 Chapter 3 Installing the Collector or Repeater 1. Attach the TCU to the TCU mounting plate. a. Insert the TCU mounting disc into the mounting plate keyhole. b. Slide the TCU down until you feel it click into place. 2. Connect the cable from the TCU to the RF filter. 3.
Page 51 9. Connect power to the cabinet. See the wiring diagram on the inside of the cabinet door. Provide power to the cabinet using electrical conduit. Itron recommends using a knockout punch and die (such as a Greenlee® Slug-Buster®) to punch the appropriate sized hole in the bottom of the cabinet.
Page 52: Tower Ccu Wiring Installation Diagram
Chapter 3 Installing the Collector or Repeater Tower CCU Wiring Installation Diagram TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 53: Solar Powered Installation
Because of the size and weight of the solar system, Itron recommends more than one person is present for the installation.
Page 54: Sunwize Solar Panel Wiring Legend
Sunwize Solar Panel Wiring Legend The following diagram illustrates how an Itron Sunwize solar panel system must be wired to connect to the collector or repeater.
Page 55: To Assemble The Solar Ccu 100
Maintenance Manual supplied with the solar system. 2. Set the photovoltaic (PV) array's tilt and azimuth to the angles recorded in the design specifications provided by Itron. The Array Tilt value is the angle of the array from horizontal.
Page 56 Installing the Collector or Repeater Red. Collector or repeater power + • Black. Collector or repeater power - • • Green. Low battery indicator • Orange. Solar ID_1 • White. Solar ID_2 4. Mount the collector or repeater in the desired location. Note The supplied power cable from the solar battery box to the CCU/repeater is only 12 feet long.
Page 57 Solar Powered Installation The Array Tilt value is the angle of the array from horizontal. The default value normally maximizes annual energy production. For information about the tilt angle, click Array Tilt. The Array Azimuth value is the angle of the array clockwise from true north. The default value normally maximizes energy production.
Page 58: Solar Installation Wiring Diagram
Installing the Collector or Repeater Solar Installation Wiring Diagram The following diagram shows a typical solar powered installation. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 59: Relocating A Ccu Or Repeater
Relocating a CCU or Repeater Relocating a CCU or Repeater 1. Disconnect the AC power. Caution Do not disconnect the battery. 2. Relocate the CCU or the repeater. 3. Reconnect the AC power. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 60 Installing the Collector or Repeater TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 61: Battery Care And Maintenance
Battery Storage and Charging To ensure maximum lifespan and efficiency from your collector or repeater batteries, Itron recommends the following storage and maintenance procedures. Long-Term Storage Batteries may be stored for up to two years at room temperature (25°C or 77°F), and then may be recharged with no loss in cell reliability or performance capabilities.
Page 62: State Of Charge
Chapter 4 Battery Care and Maintenance Itron recommends you conduct open circuit voltage audits every six months on batteries stored at or near 25°C (77°F). Recharge batteries when OCV readings approach 6 volts (2.00 volts per cell). Increase OCV audits if storage temperatures are significantly higher than 25°C (77°F)—even for short durations.
Page 63: Battery Service Life
Battery Service Life The charging of collector and repeater batteries requires the following items: • Power Sonic PSC-61000A-C charger • Molex 39-01-4046 connector • Collector or repeater batteries The recommended method for charging batteries is to utilize the Power Sonic PSC- 61000A-C charger.
Page 64: Preventative Maintenance
A ten year battery lasts for five years at 33°C (91.4°F) and only 2½ years at 41°C (105.8°F). Preventative Maintenance Itron recommends a preventative maintenance cycle of a two-year replacement in extreme environments (average temperatures greater than 110°F/44°C), or five years in non- extreme environments (average temperatures less than 90°F/31°C).
Page 65: Detailed Collector Or Repeater Specifications
P P E N D I X Detailed Collector or Repeater Specifications CCU or Repeater Dimensions and Weight Weight is shown in pounds and dimensions are shown in inches. Component Weight CCU 100 or Repeater 100 7 lbs TCU 100 AC tower unit 76 lbs External GPS/WAN antenna system 6 lbs...
Page 66 Appendix A Detailed Collector or Repeater Specifications TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 67 CCU or Repeater Dimensions and Weight The following illustration shows the dimensions for the optional pedestal unit. This unit ships with a gasket and fasteners to attach the cabinet to the pedestal. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 68: Antenna Specifications
Appendix A Detailed Collector or Repeater Specifications Antenna Specifications Specifications for the 900 MHz, GPS, and WAN antennas are listed in the following tables. Important All coaxial cable connections must be properly weather-proofed per industry standards unless otherwise specified. This includes any connections for the antennas and the collector or repeater components.
Page 69: Environmental Specifications
< 1.0 lb. For the latest antenna part numbers, see the Fixed Network 100 Ordering Guide or contact your Itron representative. To reduce potential radio interference to other users, select an antenna type with gain such that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication.
Page 70: Transmitter
Warning There is a risk of explosion if the battery is replaced by an incorrect type. Always replace with Itron part number BAT-0045-001. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 71 Battery Pack The batteries can power the system for a duration of 90 minutes in the case of a power outage. Then AC power fails The collector or repeater battery pack maintains system functions for approximately 90 minutes. A message indicating the AC failure is sent to the Network Collection Engine.
Page 73: Port And Protocol Requirements
P P E N D I X Port and Protocol Requirements Network Collection Engine (NCE) installations are typically deployed when CCUs are on the Internet, the Fixed Network web server is in a DMZ, and the Fixed Network database server is in the corporate intranet. The following illustration is a simple diagram of the network topology.
Page 74: Ports And Protocols
Protocol Required Purpose address port address port operation Fixed Network cdp1.itron.com HTTP Itron Product Root Certificate web server Revocation List: http://cdp1.itron.com/CertEnroll/ Itron Product Root.crl. Fixed Network Utility CDP HTTP Certificate Revocation List. web server Usually published from Fixed Network database server;...
Page 75 Ports and Protocols Fixed Network database/NPA server outbound traffic Source Source Destination Destination Protocol Required Purpose address port address port operation Fixed Network Collectors (any) 4443** HTTPS Collector commands and database server diagnostic portal. Fixed Network initial 4443** HTTPS Collector shutdown, reboot, etc. database server configuration Collector commands and...
Page 76 Appendix B Port and Protocol Requirements Fixed Network server to server traffic (DMZ → intranet) Source Source Destination Destination Protocol Required Purpose address port address port operation Fixed Network Fixed Network 1433** MSSQL Database access. web server database server Fixed Network Fixed Network 1433** MSSQL...
Page 77 Ports and Protocols Workstation to server traffic Source Source Destination Destination Protocol Required Purpose address port address port operation Fixed Network Fixed Network 1433** MSSQL Database access for Collector workstation database server Configuration Application (CCA) (Fixed Network 4.0 only). Fixed Network Fixed Network HTTP Network Administration...
Page 78 Appendix B Port and Protocol Requirements TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 79: Status And Diagnostics
P P E N D I X Status and Diagnostics Status Indicator The LED Status Indicator is primarily intended to support installation personnel for immediate feedback. The following sequences define the Fixed Network solution's operational characteristics: Sequence details: The dot time: 100 mSec The dash time is 300 mSec Off Time between B and N: 700 mSec Off time between dot and dash: 100 mSec...
Page 80: Performing An Antenna Sweep Test
Appendix C Status and Diagnostics Collector State Description LED Pattern No Battery The collector determined it should Morse code for the letter ‘S’ ( . . . ) have a backup battery, but that battery does not appear to be present or is not functioning.
Page 81 Performing an Antenna Sweep Test • Test Gear: Current and proper calibration; be sure that calibration is turned on during the test. A qualified operator of the test equipment must perform the test. Note If the system does not perform to the previous test specifications, the reasons for system failure and possible remedies must be identified before leaving the installation site.
Page 82 Appendix C Status and Diagnostics TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 83: Changing The Repeater Password
P P E N D I X Changing the Repeater Password To change the repeater password, you must log into the user interface as an administrator. The following procedures illustrate each step with Repeater 100 user interface screens. To access the repeater user interface 1.
Page 84 Appendix D Changing the Repeater Password 4. Highlight the collector or repeater you wish to access and click Connect. 5. Type the Security key. 6. Open a browser window and type https://192.168.1.9:4443 TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 85 Performing an Antenna Sweep Test 7. Click Continue to this website (not recommended). 8. Type the Username and Password. Note The user name and password are case sensitive. • Username. admin • Password. Itr0n1 TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 86 Appendix D Changing the Repeater Password The Main Menu window appears. To change the repeater password 1. From the user interface Main Menu, click Configuration. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 87 Performing an Antenna Sweep Test 2. From the Configuration menu, click Wireless Diag. 3. Enter the new information and click Submit. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 88 Appendix D Changing the Repeater Password TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 89: Antenna Line Sweeps Procedure
ChoiceConnect® system architecture, enhances customer engagement, increases operational efficiencies, and ensures system integrity. The endpoints transmit to an Itron installed collection engine (data server) that is installed at the customer site, via one of three Itron manufactured network devices: a ChoiceConnect Tower Mounted Collector Unit (TCU 100), a ChoiceConnect Collector Unit (CCU 100) or a ChoiceConnect Repeater Unit (Repeater 100).
Page 90: Testing On A Network Device With A Remotely-Mounted 900 Mhz Antenna
Perform sweep testing under the following specific testing conditions: Note Attach a copy of each trace to the antenna sweep checklist so that the Itron Field Engineer can inspect and sign off on acceptable results. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide...
Page 91 1. Configure the test equipment in return loss mode and calibrate. 2. Identify if the antenna passes or fails based on antenna manufactures specification. For more information about the antenna specifications, see Itron ChoiceConnect 900MHz Antenna Specifications on page 89.
Page 92: Understanding Party Responsibilities
The supplier should expect that representatives from both Itron and the customer will be on site at several installations of each type of network device (if not more), to ensure the installations meet the Itron and customer quality and design requirements.
Page 93 • Compiling a package of as-built and closeout documentation in a compact electronic format (Adobe .pdf files preferred) and e-mailing each site package to the Itron PM development within three business days following each completion. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide...
Page 94 Appendix E Antenna Line Sweeps Procedure TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 95: Itron Choiceconnect Antenna And Line Sweep Test Form
Itron ChoiceConnect Antenna and Line Sweep Test Form This attachment contains an example of the Itron ChoiceConnect® Antenna and Coax Sweep Test Form. Itron provides this form to the supplier, so that the supplier can determine their fixed fee, lump sum, and all inclusive pricing needed to complete the expected number of network device installations.
Page 97: Itron Choiceconnect 900 Mhz Antenna Specifications
Itron ChoiceConnect 900 MHz Antenna Specifications The BOA 900MHz omnidirectional base station antennas consist of a linear array, encapsulated in a heavy duty fiberglass radome with a thick walled 6061-T6 aluminum mounting base for reliable long term use. This rugged design allows the antennas to withstand harsh environments and is ideal for Industrial, Wireless, and SCADA applications.
Page 98: Typical Coaxial Cable Specification Summary Table
Antenna Line Sweeps Procedure The following illustration shows the antenna's electrical specifications: The following illustration shows the antenna's mechanical specifications: Typical Coaxial Cable Specification Summary Table Coaxial Cable Return Loss/VSWR Make Cable Model Return Loss (dB) VSWR (max.) Andrew 7/8" Heliax LDF5-50A -24.5 1.13:1...
Page 99: Sample Sweeps Output
Sample Sweeps Output Sample Sweeps Output Return Loss: Cable Path Loss: TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 100 Antenna Line Sweeps Procedure Cable Length: TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 101: Grounding Specifications
The ChoiceConnect® Grounding Specification procedure is designed to ensure that remote and tower mounted antennas perform to the required specification prior to integration of collector or repeater into the Itron Fixed Network. For devices already on- air, this testing procedure can be used for troubleshooting problems.
Page 102: Understanding Grounding And Bonding
Reducing the Ohms level In many areas of the country you may be starting with 350 Ohms or more. Itron’s networks are built all over the United States and the geological features can vary greatly in different parts of the country; therefore, allow the installing contractor to determine how best to lower resistance to ground (to 5 Ohms or less) in a specific region.
Page 103: Using A Megger
Sample Sweeps Output • temperature • depth and spacing of the ground rods. For more information about using a Megger to measure the resistance to ground, see Using a Megger on page 95. Drive a new service entrance ground rod. You cannot know the exact length or •...
Page 104: Adjusting The Routing Of The Grounding Conductor
Appendix F Grounding Specifications Meggers come in three and four terminal configurations. To test the actual resistivity of the soil itself, use a four terminal model. The advantage of this method is that you are not connected to the electrical system during testing. An electrical line fault during testing can send high current to the grounding system, resulting in high current and voltage at the test leads and meter.
Page 105: Supplier General Requirements And Equipment Competencies
Sample Sweeps Output Supplier General Requirements and Equipment Competencies Itron requires that all suppliers have previous telecom experience and have the following equipment and resources: • Certified, Clamp-On Ground Resistance testing devices (or equivalent) • Competent trained operators readily available •...
Page 106 Appendix F Grounding Specifications • Ground bars. Bars must be 1/4 inch thick solid electrical grade copper and must be electroplated with tin 0.0003 inches thick typical, 0.0002 inches thick minimum. Hole spacing between top row and center row holes must be ¾ inch, between center row and bottom row holes must be 1 inch (Telco), and between top row and bottom row must be 1 ¾...
Page 107: Existing Building Or Rooftop Sites
Ground kits must be solid strap type with No. 6 AWG wire and 2-hole compression crimped lugs (installed using the proper UL tool and circumferential hexagon die). Ground kits ordered through Itron North Supply do not require approval. Coax ground kits not ordered through Itron North Supply require approval from the Itron construction team.
Page 108: Co-Located Sites & Other Existing Structures
BGR can be started by the contractor. Equipment Buried Ground Ring The following is a list of required specifications for all Itron sites not installed on a lite pole structure. This includes TCU, CCU, and Repeater sites: •...
Page 109: Chemical Ground Rod Installation
Tapes must be saved and made available to the Inspector to verify removal and proper installation. When an Itron TCU / CCU / Repeater is co-located with another wireless service provider’s site, bond Itron’s grounding system to the tower BGR, to another provider’s ground system, or to the common ground ring to ensure that all ground systems are at the same potential.
Page 110 Appendix F Grounding Specifications TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 111 Sample Sweeps Output The following illustration shows exterior ground details. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 112 Appendix F Grounding Specifications TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 113: Itron Concentrator Equipment
TCU / CCU on a Steel Frame or I-Beam or Platform If the Itron TCU / CCU equipment is mounted on a steel frame or I-beam, bond the steel to the BGR at opposite ends with two No. 2 AWG BTCW and exothermically welded at each end.
Page 114: Tcu / Ccu / Repeater Remote Antennas & Coax On Towers
Grounding Specifications In this configuration, the MGB is typically used for Itron TCU / CCU equipment, coax cable, and platform grounding. 4. Mount the MGB so that all equipment, coax, and platform ground lugs attach to the top two rows of holes and the leads connecting to the BGR attach to the bottom two rows of holes.
Page 115 Sample Sweeps Output • At the bottom of a tower on page 107 • At the end of an ice bridge on page 107 • With GPS and WAN antennas on page 108 • Grounding a coax ground kits on page 108. To install coax ground kits at the top of a tower Install one CGB at the top of the tower as close as possible to the tower top coax ground kits.
Page 116 Grounding Specifications To attach a coax ground kit at GPS and WAN antenna If the GPS and WAN antennas are mounted on the monopole or antenna support structure, attach a coax ground kit to the coax as close as possible to the antenna and connected to a small CGB.
Page 117: Collector Sites With Indoor Itron Tcu / Ccu Equipment
Sample Sweeps Output Collector Sites with Indoor Itron TCU / CCU Equipment When grounding equipment for collector sites where the Itron TCU / CCU equipment is located indoors include the installation on an interior ground ring (halo) installed approximately 6 inches below the ceiling or 8 feet above the finished floor, whichever is lower.
Page 118 Grounding Specifications To work with interior connections 1. Connect all grounding and bonding conductors that are connected above grade or interior to a building using two-hole multiple crimp type (with UL tool and circumferential die compression) connections or by exothermic weld connections where allowed.
Page 119: Grounding Rooftop Network Devices
Do not use AC service panel grounds. 3. If the Itron TCU / CCU equipment is located on the ground floor or in the basement, the MGB may be connected directly to both building steel and the water main or ground rod.
Page 120: Down Conductor Installation
3. If the Itron TCU / CCU equipment is located on the ground floor or in the basement, the MGB can be connected directly to both the existing lightning protection or building ground system and the water main or ground rod.
Page 121: Cold Water Pipe Option
Sample Sweeps Output A low halogen cable that meets the ratings of Telcordia GR-347 is acceptable. Place the MGB bar as close as possible to the equipment cabinets and the path to ground options (for example, ground rod, cold water pipe, or building steel). Install the ground bar to ensure that the wire bending radii for the 4/0 AWG and No.
Page 122: Cable Tray Grounding
Grounding Specifications Grounding antennas on rooftops 1. Bond each antenna mount/mast to the CGB with No. 2 AWG BTCW exothermically welded to the mast and connected to the ground bar with an approved two- hole ground lug. 2. Install coax ground kits as close to the antennas as possible, just before the antenna jumpers, and then bonded to the CGB.
Page 123: Water Tower Grounding
Itron does not construct water towers. Therefore, network devices utilizing water towers as antenna structures do not require the installation of a structure ground ring around the leg of a water tower. The equipment BGR serves as the primary ground point for all Itron equipment, antennas, coax, and cable tray.
Page 124: Equipment Shelter Grounding
Equipment Shelter Grounding Ground Itron equipment that is installed in shelters the same way you ground a non- shelter site in terms of equipment ground leads, coax ground kits prior to the Itron TCU / CCU equipment jumpers, and MGB placement.
Page 125: Repeaters On Rooftops
Sample Sweeps Output 4. Bond the CGB to a single ground rod located immediately adjacent to the support structure using No. 2 AWG BTCW. Note In all cases, ensure that the grounding design complies with the utility pole owner’s requirements. Repeaters on Rooftops Repeaters located at rooftop sites must have antenna mounts, coax, and coax cable tray (if required) grounded in the same manner as a full network device.
Page 126: Cable Entrance Facilities
Grounding Specifications AC Power Grounding Connections In accordance with the National Electric Code, Article 250 or appropriate local codes, bond the AC power neutral to the Master Ground Bar (MGB-1) Producer (P) section. Refer to Section 3.2.1 of NP-312-202, Interior Grounding System Design, for more information.
Page 127: Clamp-On Ground Resistance Testing
Sample Sweeps Output Clamp-On Ground Resistance Testing A clamp-on ground resistance tester measures ground rod and small ground grid resistance without the use of auxiliary ground rods. Clamp-on ground resistance testers are used in multi- grounded systems without disconnecting the ground under test and with electrical service connected.
Page 128: Determining The Correct Measuring Point
Grounding Specifications The following illustration shows a Principle of Operation. Determining the Correct Measuring Point The preferred point of measurement (if internal bonding allows) is on the conductor between the ground bus and the service neutral. If internal bonding does not allow access to this point, an alternate point is on the service side of the neutral line prior to the neutral to ground bond.
Page 129: Testing Procedures
Sample Sweeps Output The following illustration shows an overview of the testing location. Testing Procedures To prepare the meter 1. Ensure mating surfaces of the jaws are clean and free of corrosion. 2. Press and hold the ON/OFF button for approximately 3 seconds. 3.
Page 130: Understanding Party Responsibilities
The Supplier should expect that representatives from both Itron and the Customer will be on site at several installations of each type of network device (if not more), to ensure the installations meet the Itron and Customer quality and design requirements.
Page 131 • Compiling a package of as-built and closeout documentation in a compact electronic format (Adobe .pdf files preferred) and e-mailing each site package to the Itron PM development within 3 business days following each completion. TDC-0971-011 CCU 100 and Repeater 100 Installation Guide...
Page 132 Grounding Specifications TDC-0971-011 CCU 100 and Repeater 100 Installation Guide Proprietary and Confidential...
Page 133: Index
Index pole mount • Symbols & Numbers power operating range • siting • specifications • wall mount • charging • installation diagram • coaxial cable • mains power • components • service requirements • connecting cables • 9, 12, 14, 16, tower installation diagram •...
Page 134 • AC • battery pack • DC • CCU • maintenance • environmental • materials not provided by Itron • repeater • module • transmitter • mounting hardware • 16, state of charge • status indicator • storage •...

This manual is also suitable for:

Choiceconnect repeater 100

ITRON ChoiceConnect CCU 100 Installation Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ITRON ChoiceConnect CCU 100

Summary of Contents for ITRON ChoiceConnect CCU 100

This manual is also suitable for:

Table of Contents
