PRIOR to USE
Install the mount onto a strong structure such as concrete wall
Use the supplied accessories when installing the mount bracket depends on mounting position
DIMENSION
(Unit: mm)
PARTS SUPPLIED
Junction Box
Screw
AK-22 Quick Installation Guide (EN)
Waterproof Stopper
Screws, Water-proof
Stopper For Wire
SPECIFICATION
Construction: Aluminum Cast
Environment: Ceiling Mount
Dimension(mm): ф113.5x44.0 mm
Weight: 239g (0.53lb)
Rubber
3 x Expansion Bolt
Installation Template
3 x Screws
QIG
