TCL LED32B2600 Service Manual page 6

TCL MULTIMEDIA
LCD TV SPECIFICATION RELEASE
Version: V1.0
Model: LED32B2600/MS306D-ISDB-T LA
Panel Size (inch)
Category
Aspect Ratio
Color Temperature
Backlight Adjustable
Scaler Mode
Picture Effect
Film Mode (3:2 pull down)
Picture Enhancement
Comb Filter
Dynamic Niose Reduction
Adaptive De-interlacing
Blue Stretch
Black Stretch
Motion Compensation
DLTI
DCTI
Dynamic Skin Correction
DNR
Panel Specification
Back Light Unit
Panel Supplier
Viewing Technology
Display Resolution
Brightness (cd/m2)
Contrast Ratio
Response Time
Viewing Angle (H/V)
Life Time
Color
SOUND
Speakers
Audio Power Output
DVSS (Dolby Virtual Surround)
DDAS (Digital Dynamic Audio System)
AVC (Auto Volume Control)
BBE
SRS
MTS
Sound Features
Sound Control
FUNCTION
Parental Guidance
CCD (Closed Caption)
Teletext
Macro Vision
Calendar
Clock/Timers
Lock
OSD Language
OSD Features
REC
GUIDE
AUDIO Language
Screen Saver
Melody
Software Upgrade
Game
USB Connection
Demo Function
Hotel
Other Functions
Design and specifications are subject to change without notice!
Issued Date: 2013.08.12
32"
LCD TV
16:9
Medium/Warm/Cool
Yes
Auto/4:3/16:9 /Zoom1/Zoom2/Panorama
4 Picture Effects Preset (Standard/Dynamic/Mild/User)
Auto
3D
3D
3D
Yes
Yes
Yes
Yes
Yes
Yes
Yes(Off/Low/Middle/High)
LED
CSOT(4A-LCD32O-CS2)
16:9
1366*768
250(typical)
3000:1
6.5ms
178°/178°
＞30,000hrs(min)
16.7M (8 bit)
Integrated speakers (Bottom Side)
5W+5W
X
YES
YES
X
X
Yes(Stereo/Mono/SAP)
AV Stereo,Mstar Surround
Volume, Balance,5 Band EQ, 5 Mode Presets
(Movie/Sports/Standard/Music/User)
Yes
Yes
X
X
X
Yes
Yes(Parental Guidance and Content Lock at DTV )
English/Portuguese/Spanish
16 Bit Colors
Yes(at DTV)
Yes(at DTV)
Yes(at DTV)
Optional
X
Yes(By USB)
Yes
Yes.Movie /Music/Photo/ Text
X
In Factory Mode
NA
SIGNAL FORMAT CAPABILITY
Component Video Format Y,Pb/Cb,Pr/Cr:up to 1080P
DVI Video Format Up to XGA for HDMI-PC
HDMI Video Format Up to 1080P
PC Compatibility Up to SXGA
TERMINALS
Audio/CVBS Input (Composite) 2 (AV1 on side,AV2 Share with "YPbPr")
S-Video Input X
Audio Input for S-Video X
YPbPr Input 1
Audio Input for YPbPr 1
YCbCr Input Share with for "YPbPr"
Audio Input for YCbCr Share with for "YPbPr"
VGA Input(RGB) 1 (D-Sub,15 Pins)
Audio Input for RGB Share with for "YPbPr"
DVI Share with "HDMI" PORT
Audio Input for DVI Share with for "YPbPr"
HDMI 2
Audio/CVBS Output (Composite) 1(Audio Output For Mini;CVBS Output For RCA)
SPDIF 1
Headphone Output X
RF Input(Antenna) 2 (Antenna,Cable) F Type
USB 2.0 1(At Side)
BASIC INFO.
TV System NTSC-M,PAL M/N
DTV System ISDB-T
AV System PAL,NTSC
Channels(Analog) Antenna：2～69；CATV：1～125
DTV Channels(Digital) Antenna：7～69
Chassis MS306D-LA
Certification CB
Power Supply AC 110V-240V 50/60Hz
Power Consumption-TV on 45W
Power Consumption-Standby ≤0.5W
Default Color of Front Cabinet Black
Keyboard Position Back
Base Stand Detachable Yes
Unpackaged Dimension for Main Body (L*H*D) (mm)
With Base Stand (mm) 739.6*502*200
Without Base Stand (mm) 739.6*450*114
Packaged Dimension (L*H*D)
854*571*165
Main Body (mm)
Speaker Box NO
Base Stand Packaged with ALL
Net Weight (Kg) 5.6kg
Gross Weight (Kg) 7.4kg
Container Loading
20 feet 368
40 feet 784
40 feet high 892
ACCESSORIES
Operation Manual English(Default)
Remote Control Mode RC200 (with two 7# batteries)
Base Stand Integrated Packaging
Speaker Box Integrated
Wall Mount Optional
Others AC Power Cord
Drafted by:XiaoJianfeng/ZengZhenhua
Approved by:
