5-3. The BIOS Setting Menu

Reboot your system. Press <CTRL> and <H> key while booting up the system to enter the BIOS setting
menu. The main menu of BIOS Setting Utility appears as below:
For selecting the option in the menu, you may:
Press F1 to view array status.
Press ↑↓ (up, down arrow) to choose the option you want to confirm or to modify.
Press Enter to confirm the selection.
Press Esc to return to top menu.
If you want to create a RAID 0 (striping) array or RAID 0+1 array, all data in your hard disk will first
be erased! Please backup the hard disk data before creating a RAID array. If you want to create a
RAID 1 (mirroring) array, please be sure which hard disk is the source disk and which one is the
destination disk. If you make a mistake, you may copy the blank data to the source disk, which will
result in both hard disks becoming blank!
