RADLEY 1239-221 Owner's Manual

RADLEY 1239-221 Owner's Manual

20vmax cordless drill

Advertisement

READ ALL INSTRUCTIONS BEFORE FIRST USE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
*Maximum initial battery voltage (measured without a workload)
JD6321
is 20 volts. Normal voltage is 18 volts.
WEAR CSA APPROVED
EYE PROTECTION
WEAR EAR
PROTECTION
1239-221
WEAR A
FACE MASK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1239-221 and is the answer not in the manual?

Questions and answers

Dwayne Fay
January 19, 2025

Why can’t I find a replacement charger for my Radley drill

User image 678ccbe35c41e
1 comments:
Mr. Anderson
May 14, 2025

It may be difficult to find a replacement charger for the Radley drill 1239-221 because the charger is designed specifically for the 20V Max cordless drill battery and should not be used with other batteries. Using a different charger or battery may cause damage or pose safety risks. The charger must also meet specific electrical and safety standards, making it less interchangeable with generic options.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for RADLEY 1239-221

  • Page 1 1239-221 READ ALL INSTRUCTIONS BEFORE FIRST USE. KEEP THIS MANUAL FOR FUTURE REFERENCE. *Maximum initial battery voltage (measured without a workload) JD6321 is 20 volts. Normal voltage is 18 volts. WEAR CSA APPROVED WEAR EAR WEAR A EYE PROTECTION PROTECTION...
  • Page 2 PRODUCT SPECIFICATIONS 20V MAX CORDLESS DRILL Variable chuck speed 0–700 RPM Torque clutch positions 19 + 1 Drill mode ” Single sleeve 3 / 8 Keyless chuck 1 / 4 ” In metal 3 / 4 ” in wood Maximum drilling capacity Weight 2 lb.
  • Page 3: Table Of Contents

    1239-221 TABLE OF CONTENTS ………….……………………………………………………………1 Table of contents ………….……………………………………………………………2 General safety warnings ………….……………………………………………………………3 Eye, ear & lung protection ………….……………………………………………………………3 Electrical safety ………….…………………………………………………………….4 Power tool safety ………….……………………………………………………………4–6 Work area safety ………….……………………………………………………………4 Personal safety ………….……………………………………………………………5 Power tool use and care ………….……………………………………………………………5–6 Battery tool use and care ………….……………………………………………………………6...
  • Page 4: General Safety Warnings

    GENERAL SAFETY WARNINGS WARNING: Before using this tool or any of its accessories, read this manual and follow all Safety Rules and Operating Instructions. The important precautions, safeguards and instructions appearing in this manual are not meant to cover all possible situations. It must be understood that common sense and caution are factors which cannot be built into the product.
  • Page 5: Electrical Safety

    1239-221 ELECTRICAL SAFETY WARNING: use proper circuit protection. WARNING: Ventilation openings in batteries and chargers must always be open to allow cooling air to circulate freely. Air vents that are blocked, restricted or covered may result in the battery or charger overheating.
  • Page 6: Personal Safety

    PERSONAL SAFETY Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
  • Page 7: Battery Tool Use And Care

    1239-221 Maintain power tools. Check for misalignment or binding of moving parts, operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
  • Page 8 SPECIFIC SAFETY RULES WARNING: Know your cordless drill. Do not plug in the charger or install the battery in the tool until you have read and understand this Owner's potential hazards related to this tool. Following this rule will reduce the risk WEAR CSA Always wear eye protection.
  • Page 9: Battery & Charger Safety

    1239-221 Before starting the operation, jog the drill switch to make sure the drill bit does not wobble or vibrate. apart or become unbalanced during use. Make sure the spindle has come to a complete stop before touching the chuck or attempting to change the drill bit.
  • Page 10: Battery Pack Recycling

    Use the charger only in a standard 120V, 60 Hz electrical outlet. Do not use the charger in wet or damp conditions. It is intended for indoor use only. Do not use the charger near sinks or tubs. Do not immerse the charger in water.
  • Page 11: Symbols

    1239-221 SYMBOLS WARNING: Some of the following symbols may appear on the drill. Study these symbols and learn their meaning. Proper interpretation of these symbols Volts Direct current Amperes No load speed Hertz Alternating or direct current Watts Class II construction...
  • Page 12: Know Your Cordless Drill

    KNOW YOUR CORDLESS DRILL & BATTERY PACK Torque clutch Single sleeve keyless chuck LED worklight Trigger switch Forward / reverse switch Battery 5350-547 Battery charger DKYC2100400U Green ADAPTER CHARGER BASE CHECKING THE BATTERY CHARGE STATUS The level of charge remaining in the battery can be checked by using the battery LED power indicator that is contained on the end of the battery.
  • Page 13: Assembly And Operating

    1239-221 ASSEMBLY AND OPERATING CHARGING THE BATTERY PACK Place the battery charger (1) in a dry location near a 110–120V 60 Hz electrical outlet (Fig. 1). Plug the battery charger into the outlet and make sure the green LED indicator light (5) comes ON.
  • Page 14: Installing A Battery On The Drill

    ASSEMBLY AND OPERATING INSTALLING A BATTERY ON THE DRILL Remove the discharged battery (1) from the drill by pressing downward on the battery release button (2) and sliding the battery backward until it is removed from the drill handle (3) (Fig. 3). Slide the fully charged battery onto the matching keys (4) in the drill handle where the discharged battery has been removed.
  • Page 15: Forward/Reverse Switch

    1239-221 ASSEMBLY AND OPERATING (continued) FORWARD / REVERSE SWITCH The forward/reverse switch (1) is conveniently mounted above the trigger switch (2) (Fig. 6). To make the drill rotate clockwise (for drilling) push the forward/reverse switch to the left. To make the drill rotate counterclockwise for removing screws, push the forward/reverse switch to the right.
  • Page 16: Installing Drill Bits

    ASSEMBLY AND OPERATING (continued) INSTALLING DRILL BITS WARNING: Never hold the chuck body with one hand and use the drill power to rotate the drill body to loosen or tighten bits. Serious injury may result. This drill is equipped with a single sleeve keyless chuck. To open the keyless drill chuck, grasp and hold the chuck collar (1) with one hand (Fig.
  • Page 17: Drilling

    1239-221 ASSEMBLY AND OPERATING (continued) DRILLING When drilling into smooth, hard surfaces such as metal, use a center punch to mark the started. The workpiece to be drilled should be secured in a vice or with clamps to keep it from turning as the drill bit rotates (Fig.
  • Page 18: Driving Screws

    ASSEMBLY AND OPERATING (continued) DRIVING SCREWS Select the correct screwdriver bit for the screw being driven. gripped by the chuck jaws. Set the torque clutch to the appropriate setting, based on the list on Page 13. NOTE: If the workpiece material is particularly soft or porous, set the torque clutch to a lower setting to avoid overdriving the screw.
  • Page 19: Retightening A Loose Chuck

    1239-221 ASSEMBLY AND OPERATING (continued) RETIGHTENING A LOOSE CHUCK Remove the battery pack from the drill. Insert a ” (8 mm) or larger hex key (1) into the chuck (2) and tighten the chuck jaws securely (Fig. 16). Make sure each surfaces of the hex key.
  • Page 20: Battery Pack Removal And Preparation For Recycling

    Lithium-ion rechargeable batteries generally provide superior performance to nickel-cadmium batteries when used in power tools.  Faster charges  Longer battery life  More power  Lighter weight Lithium-ion batteries perform best and deliver peak output power at room temperature (20°...
  • Page 21 1239-221 PARTS EXPLODED DIAGRAM...
  • Page 22 Key # Part # Part Name Quantity 4020030021 Chuck screw M5x20 1140020049 Chuck 4030010248 Tapping screw ST2.9x14 2020210007 Compressing plate 2050070059 Positioning spring 3120080141 Torque setting ring 3150190130 Inner threaded ring 2050080148 Spring 2030020251 Washer 1 1 0 0 4110030023 Needle roller 1 1 1 1 4080040002...
  • Page 23: Warranty

    WARRANTY RADLEY CORDLESS DRILL WARRANTY If this Radley Tool fails due to a defect in material or workmanship within one year from the date of purchase, return it to any Home Hardware store with the original bill of sale for exchange. This warranty does not include expendable parts including but not limited to blades, brushes, belts, light bulbs and/or batteries.
  • Page 24 EXCLUSIVE TO HOME HARDWARE For information on the entire line-up of Radley power tools visit homehardware.ca or your local Home Hardware retail store. MADE IN CHINA / FABRIQUÉ EN CHINE HOME HARDWARE STORES LIMITED ST. JACOBS, ONTARIO N0B 2N0 ORDER ONLINE / COMMANDE EN LIGNE 1239-221 ©...
