- Page 1 4V CORDLESS SCREWDRIVER KIT OWNER’S MANUAL 1 Year Limited Warranty on tool 3160002 WEAR CSA APPROVED WEAR EAR WEAR FACE EYE PROTECTION PROTECTION PROTECTION...
-
Page 2: Table Of Contents
TABLE OF CONTENTS General Power Tool Safety Warnings ................2-3 Screwdriver Safety Warnings ..................4-5 Safety Rules for Charger ....................5-6 Symbols ..........................7 Assembly ..........................8 Operation ..........................8-10 Maintenance ......................... 11 Exploded View ........................12 Parts List ..........................13 Warranty ..........................14 WARNING To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. -
Page 3: General Power Tool Safety Warnings
1248-203 4V CORDLESS SCREWDRIVER KIT GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. - Page 4 • Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. • Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 5: Screwdriver Safety Warnings
1248-203 4V CORDLESS SCREWDRIVER KIT • Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire. • When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. -
Page 6: Safety Rules For Charger
• Batteries can explode in the presence of a source of ignition, such as a pilot light. To reduce the risk of serious personal injury, never use any cordless product in the presence of open flame. An exploded battery can propel debris and chemicals. If exposed, flush with water immediately. - Page 7 1248-203 4V CORDLESS SCREWDRIVER KIT Cord Length (Feet) 50’ 100' Cord Size (AWG) NOTE: AWG = American Wire Gauge • Do not operate charger with a damaged cord or plug, which could cause shorting and electric shock. If damaged, have the charger replaced by an authorized serviceman.
-
Page 8: Symbols
SYMBOL MEANING Indicates a hazardous situation, which, if not avoided, will result in death or serious injury. Indicates a hazardous situation, which, if not avoided, could result in death or serious injury. Indicates a hazardous situation, that, if not avoided, may result in minor or moderate injury. -
Page 9: Assembly
1248-203 4V CORDLESS SCREWDRIVER KIT ASSEMBLY WARNING Do not use this product if it is not completely assembled or if any parts appear to be missing or damaged. Use of a product that is not properly and completely assembled or with damaged or missing parts could result in serious personal injury. - Page 10 TO CHARGE When charging the screwdriver, a red charge light will Illuminate solid on the handle of the USB Charging port screwdriver. This red charge light will turn off and the green light up and keep illumining when the screwdriver is fully charged. •...
- Page 11 1248-203 4V CORDLESS SCREWDRIVER KIT Driving and removing screws Your tool is equipped with a two-way switch that allows changing the chuck’s rotation direction. 1. Clockwise rotation, press the forward switch. 2. Counter clockwise rotation, press the reverse switch. 3. To stop the rotation, just release the switch.
-
Page 12: Maintenance
MAINTENANCE GENERAL MAINTENANCE Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust, oil, grease, etc. Regularly clean the machine housing with a soft cloth, preferably after each use. -
Page 13: Exploded View
1248-203 4V CORDLESS SCREWDRIVER KIT EXPLODED VIEW... -
Page 14: Parts List
PARTS LIST WARNING: When servicing, use only original equipment replacement parts. The use of any other parts may create a safety hazard or cause damage to the Wet/Dry Vacuum. Any attempt to repair or replace electrical parts on this Wet/Dry Vacuum may create a safety hazard unless repairs are performed by a qualified technician. -
Page 15: Warranty
WARRANTY 4V LITHIUM-ION SCREWDRIVER If this Radley Tool fails due to a defect in material or workmanship within one year from the date of purchase, return to any Home Hardware store with the original bill of sale for exchange. This warranty does not include expendable parts including but not limited to blades, brushes, belts and light bulbs. - Page 16 © 2021 Home Hardware Stores Limited Made in China 1-833-818-4111 Customer Service/Tech Support This Radley® product carries a one (1) year LIMITED warranty against defects in workmanship and materials. See Owner’s Manual for full details. READ ALL INSTRUCTIONS BEFORE FIRST USE.
