never be attached to an electrically "live" terminal. (See Figure A.)
3. Your product must be plugged into an appropriate outlet, properly installed and grounded in
accordance with all codes and ordinances. The plug and outlet should look like those in the
following illustration. (See Figure A.)
1. Grounded tools require a three wire extension cord. Double Insulated tools can use either a
two or three wire extension cord.
2.
As the distance from the supply outlet increases, you must use a heavier gauge extension
cord. Using extension cords with inadequately sized wire causes a serious drop in voltage,
resulting in loss of power and possible product damage.
3. The smaller the gauges number of the wire, the greater the capacity of the cord. For example,
a 14 gauge cord can carry a higher current than a 16 gauge cord.
4. When using more than one extension cord to make up the total length, make sure each cord
contains at least the minimum wire size required.
5. If you are using one extension cord for more than one product, add the name plate amperes
and use the sum to determine the required minimum cord size.
6. If you are using an extension cord outdoors, make sure it is marked with words to indicate it is
acceptable for outdoor use.
7. Make sure your extension cord is properly wired and in good electrical condition. Always
replace a damaged extension cord or have it repaired by a qualified electrician before using it.
8. Protect your extension cords from sharp objects, excessive heat, and damp or wet areas.
When unpacking. Check to make sure all the parts shown on the Parts List are included.
ASSEMBLY AND OPERATING INSTRUCTIONS
CAUTION:
Always make sure the Power Cord of the 3-SPEED AIR CLEANER is unplugged
from its electrical outlet prior to making any adjustments to the product.
1. Locate the desired ceiling location and ceiling joists, upon which to attach the 3-SPEED AIR
CLEANER.
2.
With assistance or lifting equipment (not included), raise the unit to the desired location.
Caution: Make sure other people or pets are well clear of the area during this procedure.
3. Align the four Eye Bolts (30) with the ceiling joists and measure for eyelet bolt location. Insert
four eyelet bolts (28) through the ceiling into the underside of the ceiling joists.
Note: The eyelet bolts must be capable of supporting the weight of the Air Filtration System,
and be of compatible size with the Eye Bolt (30). When hanging 6 the unit, make sure each
EXTENSION CORDS
UNPAKCING
5
