Blaupunkt BLA-32/138Q-GB-11B4-EGPF Setup Manual

BLA/QSW/0046
Technical Specifi cation
Energy Effi ciency Class (SDR)
Power consumption (SDR)
Screen resolution (pixels)
Screen Size (diagonal
RF
Inputs
1 x Mini AV IN - Composite Video/CVBS and L/R Audio shared for Composite
Sound Outputs 1 x Digital Optical Audio output, 1 x 3.5mm Headphone
Speaker* / Amplifi er Watts (RMS)
Voltage and power consumption
Dimensions including stand (mm)
Net weight (Kgs)
Wall Mounting
*Built-in JBL speaker systems (Full-range and tweeter).
JBL is trademark of HARMAN International The terms HDMI, HDMI High-Defi nition
Industries, Incorporated, registered in the Multimedia Interface, and the HDMI Logo
United States and/or other countries. are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc.
BLA-32/138Q-GB-11B4-EGPF
F
31 W
1366 x 768
81 cm / 32 inches
75 ohm Antenna / Analog / DVB / Satellite
3 x HDMI, 2 x USB,
1 x RJ45 LAN/Ethernet, 1 x Mini Component/YPbPr,
Video and Component/YPbPr
2 x 10 / 2 x 8
AC 220V~240V; 50Hz
31/45/70 W
(ecomode/standard/max)
732 W x 467 H x 157 D
5.3
VESA 200 x 200 (mm)
Manufactured under license from Dolby
Laboratories. Dolby, Dolby Audio, and the
double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
Quick Start Set Up Guide
For information on using the TV's features, please refer to the operating Instructions.
Model Numbers
BLA-32/138Q-GB-11B4-EGPF
Quick & easy guide for setting up your TV

What is included in the box

Using the remote control

Setting up the TV for the fi rst time - including attaching the stand

Connecting other devices to the Television

Need help setting up or using your TV?
Please contact the UK & ROI Helpline*
Telephone UK 0330 024 0803 or ROI 01443 3323
Online support at: www.umc-uk.co.uk
Email support at: service@umc-uk.co.uk
*Calls to 0330 numbers are charged at standard call rates and are included as
part of any bundled minutes with your phone provider.
Calls to the ROI number are charged at the local call rate.
The telephone opening hours are:
Monday to Friday: 8.30am – 6pm
Saturday: 9am – 5pm
Bank Holidays: 10am – 4pm
Closed Christmas and New Years day.
Register For Your
Manufacturers Warranty
Register your manufacturers guarantee online within 14 days
of purchase at www.registertv.co.uk/blaupunkt
