Quick Installation Guide NO: G03-JC38AZ02QIG-F Rev: 1.0 Release Date: 2022-02-11 Notice: The photos in this file are for illustration purpose only. The model may not be the latest version. Please refer to the product you purchased for actual specification.
Page 3
Dimension and Outlines: I. To Dissemble the Chassis 1. Put the system upon a stable platform with this side up, as the photo shows.
Page 4
2. Locate the screws at the spots marked on this cover and unscrew them one by one to open the chassis. 3. Remove the screw in the marked spot on front panel. 4. Remove the screw in the marked spot on rear panel.
Page 5
5. Lift the cover up to open the chassis. 6. The overview of the internal layout of the system.
Page 6
II. To Install SO-DIMM to the Board 1. Locate the SO-DIMM slots on the board. 2. Insert the gold-figure side of the compatible SO-DIMM into the slot at a 30 degree angle. See to it that the break of the module fit into the notch of the slot. 3.
Page 7
III. To Install M.2 E-key (2230) PCIe Card 1. Locate the M.2 E-Key, type-2230 slot on the board. 2. Remove the marked screw with a screwdriver. 3. Insert the gold-figure side of compatible M.2 PCIe card into the slot until the golden finger side fully emerged into the slot.
Page 8
4. Install the screw back to the original spot. 5. Locate the reserved antenna holes on the rear panel. Remove the dust-proof plugs on the marked spots from the panel to install the antenna. 6. Push this antenna screw head into antenna hole of the rear panel from the backside of the panel.
Page 9
The washer ① & the hexagonal screw nut ②. Push the washer ① through the antenna head. 7. And then lock the antenna screw head to the front side of the rear panel with the hexagonal screw nut② and tighten it up. 8.
Page 10
9. Repeat step 6 to 8, to finish installation of the other antenna. 10. Connect the external Wi-Fi receiver antenna to the antenna screw head on the rear panel. IV. To Install M.2 M-key (2242/2280) SATA Card 1. Locate the M.2 SATA slot on the board. System supports two types of M.2 M-Key card in different lengths (2280/2242).
Page 11
2. Remove the marked screw with a screwdriver. 3. Insert compatible M.2 M-Key, type-2280 card into the slot. See to it that the golden-finger side should be fully plugged into the slot. 4. Install the screw back to the original spot.
Page 12
Note: The screw post and nut fixed at location MH4 by default for 8cm type-2280 card installation. If you wish to install type-2242 card, please remove corresponding screw post under the screw as well and lock the screw post into location MH3 before installing 4.2 cm card to the slot.
Page 13
3. Insert the gold-figure side of compatible M.2 B-Key, type-3052 card into the slot until the golden finger side fully emerged into the slot. 4. Install the screw back to the original spot. *Note: 1. The screw post and nut fixed at location MH2 by default for 5.2cm type-3052 card installation. The screw post nut fixed at location MH1 is reserved for either M.2 E-key type-2230 card or M.2 B-key type-3042 card installation;...
Page 14
VI. To Install Hard Disk 1. Locate HDD racks on the board. 2. Remove the screws in the marked positions with a screwdriver to remove the HDD racks from the board. 3. Lock the SATA hard disk to one rack by tightening the screws in the marked spots. 4.
Page 15
5. Hard disk drive with racks installed. 6. Push compliant HDD with rack installed to corresponding HDD connector onboard and adjust the racks to its original location before installation. 7. Lock the racks to the board by tightening up the screws in the marked spots.
Page 16
VII. To Wall Mount the system 1. Install wall mount rack to the system by tightening the screws in the marked positions. Then lock the other two screws on the other side in the same way. 2. Wall mount the system by tightening two screws in the marked positions. Then tighten up the other two screws in the marked positions on the other rack.
