Name of the Components:

Use of timer:
The heater will be always on when the slide switch is in TIMER position "1".
The heater will be always off when the slide switch is in TIMER position "0".
The timer operates when the slide switch is in TIMER position "
To set the timer, rotate the clock dial clockwise, until the current time is aligned
with the indicator arrow at the centre.
To turn the heater ON, push the corresponding time
s e g m e n t o u t w a r d s f r o m t h e c e n t r e . E a c h s e g m e n t
represents around 15 minutes. For example, if you want the
heater continuously ON for 2 hours, push 8 segments
outwards the centre face.
Assembly instructions:
The heater is packaged with the feet unattached. You must attach them before
operating the heater.
Radiator fins
Plastic handle
Thermostat
knob
Switch
Timer
Cord bracket
Truckle
" .
