YOODA CAMELEO 1Rw Manual

www.sukcesgroup.pl
In order to fully explore available functions of CAMELEO series please take a moment and read this manual before using the device.
CAMELEO transmitters are compatible with all YOODA brand devices.

General information

Radio receiver range is a variable value and can differ from declared values depending on conditions in which device
operates. Possible sources of changes in range are building construction, interference caused by other radio transmitters
etc.

Detailed description

To access P2 programming button, batteries and mounting holes remove front frame.
UP button
STOP button
DOWN button
CAMELEO_1Rw | CAMELEO_2Rw
Single-channel transmitter
(front)
1. Control:
can control single motor,
or a group of up to 20 motors on each channel
2. Range:
200 meters outdoor,
35 meters indoor
3. Battery:
2 x CR2032
4. Power supply:
3 V
5. Dimensions:
80 x 80 x 14 mm
6. Transmitting power:
10 mW
7. Operating temperature:
from 0°C to 50°C
8. Protection degree:
IP 30
Illustrations (from the top):
Fig. 1. 2-channel CAMELEO wall-mounted remote control, white (CAMELEO_2Rw)
Fig. 1. Replacable frames for CAMELEO wall-mounted remotes (colours form left:
pearl, choco, titan, beige, metalic)
P2 programming button
+
Single-channel transmitter
(view after removing front frame)
