How to enable Hotspot Mode on the Shapes
By activating the hotspot mode on the Nanoleaf Shapes, the controller will begin to broadcast its
own wifi, but with no internet connection.
1. Press and hold the rhythm as well as the power for 30 seconds.
2. All 6 buttons on the controller will begin to flash 5 times, indicating that the hotspot
mode has been activated and is being broadcasted.
3. To proceed the pairing process, navigate to the wifi settings on your device. The Shapes
wifi will appear in the list of available networks as Nanoleaf Shapes ####.
4. Tap on the Shapes to connect to its wifi
5. Open the Nanoleaf app > open the menu > navigate to device> tap on plus icon to add
new device> select Shapes.
6. You will find the Shapes as available device listed with a magnifying glass. Selecting the
Shapes will prompt you to input the pairing code of the Shapes and hit done.
7. A confirmation page "Set Up Complete" will appear on the screen, pressing "Next" at the
top right corner leads to the "Name Your Device" page.
8. You can rename the Shapes and hit "Next" at the top right corner which will lead the you
to the last set up page "Configure Your Device" to match the orientation of the Shapes
configuration on screen with the users installation.
9. By clicking "Next" the pairing process has been completed.
Setting Up on Android
TIP: Lay out the design for your Hexagons panels on the floor or table to ensure that each panel
is properly connected to a linker.
Upon opening the Nanoleaf Smarter Series App for the first time, you will be prompted to create
an account. This is used to connect to other applications like Amazon Alexa, Google Assistant
and IFTTT. Check out our integrations page for more information on this.
Arrange the Hexagons panels such that each is able to connect to at least one adjacent panel. Use
the
Layout Assistant
Ensure that at least one power supply is used per every 21 Hexagons. If you are setting up a
larger layout (greater than 20 Hexagons).
to verify the layout and map out where to place your panels.
Advertisement
Table of Contents
Related Manuals for Nanoleaf Shapes
Summary of Contents for Nanoleaf Shapes
- Page 1 “Name Your Device” page. 8. You can rename the Shapes and hit “Next” at the top right corner which will lead the you to the last set up page “Configure Your Device” to match the orientation of the Shapes configuration on screen with the users installation.
- Page 2 Once the Hexagons is cycling through colours, the power button LED will remain on and steady - this indicates that the Hexagons is ready to be paired to your mobile device. Start by pressing the Start Pairing button in the app. Select the network that you want to connect the Hexagons to (Note: this must be a 2.4GHz network).
- Page 3 Scan (or manually enter) the HomeKit Setup Code (QR code). The app will begin searching for the accessory to add. When the pairing is complete the Hexagons will flash green. Then, the panels will flash white to indicate that they have been identified by the app. The Add Accessory window will pop up to accommodate renaming the device.
