  • Page 1 ’ OWNER S AND OPERATOR S MANUAL LED Balloon Light Tower SBL750L-M CAUTION Do not operate the Light Tower, or any other appliance, before you have read and understood the instructions for use and keep near for ready use. SBL750L-M...
  • Page 3 Introduction Thank you for purchasing this Shindaiwa LED Balloon Light Tower. • This manual has been created to ensure safe usage of this Light Tower. Be sure to read this manual before operation. Improper operation/handling of this Light Tower will result in an accident or malfunction.

  • Page 4: Table Of Contents

    Table of Contents 1. Safety Precautions ························································ 2 2. Specifications ······························································ 4 3. Applications ································································ 5 4. Part Names ·································································· 5 5. Operating Procedures ··················································· 6 5-1. Using the Lamp Fitting ··············································· 6 5-2. Lifting/Lowering the Mast ············································ 7 6. Assembly at Purchase ··················································· 8 6-1.

  • Page 5: Safety Precautions

    1. Safety Precautions WARNING: TIPPING OVER  Always be sure to install this SBL750L-M Light Tower to Generator/Trailer set before use.  Lower the mast if using in strong wind that causes the lamp fitting to sway severely.  Although the mast can withstand wind speeds up to 15 m/s when the mast is completely extended (with the balloon standing vertically), the balloon fabric can be deformed in wind speeds of 12 to 14 m/s and entangled in the lamp guard.
  • Page 6  Locations of Warning/Caution labels Replace warning and caution labels with new ones if they become damaged and difficult to read. Order labels by using the part number indicated in parenthesis below. 1 CAUTION: BURN (Never touch near here) ( Part no. X505-007640 ) ...

  • Page 7: Specifications

    2. Specifications Model SBL750L-M Rated Voltage (V) 115/120 Single phase Rated Frequency (Hz) 50/60 Rated Consumed Power (W) Rated Consumed Power of Compatible Lights (W) Type Consumed Power (W) x Amount (Lights) Total Flux (lm) 110,000 Type AC axial current...

  • Page 8: Applications

    3. Applications  Various lighting applications 4. Part Names Balloon Fabric LED Lamp Fitting Unit Velcro Lamp Fitting Base Rotating Handle Tilting Handle Lamp Fitting Lever Mast Pulley Cover ＜LED Lamp Fitting Unit＞ LED Part Details LED Plate Lamp Guard LED Tip (16 pieces) LED Mounting Stay Connector...

  • Page 9: Operating Procedures

    5. Operating Procedures 5-1. Using the Lamp Fitting WARNING: ELECTRIC SHOCK  Do not touch this Light Tower during operation if it or your body is wet. CAUTION: INJURY  To change the direction of the lamp fitting, hold the lamp fitting lever with one hand and support the lamp fitting while loosening the fixing handles (rotation and tilt handles).

  • Page 10: Lifting/Lowering The Mast

    (3) Turning the LED Lamp ON/OFF <Note> When the rated voltage is supplied, the fan rotates and the balloon is inflated regardless of the power unit toggle switch position ("OFF" or "ON"). Conversely, the fan is stopped and the balloon is deflated if the rated voltage is turned off. 1 Turn ON Control Panel Part Move the toggle switch on the control panel of the...

  • Page 11: Assembly At Purchase

    6. Assembly at Purchase Although the outer cover is fitted to the LED balloon lamp fitting when shipped from the factory, the internal balloon fabric is not installed. Perform the following procedures to install. 6-1. Removing the Lamp Fitting Cover Place the lamp fitting horizontally and secure it.

  • Page 12: Installing The Balloon Fabric

    6-2. Installing the Internal Balloon Fabric Open the zipper on the balloon fabric side surface. Lamp Guard Insert three fabric bands into balloon fabric through the openings of lamp guard and snap the buttons. Be sure to match the numbers Fabric Band No.

  • Page 13: Operating Procedures (Light Tower)

    7. Operating Procedures (Light Tower) WARNING: TIPPING OVER  Always be sure to install this SBL750L-M Light Tower to Generator/Trailer set before use.  Lower the mast if using in strong wind that causes the lamp fitting to sway severely.

  • Page 14: Turning On The Led

    7-1. Turning on the LED Perform a pre-operation inspection before using the LED. (Refer to "10. Inspection/Maintenance".) Remove the lamp fitting cover. Buckle (Refer to "6-1. Removing the Lamp Fitting Cover".) Remove the bundling buckle and securing the balloon fabric. Adjust the lamp fitting direction (vertical angle and rotation).

  • Page 15: Transport Procedures (Moving On A Vehicle)

    8. Transport Procedures (Moving on a Vehicle) WARNING: TIPPING OVER  Always be sure to keep the mast to the lowest position when moving. CAUTION: FIRE  Be careful that the power cord is not caught or pulled when raising or lowering the telescopic mast or transporting the floodlight.

  • Page 16: Inspection/Maintenance

    10. Inspection/Maintenance WARNING: ELECTRIC SHOCK  Do not connect the power cord to the outlet when performing any check or maintenance of the LED and other parts. CAUTION: BURNS  Do not touch the LED, lamp guard when the LED is lit up or immediately after being turned off because they are extremely hot.
  • Page 17 ① ⑤ ③ ⑥ ② ④ ⑫ ⑩ ⑦ ⑭ ⑪ ⑧ ⑨ ⑬ (1) Cleaning the Filter Loosen the four screws securing the filter cover. Screws (4) Filter Cover Remove the filter cover from a direction in Filter which the cord does not exist. Remove the filter and lightly pour in a bucket with water.
  • Page 18 (4)Applying Grease to Pulleys Bolts (2) Mast 1st Stage Remove the two bolts and bolt/nut assembly for Pulley Cover securing the pulley cover. Bolt/Nut Apply the grease specified by Yamabiko (Moly HD リングギヤ Ring Gear grease) to the ring gear located on the side of the winch drum.

  • Page 19: Long-Term Storage

    11. Long-Term Storage WARNING: ELECTRIC SHOCK  Do not connect the power cord to the outlet when performing any check or maintenance of the LED and other parts. CAUTION: BURNS  Do not touch the LED, lamp guard when the LED is lit up or immediately after being turned off as they are extremely hot.

  • Page 20: Troubleshooting

    12. Troubleshooting WARNING: ELECTRIC SHOCK  Do not touch this Light Tower during operation if equipment or your body is wet.  Do not connect the power cord to the outlet when performing any check or maintenance of the LED and other parts. CAUTION: BURNS ...
  • Page 21 ＭＥＭＯ...
  • Page 22 ＭＥＭＯ...
  • Page 23 ＭＥＭＯ...
  • Page 24 © © © © 2019 - 49 -...
