Canon PIXMA iX6520 Series Getting Started page 26

Inkjet business printer
Hide thumbs


Printing resolution (dpi)
9600* (horizontal) X 2400 (vertical)
* Ink droplets can be placed with a pitch of 1/9600 inch at minimum.
USB Port:
Hi-Speed USB*
* A computer that complies with Hi-Speed USB standard is required. Since the Hi-Speed USB interface is fully
upwardly compatible with USB 1.1, it can be used at USB 1.1.
Print width
12.7 inches/322.2 mm
(for Borderless Printing: 13 inches/329 mm)
Operating environment
Temperature: 5 to 35°C (41 to 95°F)
Humidity: 10 to 90% RH (no condensation)
Storage environment
Temperature: 0 to 40°C (32 to 104°F)
Humidity: 5 to 95% RH (no condensation)
Power supply
AC 100-240 V, 50/60 Hz
Power consumption
Printing: Approx. 20 W
Standby (minimum): Approx. 1.3 W *1*2
OFF: Approx. 0.5 W *1
*1 USB connection to PC
*2 The wait time for standby cannot be changed.
External dimensions
Approx. 21.7 (W) X 11.8 (D) X 6.3 (H) inches
Approx. 549 (W) X 299 (D) X 159 (H) mm
* With the Paper Support and Paper Output Tray retracted.
Approx. 7.6 kg (Approx. 16.7 lb)
* With the Print Head and ink tanks installed.
Print Head/Ink
Total 4608 nozzles (PgBK 512 nozzles, Y/DyeBK each 512 nozzles, C/M each 1536 nozzles)

General Specifications
Minimum System Requirements
Conform to the operating system's requirements when higher than those given here.
Operating System/Processor/RAM
Windows 7
1 GHz or faster 32-bit (x86) or 64-bit (x64) processor
1 GB (32-bit)/2 GB (64-bit)
Windows Vista, Vista SP1, Vista SP2
1 GHz processor
512 MB
Windows XP SP2, SP3
300 MHz processor
128 MB
Internet Explorer 6 or later
Hard Disk Space
1.5 GB
Note: For bundled software installation.
The necessary amount of hard disk space may be
changed without notice.
CD-ROM Drive
SVGA 800 x 600
Windows: Operation can only be guaranteed on a PC with Windows 7, Windows Vista or Windows XP pre-
Windows: Uninstall software bundled with the Canon inkjet printer before upgrading from Windows Vista to
Windows 7, then, install the bundled software again.
Macintosh: Hard Disk must be formatted as Mac OS Extended (Journaled) or Mac OS Extended.
Macintosh: After upgrading from Mac OS X v.10.5 or lower to Mac OS X v.10.6, install software bundled with the
Canon inkjet printer.
Internet Explorer 7 or later (Windows), or Safari 4 or later (for Mac OS X v.10.5 or later) is required to install
Easy-WebPrint EX.
Specifications are subject to change without notice.
About Consumables
Consumables (ink tanks / FINE Cartridges) are available for 5 years after production has stopped.
Mac OS X v.10.6
Intel processor
1 GB
Mac OS X v.10.5
Intel processor, PowerPC G5, PowerPC G4
(867 MHz or faster)
512 MB
Mac OS X v.10.4.11
Intel processor, PowerPC G5, PowerPC G4, PowerPC
256 MB
Safari 3 or later
1.5 GB
Note: For bundled software installation.
The necessary amount of hard disk space may be
changed without notice.
XGA 1024 x 768
