- Page 1 E-Lock EVO User Manual Please read this manual carefuly before installation and keep if for future refernce...
-
Page 2: External View
721ELOCKG900 Internal view – right External view Internal view – left View from indoors Step 1 Unscrew the four screws of the lock and of the lock strike and remove the correspondent boxes. Loosen the nuts of the lock and of the lock strike and check the side (the standard side is right) - Page 3 Step 2 – Reversibility (from right to left) Unscrew the four screws of the front lock body, remove the box by extracting the cable band. Rotate the glass plate of 180° maintaining the external keyboard in its position. Reposition the cable band and fix the four screws.
- Page 4 Step 6 View from indoors Install the front lock body and fix it using the dedicated nuts. Step 7 View from indoors Connect the back lock body with the frontal one by coupling the “cable band” connector and close the mechanism by rotating the flap.
-
Page 5: System Installation
Step 9 View from indoors Unscrew the front panel to insert the batteries. System installation Open the front panel cover (see step 9), keep the “Reset” button on the back of the panel pressed for 5 seconds, digit “000#” to complete the inizialization. After the reset, the language is English. - Page 6 Recording Android Sistem Apple Sistem...
- Page 8 ℃ ℃...
- Page 9 ： ： ： ： ：...
