Panasonic TC-14Z88KQ Service Manual

Gp3 chassis
Hide thumbs

Advertisement

Quick Links

Download this manual
SPECIFICATIONS
Specifications
Power Source :
Power Consumption :
Aerial Impedance :
Receiving System :
Receiving Channels :
VHF
UHF
CATV
Intermediate Frequency :
Video
Sound
ORDER NO. MTV0401271C3
AC AUTO 110-240V, 50 / 60 Hz
75
unbalanced
Coaxial type
17 Systems
1-11 PAL B (Australia & N.Zealand)
1-12 PAL / SECAM D
1-12 NTSC M JAPAN
2-12 PAL / SECAM B, G
2-13 NTSC M U.S.A.
21-69 PAL G I / SECAM B, G, K1
28-69 PAL G (Australia)
13-56 PAL D
13-52 NTSC M JAPAN
14-69 NTSC NTSC M U.S.A.
S1-S41 (Hyper)
31.5 MHz (D, K, K1)
32 MHz (I)
32.5 MHz (B, G)
1
Colour Television
TC-14Z88KQ
GP3 Chassis
61W
38.0 MHz

Advertisement

loading

Related Manuals for Panasonic TC-14Z88KQ

Summary of Contents for Panasonic TC-14Z88KQ

  • Page 1 ORDER NO. MTV0401271C3 Colour Television TC-14Z88KQ GP3 Chassis SPECIFICATIONS Specifications Power Source : AC AUTO 110-240V, 50 / 60 Hz Power Consumption : Aerial Impedance : unbalanced Coaxial type Receiving System : 17 Systems Receiving Channels : 1-11 PAL B (Australia & N.Zealand)
