- Page 1 Wireless Network Extender Model # WxB6x40Q User Guide 0535-0024-000...
-
Page 2: Table Of Contents
Table of Contents Table of Contents Introduction Features Getting to Know the Extender Front Panel Back Panel Installing the Extender Syncing Wi-Fi Connecting the Extender Accessing the Extender’s GUI Status Wireless Setup MoCA Setup (Optional) Advanced Setup Specifications Notices Warranty... - Page 3 WxB6x40Q Wireless Network Extender Important Safety Instructions FCC Class B Equipment Important Note on Wi-Fi Contact Information Technical Support...
-
Page 4: Introduction
Introduction The Actiontec WxB6x40Q is a wireless network extender with dual concurrent radios supporting both 2.4GHz and 5GHz operation in 802.11 a/b/g/n, and also 5GHz in 802.11ac. This allows the Extender to connect to everything from legacy wireless laptops, computers, and gaming platforms, up to the most current (and future) Apple and Android tablets, laptops, media platforms, and smartphones. -
Page 5: Features
WxB6x40Q Wireless Network Extender Features • Fast 802.11ac/n Wi-Fi wherever you need it • Upgrade to 802.11ac speeds without replacing your router • Dual band concurrent radio for wireless throughput up to 2 Gbps • 4x4 802.11ac 5 GHz solution •... -
Page 6: Getting To Know The Extender
Getting to Know the Extender This chapter describes the location and uses of the Extender’s LEDs, ports, and buttons. Front Panel The front panel features LEDs that illuminate green when power, available ports, and/or wireless bands are functioning and in use. Power 2.4GHz radio 5 GHz radio... -
Page 7: Back Panel
Back Panel • Power port: used to connect the power adapter (external, 12V DC, 2A, made by Actiontec, model #NBS24J120200VU) to the Extender. • Reset button: restores the Extender back to the original factory default settings when held down for at least 10 seconds. -
Page 8: Installing The Extender
Getting to Know the Extender Installing the Extender There are two parts to installing an Extender: syncing the Wi-Fi settings, and placing and connecting the Extender. Syncing Wi-Fi To sync the Extender with the gateway/modem’s Wi-Fi settings: 1. Place the Extender next to the gateway/modem. 2. -
Page 9: Connecting The Extender
WxB6x40Q Wireless Network Extender The Extender is now synced with the gateway/modem’s Wi-Fi settings. Unplug the Extender and its power cable. Connecting the Extender Now that the Extender is synced with the gateway/modem’s wireless network, it can be connected to the gateway/modem’s MoCA or Ethernet network .To do this: 1. -
Page 10: Accessing The Extender's Gui
Accessing the Extender’s GUI The Extender features an onboard graphical user interface (GUI) that includes user-configurable settings. Some of these settings should be accessed by experienced network technicians only. To configure the network settings of the Extender: 1. Ensure that the Extender is connected to a gateway/modem’s MoCA coaxial network, and that both devices are powered on. - Page 11 WxB6x40Q Wireless Network Extender 5. Enter the IP address written down in step 4 in the address box of the web browser. 6. The Extender’s Status screen appears. Enter the Extender’s Username and Password (found on the label located on the back panel of the Extender;...
- Page 12 Accessing the Extender’s GUI The Extender’s GUI’s Status screen appears, as shown below. ...
-
Page 13: Status
WxB6x40Q Wireless Network Extender Status The first GUI screen that appears is the Status screen, which can also be generated by clicking the Status icon in the menu bar. This screen contains basic information about the Extender’s wireless status, network stations, and product information about the Extender. -
Page 14: Wireless Setup
Accessing the Extender’s GUI Wireless Setup Clicking the Wireless Setup icon from the menu bar of any of the Extender’s GUI screens generates the Wireless Network List screen. Additional wireless settings can be accessed from the menu on the left side. - Page 15 WxB6x40Q Wireless Network Extender Basic Setup The Basic Setup wireless network screen contains various settings regarding the Extender’s wireless network. When finished adjusting the settings in this screen, click Apply. Multiple SSID This option allows the user to setup different SSIDs (wireless networks) with different parameters.
- Page 16 Accessing the Extender’s GUI SSID Enable This option makes the Extender’s wireless network name visible or not. SSID Broadcast This option controls whether or not the name of the network is broadcast to other wireless devices (usually, in the device’s available wireless network list).
- Page 17 WxB6x40Q Wireless Network Extender Wireless Security Type This option allows the user to select the type of security applied to the Extender’s wireless network. Password Phrase This option allows the user to enter a custom password phrase or value. Wireless Security The Wireless Security screen allows the user to apply wireless security to the Extender’s wireless network.
- Page 18 Accessing the Extender’s GUI The WPS screen allows the Extender to accept wireless clients via Wi-Fi Protected Setup (WPS), an automatic wireless network connection protocol. Only experienced network technicians should configure the settings in this screen. Advanced Wireless Setup The Advanced Wireless Setup screen allows the Extender to be configured with multiple SSIDs.
- Page 19 WxB6x40Q Wireless Network Extender Wireless Access Control The Wireless Access Control screen contains a number of advanced settings regarding the Extender’s wireless network. Only experienced network technicians should configure these settings. ...
-
Page 20: Moca Setup (Optional)
Accessing the Extender’s GUI MoCA Setup (Optional) Clicking the MoCA Setup icon from any of the Extender’s GUI screens generates the MoCA Coax Setup screen. The settings in this screen allow the user to configure various options for the Extender’s coaxial connection. -
Page 21: Advanced Setup
WxB6x40Q Wireless Network Extender Advanced Setup Clicking the Advanced Setup icon from any of the Extender’s GUI screens generates the Management screen, along with other advanced settings accessed through the menu on the left side. These settings configure various administrative aspects of the Extender and its GUI. They should be adjusted by an experienced network technicians only. - Page 22 Accessing the Extender’s GUI Factory Default The Factory Default advanced setup screen allows the Extender’s factory default settings to be reapplied, erasing all current settings. Click Restore Default Settings to restore the Extender to its factory default state. Firmware Restore The Firmware Restore screen lists the active and backup firmware versions available on the Extender.
- Page 23 Enable button to activate, enter the appropriate web address in the Check URL text box, then click Apply. Firmware Upgrade Actiontec periodically posts firmware upgrades that may include enhancements and/or bug fixes for the Extender. To upgrade the Extender’s firmware: 1.
-
Page 24: Specifications
Accessing the Extender’s GUI Specifications Model Number WxB6x40Q Protocol/Standards/Support Wireless IEEE 802.11ac Ethernet IEEE 802.3/802.3u/802.3ab 10/100/1000 Base-T MoCA 1.0/1.1/2.0 (optional) LAN Interfaces Four 10/100/1000 Ethernet One MoCA 2.0 bonded Coaxial Jack (optional) LED Indicators Power, Wi-Fi 2.4 GHz, Wi-Fi 5 GHz Antennas : internal 2.4 GHz ... - Page 25 WxB6x40Q Wireless Network Extender Power Adapter Input 100-240VAC @ 0.6A Output 12Vdc @ 2A Made by Actiontec, model #NBS24J120200VU Regulatory FCC 15B, 15C UL, K.21 Wi-Fi, WPS MoCA RoHS Environmental Operating temperature - 0ºC to 40ºC (32ºF to 104ºF) Storage temperature - 0ºC to 70ºC (32ºF to 158ºF)
-
Page 26: Notices
To the extent that this Limited Warranty Statement is inconsistent with local law, this Statement shall be deemed modified to be consistent with such local law. Under such local law, certain disclaimers and limitations of this Warranty Statement may not apply to the customer. Go to http://www.actiontec.com/products/warranty.php for more information. -
Page 27: Important Safety Instructions
WxB6x40Q Wireless Network Extender Important Safety Instructions Basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and personal injury, including the following: • Do not use this product near water – for example, near a bathtub, kitchen sink, laundry tub, or swimming pool, or in a wet basement;... -
Page 28: Fcc Class B Equipment
Consult the dealer or an experience radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Actiontec Electronics, Inc., may void the user’s authority to operate the equipment. -
Page 29: Important Note On Wi-Fi
WxB6x40Q Wireless Network Extender Declaration of Conformity for Products Marked with the FCC logo This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference; 2. -
Page 30: Contact Information
The transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Contact Information For questions regarding your product or the FCC declaration, contact: Actiontec Electronics, Inc 760 North Mary Avenue, Sunnyvale, CA 94085, United States Tel: (408) 752-7700 Fax: (408) 541-9003... -
Page 31: Technical Support
WxB6x40Q Wireless Network Extender Technical Support Go to www.actiontec.com/support for product support, updates, and more information including: • Firmware updates • Troubleshooting • Registration • FAQs Technical Support Phone Number United States: 1-888-436-0657...
