Structure and function

4.1

FastWheel

The machine is used to guide light into a microscope through adjustable filters. Various
filters are inserted into the FastWheel. A motor controls the rotation of the FastWheel to
bring the filters into the illumination position. An on-site control system is required to operate
the machine. This controls the rotary movement of the FastWheel via an interface.
Furthermore, an external light source and a microscope are required.
NOTE
No laser light source may be used as an illumination source for the Fast-
Wheel. Only light sources that do not pose a risk to the eyes or skin may
be used.
4.2

Operating modes

The FastWheel has two operating modes:
•
Automatic mode
•
Service mode
The operating modes are only possible through the on-site control system.
