- Page 1 ER719 User Manual ER719 User Manual Ordering Information Model No. ER719 Name NFC Reader Writer Interface VCP(HID, RS232,RS485 optional) Phone 86-010-80218328 Email info@ehuoyan.com http://www.ehuoyan.com/ Version 1.0 Page 1 of 11 Apr 2022...
-
Page 2: Special Features
4k, MI FARE 14443A compatible cards. ER719 use USB port to act as a virtual COM port. The proximity operating distance of ER719 is up to 5cm, depending on the type of contactless tag in use. The ER719 is ideal for secure personal identity verification, access control, e-payment, e-ticketing for events and mass transit, toll road fare collection and network authentication. -
Page 3: Typical Applications
ER719 User Manual Dimensions 114 mm (L) x 74 mm (W) x 16 mm (H) Weight 70 g Cable length 1.5m(optional) Color Black( White optional) Interface USB (VCP default, HID/RS232/RS485 Optional) Baud rate 115200 bps (default, 9600-115200bps optional) Operating Distance... -
Page 4: How To Use
Loyalty Program 5. How to use Step1: Connect the cable to the ER719 connector J1(shown on above). Step2: Connect the USB connector to PC( or other smart host device, if RS232 or RS485 interface please reference your host’s connector) USB port( if you use a smart pad or phone, then you may need to use an OTG converter for it) . - Page 5 Step3: Now, you can run the program to send commands to the ER719 (if works on reader mode then you can open a text file to receive the data for test). You can run the eReader.exe or else App(base on the ER719 API) to communicate with the ER719.
- Page 6 ER719 User Manual 6. How to install USB driver? If works on USB interface then the host will install the USB driver itself, just step into the tips on the OS. If works on optional RS232 or RS485 interface then it needs no driver to be installed.
- Page 7 ER719 User Manual the USB driver. On the next picture, please click “next step”. On the next picture, select “I accept this agreement”, next click “next step”. Version 1.0 Page 7 of 11 Apr 2022...
- Page 8 ER719 User Manual On the next picture, click “Finish”, then the USB driver install fully. How to find out which communications port the operating system has assigned to Version 1.0 Page 8 of 11 Apr 2022...
- Page 9 ER719 User Manual the USB driver? Windows XP--- The path is: Start=>Control Panel=>System(you might need to set your Control Panel to ‘Classic View’)=>Hardware=>Device Manager=>Ports(COM & LPT) Windows 7 and above versions--- The path is: Start=>Control Panel=>Device Manager(you might need to set your Control Panel to ‘Classic View’)=>Ports(COM &...
-
Page 10: Troubleshooting
Beep all the time when Reconnect or repower it. power on Can not read the card No card on the ER719 antenna area or the card maybe bad or it is not a supported card. Can read card SN, but You have not the right authenticated keys. -
Page 11: Fcc Statement
ER719 User Manual FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
