EHUOYAN YHY522R User Manual

Smart rfid module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RFID
SMART RFID MODULE

  YHY522R
RFID module
RFID/NFC Reader/Writer Module
User manual
Version 1.0
Dec, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YHY522R and is the answer not in the manual?

Questions and answers

Related Manuals for EHUOYAN YHY522R

Summary of Contents for EHUOYAN YHY522R

  • Page 1 RFID  SMART RFID MODULE      YHY522R    RFID module  RFID/NFC Reader/Writer Module User manual Version 1.0 Dec, 2018...

  • Page 2: Table Of Contents

    10.Digital interface ..........................8 10.2.RS232 interface ......................…….8 10.3.Selection of the transfer speeds ................…….8 10.4.Transfer protocol .....................…….9 10.4.1.Host to YHY522R transfer protocol ............…….9 10.4.2. YHY522R to Host transfer protocol ............…….10 12.Power reduction mode .........................10 12.1.Hard power-down ....................…….11 12.2.Transmitter soft power-down ................…….11 13.Reset ...............................11 14.YHY522R Command set ......................12...
  • Page 3 EHUOYAN YHY522R RFID module 16.Package outline ..........................35 17.Contact information ........................36 Page 3 of 36...

  • Page 4: Introduction

    The digital part handles the complete ISO/IEC 14443A framing and error detection(Parity & CRC). In the master mode, YHY522R will seek the card or data itself and output to host automatically. In the slave mode, the module just needs only one command to finish one action, such as read or write data from card’s block.

  • Page 5: Application Information

    & attendance, biometrics, IT-access, Identify, loyalty, Counter, data storage and fast data collection systems. Figure 1. YHY522R Applications 5. Quick reference data _____________________________ Table 1: Quick reference data...

  • Page 6: Block Diagram

    YHY522R YPHDR9-5 7. Block diagram _ _____________________________ Figure 2. Simplified YHY522R Block diagram The Analog circuitry and MFRC522 handle the modulation and demodulation RFID signal. The MCU handles the protocol requirements for the communication schemes including the RF base protocols as well as the protocols for host communication.

  • Page 7: Pin Description

    J1-4 J1-5 Reset, active-low, floating for power-on reset by default J1-6 RS232 Transmitter J1-7 RS232 Receiver J1-8 Power supply J1-9 Power supply Ground 9. Functional description _____________________________ YHY522R supports the Reader/Writer mode for ISO/IEC 14443A/MIFARE card. Page 7 of 36...

  • Page 8: Digital Interface

    10.1 RS232 Interface HOST YHY522 Figure 5 – YHY522R RS232 interface to host 10.3 Slection of the transfer speeds The default transfer speed is 19.2 kbit/s. To change the transfer speed, the host controller has to write a value for the new transfer speed by the CONFIG command, after reset the module, the new speed will active.

  • Page 9: Host To Yhy522R Transfer Protocol

    EHUOYAN YHY522R RFID module The original setting for the host and YHY522R communicates at 19200bps, N, 8, 1. In the slave mode, the host first sends the command and the module executes the operation and replies with a response to the command. The host can analyze the reply to check if the operation was successful or if any error occurred during the operation.

  • Page 10: Power Reduction Mode

    12.1 Hard Power-down A Hard Power-down is enabled with sending command 0x03 to the YHY522R . This turns off all internal current sinks as well as the oscillator. All digital input buffers are separated from the input pads and clamped internally.

  • Page 11: Yhy522R Command Set

    Figure 7– Reset timing 14. YHY522R Command Set ___ ____________________ 14.1 Commands overview The commands for the YHY522R include system commands and RFID commands. The system commands are use for controling the module settings and save parameters to the EEPROM.

  • Page 12: Commands And Response

    0x41 Ntag_Write_Text Write NFC text into NTAG chip 14.2 Commands and Response After power on or reset YHY522R , the RED led will flash one time, It means that YHY522R is ready. ® If a Mifare tag detected by the module, pin IRQ will change from “1” to “0”...

  • Page 13: Msleep

    AA BB Head Length Description Error 14.2.2 MSleep After executing this Command the YHY522R will power down, waking up the module it needs to give the RST pin a low-level pulse or Re-power on the module. Table 12. Command--:Host YHY522R Data...

  • Page 14: Mconfigure

    D[0]:Auto code ----- 0—Auto function off ,the YHY522R will not auto seek card and the IRQ pin is not active. 1—Auto seek card, if there are cards in the RF field, the RED led will light and IRQ pin will output low level.
  • Page 15 Description Error If success then reset the YHY522R to active this function. The reader will read the card id itself when there is a card into the RF field and then output the id to host, at the same time the buzzer would beep one time if it is connecting to a buzzer.
  • Page 16 01: Auth mode 1 08: Baud code,115200bps If success then reset the YHY522R to active this function. The reader will read the card block itself when there is a card into the RF field and then output the block data to host, at the same time the buzzer would beep one time if it is connecting to a buzzer.

  • Page 17: Download_Keys

    14.2.4 Download_Keys This command can load up to 40 groups keys to the YHY522R ’s EEPROM, all the data stored in the EEPROM is encrypted. When auth mode is 1, the reader will use the EEPROM’s key to auth the card. After reset this keys will active.

  • Page 18: Sense_Mode

    Auto code:1Byte Auto code ----- 0—Auto function off ,the YHY522R will not auto seek card and the IRQ pin is not active. 1—Auto seek card, if there are cards the RED led will light and IRQ pin output low level.

  • Page 19: Change_Card_Keys

    Access bits: 4 bytes---‘ FF 07 80 69’ Key B: 6 bytes ----default ‘FF FF FF FF FF FF’ (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 46. Response--: YHY522R Host Receive...

  • Page 20: Card_Sleep

    This command sets the Card into sleeping. After successfully operation the card will be halt. Reactivate the card need to remove the card from antenna area and put the card into antenna area again. Or reset the YHY522R to repower the card. Table 51. Command--:Host YHY522R...

  • Page 21: Card_Type

    This command reads card type. Table 54. Command--:Host YHY522R Data Header Length Command XOR Checksum Send 0xAA 0xBB 0x02 0x19 0x1B Table 55. Response--: YHY522R Host Receive Head Length Status Data XOR Checksum Card type: Success 0xAA 0xBB 0x04 0x19...

  • Page 22: Block_Read

    Key type: 1 byte, 0x00—Key A, 0x01—Key B. Block number: 1 byte, 0x00..0xff (0..255) Key: 6 bytes, default “FFFFFFFFFFFF” (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 61. Response--: YHY522R Host Receive Head...

  • Page 23: Block_Write

    Key: 6 bytes, default “FFFFFFFFFFFF” BData: 16 bytes data to be write into card (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 64. Response--: YHY522R Host Receive Head...

  • Page 24: Value_Init

    EHUOYAN YHY522R RFID module AA BB Head Length Description Status AA BB 02 DD DF Receive(Failure) AA BB Head Length Description Error *If write one block data include ‘AA’, then the ‘00’ will be added behind ‘AA’, but the length does not add 1.

  • Page 25: Value_Read

    Key: 6 bytes, default “FFFFFFFFFFFF” (*) Value: 4 bytes value to be write into card, low byte first (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 67. Response--: YHY522R Host Receive...

  • Page 26: Value_Inc

    Key: 6 bytes, default “FFFFFFFFFFFF” (*) Value: 4 bytes value to increment, low byte first (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 72. Response--: YHY522R Host Receive...

  • Page 27: Value_Dec

    Key: 6 bytes, default “FFFFFFFFFFFF” (*) Value: 4 bytes value to decrement, low byte first (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 75. Response--: YHY522R Host Receive...

  • Page 28: Value_Backup

    Key: 6 bytes, default “FFFFFFFFFFFF” (*) Source block: 1 byte Target block: 1 byte (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 78. Response--: YHY522R Host Receive Head...

  • Page 29: Sector_Read

    Key type: 1 byte, 0x00—Key A, 0x01—Key B. Sector number: 1 byte, 0x00..0x1F (0..31) Key: 6 bytes, default “FFFFFFFFFFFF” (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 81. Response--: YHY522R Host Receive Head...

  • Page 30: Sector_Write

    Key: 6 bytes, default “FFFFFFFFFFFF” SData: 48 Bytes data to be write into card (*)Note: If auth mode is “1”, then this key is not active, it can be any 6 data bytes. Table 84. Response--: YHY522R Host Receive Head...
  • Page 31 This command reads 4 continuous pages data from the appointed start page. Table 86. Command--:Host YHY522R Data Header Length Command XOR Checksum Send 0xAA 0xBB 0x03 0x28 Start page Table 87. Response--: YHY522R Host Receive Head Length Status Data XOR Checksum 4 pages data: Success 0xAA 0xBB 0x12 0x28 16Bytes...
  • Page 32 EHUOYAN YHY522R RFID module Page Info: 0xAA 0xBB 0x07 0x29 5 bytes Page Info: 1byte(page address)+4 bytes data Table 90. Response--: YHY522R Host Receive Head Length Status Data XOR Checksum Success 0xAA 0xBB 0x02 0x29 0x2B Failure 0xAA 0xBB 0x02...
  • Page 33 0xAA 0xBB Len1 0x41 Data Data=Lock+Len2+Text Lock: 00-rewrite, 01-Lock(read only) Len2: length of the text, up to 58 bytes； Text: NFC NDEF ascii code. ------------------------------------------------------------------- Table 96. Response--: YHY522R Host Receive Head Length Status Data XOR Checksum Success 0xAA 0xBB...

  • Page 34: Electrial Characteristics

    EHUOYAN YHY522R RFID module AA BB 02 BE BC Receive(Failure) AA BB Head Length Description Error -------------------------------------------------------------------- ____________________ 15. Electrical Characteristics 15.1 Operating Condition Table 86: Operating Condition Range SYMBOL PARAMETER CONDITIONS UNIT Ambient Tamb °C Temperature DC Supply GND = 0V...
  • Page 35 EHUOYAN YHY522R RFID module Figure 8– YHY522R Top view Page 35 of 36...
  • Page 36 Figure 9– YHY522R Side View Figure 10– YHY522R Back side View ------------------------------------------------------------------------------------------------------------------------------------------ ___ _____________________ 17. Contact information To obtain information about EHUOYAN sales and technical information, please reference the following information. Contact Information: Ehuoyan Technology Co.,Ltd. Tel: +86-010-80128328 email: info@ehuoyan.com Web Site : http://www.ehuoyan.com/...
