- Page 1 ER303 User Manual ER303 Manual Ordering Information Model No. ER303 Name Blue Tooth NFC Reader Phone 86-010-80128328 Email info@ehuoyan.com http://www.ehuoyan.com/ Version 1.0.0 Page 1 of 10 July 2017...
- Page 2 ER303 use Blue Tooth to communicate with the host which has Blue Tooth BLE. For example Smart Phone, PAD, and PC which has BLE component. The proximity operating distance of ER303 is up to 6 cm, depending on the type of contactless tag in use.
-
Page 3: Typical Applications
ER303 User Manual Dimensions 120 mm (L) x 80 mm (W) x 16 mm (H) Weight 110 g Cable length 1.5m Color white Interface Blue Tooth BLE Baud rate 9600 bps (default) Operating Distance Up to 6 cm (depends on the tag type) -
Page 4: How To Use
Blue Tooth BLE test. Open the blue tooth switch on your smart phone or PAD. Open the app and you will find some BLE Peripherals Nearby. Select “EHUOYAN R1” to match this reader. Version 1.0.0 Page 4 of 10... - Page 5 ER303 User Manual If the match ok, then it will show “Connected”. Version 1.0.0 Page 5 of 10 July 2017...
- Page 6 ER303 User Manual Step3: On the next picture, select “Listen for notifications”, then the smart phone will ready for receive the data from this NFC reader. Version 1.0.0 Page 6 of 10 July 2017...
- Page 7 ER303 User Manual Step4: Put on one card or tag on the reader, you will hear a sound and the led will flash one time. Version 1.0.0 Page 7 of 10 July 2017...
- Page 8 ER303 User Manual Then you can see the data transfer to the smart phone. Version 1.0.0 Page 8 of 10 July 2017...
-
Page 9: Troubleshooting
ER303 User Manual Note: For more detail about the received data please reference the manual for the programmer. 6. Troubleshooting fault solution No sound when power on If the blue led is not light, plug the USB again or plug it into another USB power. - Page 10 ER303 User Manual Contact Information: EHUOYAN Technology Co., Ltd. Tel: +86 -010-80128328 Email: info@ehuoyan.com Web Site: www.ehuoyan.com Version 1.0.0 Page 10 of 10 July 2017...
