MULTIMEDIA RECEIVER
Wireless Apple CarPlay & Android Auto
USER MANUAL
Android Auto and Apple CarPlay is not owned or controlled by any car manufacturer and are not
responsible for the privacy practices of third parties or the terms and conditions under which they offer
such products. We strongly encourage you to read the Android Auto or Apple CarPlay privacy policies
and terms and conditions to make sure they are acceptable to you.
INCLUSIONS: Head unit, GPS antenna, microphone, wiring harness,
DISCLAIMER: We recommend using an Authorised Dealer that offers an installation service
to install this product. Never cut or modify a harness as this could damage the head unit and
vehicle, as well as void the warranty of the product.
AM9X AM10X
Android Auto, Google Play, Android, are registered trademarks of
Google, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Apple, Apple Car Play, Apple iPhone, Apple Music and Siri are registered
trademarks of Apple, Inc.
audio-video lead & screws
TM
Advertisement
Table of Contents
Related Manuals for Aerpro AM9X
Summary of Contents for Aerpro AM9X
- Page 1 MULTIMEDIA RECEIVER Wireless Apple CarPlay & Android Auto USER MANUAL AM9X AM10X Android Auto, Google Play, Android, are registered trademarks of Google, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc. Apple, Apple Car Play, Apple iPhone, Apple Music and Siri are registered trademarks of Apple, Inc.
-
Page 2: Interface Icons
FEATURES • Large touchscreen LCD (1024 x 600) • Rear USB input (1.5A max charging) • Works with Apple CarPlay (wireless or wired) • 8 Band graphic EQ • Supports Android Auto (wireless or wired) • 8 EQ Presets • Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP) •... -
Page 3: Radio Mode
RADIO MODE To enter Radio Mode, touch “Radio” icon on the Main Menu Home screen/back button Seek down Radio frequency Seek up Display On/Off AF and TA settings FM Band button AM Band button Auto Store button EQ Mode button Keypad button Preset station list Auto Tuning... - Page 4 MEDIA PLAYING MODE This operation allows you to play various compatible formats. Touch the icon to return to previous track or press and hold the icon to fast rewind Touch the icon to play or pause the track Touch the icon to go to next track or press and hold the icon to fast forward Touch the end of the progress bar line and drag it left or right to the desired track time Touch the icon to repeat a folder or track...
-
Page 5: Bluetooth Mode
• This unit can be paired with 5 mobile phones, but only one can be active at a time. • The unit Bluetooth name is AERPRO 5 5 5 5 5 5 6 Touch the icon to enter pairing mode... - Page 6 CONNECTED DEVICES SCREEN Touch the icon to access the connected devices screen This screen displays paired devices and allows the user to turn Android Auto/Apple Carplay or other bluetooth features on or off. (If applicable to the device) Paired devices Apple Carplay activate/deactivate Android Auto activate/deactivate Bluetooth calling activate/deactivate...
-
Page 7: Setup Menu
SETUP MENU Setup menu allows you to change the settings within unit, General, Display, Audio and Others General Touch “General” on the Setup Menu • display for general settings Setting Options Functions Date Day / Month / Year Select to adjust calendar date Time Time Time... - Page 8 SETUP MENU Audio • Touch “Audio” on the Setup Menu display for audio adjustment settings Setting Options Functions Equalizer Balance and EQ setting Time Alignment Default / Presets / Reset Speaker delay Sub filter settings Subwoofer Filter On / Off On / Off Sound boost Loudness...
- Page 9 SETUP MENU Display • Touch “Display” on the Setup Menu display, then select a feature you want to adjust. Setting Options Functions Brightness 0 to 20 Touch the desired screen brightness Dimmer Mode Auto / Day / Night Touch the desired screen preset (Auto changes brightness when headlights on*) * Requires an illumination wire to be present in the vehicle (Usually orange wire in ISO harness needs to have a connection)
- Page 10 3. A pair message and a pairing request code may appear on your compatible device and head unit. Click allow to accept 4. An ‘Allow CarPlay with Aerpro while phone is locked’ message may appear on your device. Click allow to accept 5.
- Page 11 1. Before using Android Auto wirelessly, turn on the Bluetooth and WiFi function on the compatible device. 2. Navigate to the Bluetooth settings on your compatible device and select Aerpro for pairing 3. A pair message and a pairing request code may appear on your compatible device and head unit.
- Page 12 HOW TO USE CARPLAY ® Requirements • Lightning Data Cable • iPhone 5 or later • iPhone with iOS 7.1 or later • Data Plan for in app content • Siri activated Phone Setup (Before you begin): 1. Apple CarPlay ® features may operate differently than on your Apple iPhone ® 2.
-
Page 13: Using Siri
USING SIRI ® Apple CarPlay uses Siri to perform many actions like sending messages, placing calls, and looking up/setting POI/Destinations. A Siri session can be initiated on any screen • Touching and holding the Home icon on the CarPlay screen or •... - Page 14 HOW TO USE ANDROID AUTO ® Requirements • USB Data Cable • Compatible Android® phone with OS Android 6.0 or higher • Data Plan for in app content • Wireless Android Auto requires 5GHz(802.11/ac) Wi-Fi support (refer to page 18 of this manual) •...
- Page 15 ATTACHING THE HEADUNIT TO THE FACIA Before installation use the provided head unit screws and attach the head unit to the mounting positions on the facia. Also retain factory plastic mounting clips and any factory additional screws. Facias are vehicle specific and their installation may differ, and may have additional supplied brackets or parts and fittings.
-
Page 16: General Wiring Diagram
GENERAL WIRING DIAGRAM Video in Video Out Camera in Line Out-Front Right Line Out-Front Left CameraGround Line Out-Rear Right Camera12V+ Factory Camera AV in Right Line Out-Rear Left Retention harness AV in Left Line Out-Sub Woofer 12V+output TX (data wire not used) RX (data wire not used) GPS antenna Mic input... -
Page 17: Specifications
SPECIFICATIONS Display LCD Size 10.1" (AM10X) / 9" (AM9X) Resolution 1024*600 Touch Screen Capacitive System Specification OS System/CPU Linux 3.4.5 / SPHE8368U RAM / Flash Memory 128MB / 256MB DIN Size 2.0 DIN 2DIN short body Power Output Rated Power 4CH x 25W (4 Ohm @ 14.4 V, 1 kHz, THD 10 %) -
Page 18: Faq & Troubleshooting
FAQ/TROUBLESHOOTING My Android phone will not connect wirelessly to the head unit • Your mobile phone must be a compatible Android phone with an active data plan, 5 GHz Wi-Fi support (802.11/ac), and the latest version of the Android Auto app. •... -
Page 19: Safety Information And Warnings
TECHNICAL ASSISTANCE Please retain this user guide for future reference. If you would like to download a digital copy of this manual, or other Aerpro manuals/software, please visit the Aerpro.com website and search for information on your model. This quick start guide is considered correct at time of printing but is subject to change.
