HP Compaq dx6100 ST Supplementary Manual

HP Compaq Business Desktop
dx6100 Series Personal Computer
Illustrated Parts Map
Slim Tower Chassis
System Unit
1 Computer cover assy with front bezel and no inserts
2 Power supply, PFC
3 Chassis assembly
Cables
1 SATA hard drive cable, 24" (326965-007)
1 SATA hard drive cable, 18" (326965-002)
2 Power switch/LED cable - use switch holder
(370857-001)
3 Audio cable (CD to system board) (387527-001)
4 Front I/O device with cable
* Diskette drive cable (168999-006)
* UATA data cable, 8.6" (108950-054)
* Flying serial port with cable
*Not shown
© 2004 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
All other product names mentioned herein may be
trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided "as is" without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
Standard and Optional Boards
1 System board with alcohol pad and thermal grease
Memory Modules
370503-001 * 128 MB/400 MHz FSB
350030-001
* 256 MB/400 MHz FSB
not spared * 512 MB/400 MHz FSB
* 1.0 GB/400 MHZ FSB
Intel Pentium 4 Processors with alcohol pad and thermal grease
* 2.8 GHz\800 MHz FSB, 1MB cache
* 3.0 GHz\800 MHz FSB, 1MB cache
* 3.2 GHz\800 MHz FSB, 1MB cache
* 3.4 GHz\800 MHz FSB, 1MB cache
* 3.6 GHz\800 MHz FSB, 1MB cache
Other Cards
* PCI Modem, International, LP bracket
PC MCIA Reader with PCI card
* Intel Pro 10/100/1000 MT NIC, LP bracket
* FireWire 1394 card, 2 ext/1 int port, LP bracket
Wireless LAN adapters (802.11b)
* 13 channel, LP bracket - use cable 333365-005
Graphics Solutions
* 4 Layer ADD2 Graphics, LP bracket
* ATI RV370 VGA graphics, 64M, LP bracket
* ATI RV370 VGA graphics, 128M, LP bracket
*Not shown
LP= Low profile mouinting bracket
FH = Full height mounting bracket
368388-001
346142-005
368387-001
149806-005
368386-001
370499-001
368389-001
370500-001
Development Company, L.P.
warranty.
August 2004
Document Number
361289-001
361682-001
335697-005
335698-005
335699-005
335700-005
367594-001
366643-001
366644-001
367415-001
367416-001
361287-021
331589-001
338154-005
361551-001
354900-005
361264-001
364833-001
364834-001
Mass Storage Devices (not illustrated)
40 GB\7200 RPM SATA hard drive
80 GB\7200 RPM SATA hard drive
120 GB\7200 RPM SATA hard drive
160 GB\7200 RPM SATA hard drive
Diskette drive with mounting screws
48X CD-ROM drive with mounting screws
52X CD-ROM drive
48X/32X/48X CD-RW
48X/32X/48X +16X DVD/CD-RW
8X DVD+R/RW
16/40X DVD ROM Drive
Zip 250 Drive with mounting bracket
Zip 250 drive without mounting bracket
Miscellaneous Parts
1 Front bezel assembly with no inserts
* 5.25" Bay bezel blank (carbonite)
2 CD drive bezel with diskette drive
3 CD drive bezel without diskette drive
4 CD drive bezel with Zip drive
5# Speaker with alcohol pad and thermal grease
6 Active heatsink with thermal grease and alcohol pad 367857-001
7 Chassis fan
* Heatsink duct baffle
8 Heatsink retention plate with thumbscrew
9 Power switch holder with LED holders (use with
368387-001 switch)
* Mouse, 2-Button, PS/2 with scroll wheel
* Mouse, 2-Button, USB, optical with scroll wheel
* Mouse, 2-Button, USB, with scroll wheel
* Drive Key, 16 MB
* Drive Key, 128 MB
* Drive Key, 256 MB
* Real-time-clock battery
* Expansion card retainer kit
* Port control cover
* Rubber foot (4 each)
* Kensington lock
*Not shown
#The heatsink must be removed before removing the speaker. Make sure
the mating surfaces between the heatsink and the processor have been
cleaned with the alcohol pad provided and fresh thermal grease has been
applied when reinstalling the heatsink.
Miscellaneous Screw Kit (not illustrated)
Miscellaneous screw kit
M3 x 5mm, hitop (263585-001) 4 ea
#6-32 x .250, hitop (262508-001) 8 ea
#6-32 x .250, pan head (101517-067) 3 ea
#6-32 x .312, hitop (262508-002) 4 ea
#6-19 x .312, pan head (101346-068) 2 ea
#6-19 x .315, T15 head (331310-001) 2 ea
See next page for keyboard spares
365555-001
345713-005
365556-001
345712-005
333505-005
326773-005
333969-005
346788-005
359493-005
358688-005
325313-005
333504-005
326772-005
368083-001
335937-005
370501-001
367852-001
370504-001
368084-001
366641-001
375514-001
370709-001
370857-001
323614-005
323615-005
323617-005
324780-005
349988-005
344249-005
153099-001
377661-001
367856-001
370708-001
370856-001
337237-005
