- Page 1 USE AND CARE GUIDE 3 SEAT SWING WITH CANOPY Product Code: D71 20558 KSN: 0-08803510-0 UPC Code: 095454822442 Date of Purchase: _____/ _____/ _____...
-
Page 2: Table Of Contents
Thank you for your purchase Thank you for your purchase! We are pleased that you have chosen Sears for your outdoor furniture purchase. We hope that you enjoy the unmatched quality, comfort, and style of your new patio set. Every piece is meticulously considered all the way down to the smallest details, exclusively for you, by our world class design team. -
Page 3: Safety Information
Safety Information SET UP YOUR FURNITURE PROPERLY Ensure that all parts are assembled properly and fully tightened as per the instructions. When placing in the desired location, ensure that all legs are resting on the same surface. you may adjust the legs levelers as required to ensure that the item stands in a rigid position. -
Page 4: Warranty
Warranty Cushions are covered for a period of one (1) year against defects in material or workmanship. Frames are warranted to be free from defects in material workmanship for a period of one (1) year. Exclusions: items used for commercial, contract, or other non-... -
Page 5: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY To prevent damage, place all parts on a soft surface during assembly. Remove all protective caps before beginning assembly. It takes about 90 minutes for two person to complete all the assembly. OBSERVE WEIGHT LIMITS The recommended weight limits for the following products are listed below: Swing: 600 lbs CAUTION: If you overload your furniture, injuries can occur. -
Page 6: Package Contents
Pre-Assembly (continued ) Package Contents PART DESCRIPTION QUANTITY Top Cross Bar Back Leg Tube R1 / L1 Front Leg Tube Rear Brace Side Tube Canopy Frame Canopy Side Frame Armrest R1 / L1 Seat Seat Cushion Canopy Foot Adjustment Knob Hook... -
Page 7: Assembly Instructions
Assembly Instructions 1. Bring the top end of leg tube #3-L and #2 together using two hardware sets A. Do not tighten the bolts and nuts. Repeat for the other side #3-R. Attach tube #1 at both ends to top end of leg tubes #2 and tighten the bolts and nuts. - Page 8 Assembly Instructions (continued ) Fig. 3b Fig. 3a: CANOPY ASSEMBLY #3-R 1. Insert tubes #6 into the sleeves of the canopy cover #11. Insert both tubes #6 into ends of tube #7. (See Fig. 3a). 2. First, attach a tube #7 on to the main frame using a 95mm bolt #20 and a knob #14 to connect with top end of leg tube #3-R, and then insert...
-
