Summary of Contents for Garden Oasis EAST POINT 5PC BAR SET
- Page 1 OWNER’S MANUAL EAST POINT 5PC BAR SET Product code: D71 M12195 UPC code: 769455 761507 Vendor Item: SS-J-251-2MT Date of purchase: _____/ _____/ _____...
-
Page 2: Item Description
PARTS Read through all the instructions before beginning assembly. Unpack and identify all the parts. Place them on a flat, non-abrasive surface. Assembly by two people is recommended. ITEM DESCRIPTION QUANTITY Left Tempered Glass with Rim Right Tempered Glass with Rim Left Bottom Mesh Shelf Right Bottom Mesh Shelf Left Side Apron Panel... - Page 3 ACCESSORIES Ja (13 + 1 spare) Jf (1 spare) Short Bolt Glass Bumper Jg (2) Jb (8 + 1 spare) Long Bolt Allen Wrench Jc (11 + 1 spare) Jh (2) Hex Wrench Ji (1) Jd (21) Touch-up Paint Metal Washer Je (11) Jj (1) Lock Washer...
- Page 4 Adjust panel leg feet up and down to level the unit. Ja x 4 Short Bolt Jc x 4 Jd x 4 Metal Washer Je x 4 Lock Washer Note: The arrow points top side. Tighten all bolts and nuts.
- Page 5 Push (do not force) mesh shelf into place. Ja x 4 Short Bolt Jc x 4 Jd x 4 Metal Washer Je x 4 Lock Washer Do not tighten completely. Repeat procedure for the other support bar (I). Securely tighten all bolts and nuts.
- Page 6 Ja x 3 Short Bolt Jc x 3 Jd x 3 Metal Washer Je x 3 Lock Washer Tighten all bolts and nuts. Ja x 2 Short Bolt Jd x 2 Metal Washer Do not tighten completely.
-
Page 7: Care Instructions
Jb x 4 Long Bolt Jd x 4 Metal Washer Do not tighten completely. Jb x 4 Long Bolt Jd x 4 Metal Washer Tighten all bolts. Twist knobs to readjust level. Your bar table is ready for use. CARE INSTRUCTIONS Wash with a mild solution of soap and water;...
